| Item No. |
Part Number |
Name | Req | Table Name | Price |
Buy |
|
| 1 |
GM11.5-373
|
Crown & Pinion, 3.73 Ratio, Quality Gear
| 1 | Gm11.5" 14 Bolt Rear Differential | Log in to see
prices |
|
|
| 1 |
GM11.5-410
|
Crown & Pinion, 4.10 Ratio, Quality Gear
| 1 | Gm11.5" 14 Bolt Rear Differential | Log in to see
prices |
|
|
| 1 |
GM11.5-463
|
Crown & Pinion, 4.63 Ratio, Quality Gear
| 1 | Gm11.5" 14 Bolt Rear Differential | Log in to see
prices |
|
|
| 1 |
GM11.5-488
|
Crown & Pinion, 4.88 Ratio, Quality Gear
| 1 | Gm11.5" 14 Bolt Rear Differential | Log in to see
prices |
|
|
| 1 |
GM11.5-513
|
Crown & Pinion, 5.13 Ratio, Quality Gear
| 1 | Gm11.5" 14 Bolt Rear Differential | Log in to see
prices |
|
|
| 2 |
40000278
|
Loaded Open Diff Case Assembly
| 1 | Gm11.5" 14 Bolt Rear Differential | Log in to see
prices |
|
|
| 2A |
5086962AA
|
Loaded POSI Case (Helical)
| 1 | Gm11.5" 14 Bolt Rear Differential | Log in to see
prices |
|
|
| 2A |
40023075
|
AAM Loaded Open Case Assembly
| 1 | Gm11.5" 14 Bolt Rear Differential | Log in to see
prices |
|
|
| 3 |
26062829
|
Side Gear
| 2 | Gm11.5" 14 Bolt Rear Differential | Log in to see
prices |
|
|
| 4 |
26062828
|
Pinion Gear
| 2 | Gm11.5" 14 Bolt Rear Differential | Log in to see
prices |
|
|
| 5 |
40007448
|
Cross Shaft
| 1 | Gm11.5" 14 Bolt Rear Differential | Log in to see
prices |
|
|
| 7 |
--
|
Axle Shaft
| | Gm11.5" 14 Bolt Rear Differential | Log in to see
prices |
|
|
| 9 |
12471484
|
Pinion Nut
| 1 | Gm11.5" 14 Bolt Rear Differential | Log in to see
prices |
|
|
| 10 |
4002212
|
Pinion Gear Washer
| 2 | Gm11.5" 14 Bolt Rear Differential | Log in to see
prices |
|
|
| 11 |
40002211
|
Side Gear Washer
| 2 | Gm11.5" 14 Bolt Rear Differential | Log in to see
prices |
|
|
| 12 |
5086783AB
|
Crown Bolt (Metric)
| 12 | Gm11.5" 14 Bolt Rear Differential | Log in to see
prices |
|
|
| 20 |
1247164
|
Hub Seal
| 2 | Gm11.5" 14 Bolt Rear Differential | Log in to see
prices |
|
|
| 22 |
KOY LM104949
|
Outer Wheel Bearing, Cone
| 2 | Gm11.5" 14 Bolt Rear Differential | Log in to see
prices |
|
|
| 22 |
KOY LM104911
|
Outer Wheel Bearing, Cup
| 2 | Gm11.5" 14 Bolt Rear Differential | Log in to see
prices |
|
|
| 23 |
KOY 387AS
|
Inner Wheel Bearing, Cone
| 2 | Gm11.5" 14 Bolt Rear Differential | Log in to see
prices |
|
|
| 23 |
KOY 382A
|
Inner Wheel Bearing, Cup
| 2 | Gm11.5" 14 Bolt Rear Differential | Log in to see
prices |
|
|
| Ni |
40001429
|
Cross Shaft Lock Pin
| 1 | Gm11.5" 14 Bolt Rear Differential | Log in to see
prices |
|
|
| Ni |
26060977
|
Pinion Yoke Sleeve
| 1 | Gm11.5" 14 Bolt Rear Differential | Log in to see
prices |
|
|
| 3 |
26062829
|
Side Gear
| 2 | GM11.5 - SPGK - Internal Nest Kit | Log in to see
prices |
|
|
| 4 |
26062828
|
Pinion Gear
| 2 | GM11.5 - SPGK - Internal Nest Kit | Log in to see
prices |
|
|
| 5 |
40007448
|
Cross Shaft
| 1 | GM11.5 - SPGK - Internal Nest Kit | Log in to see
prices |
|
|
| Ni |
40001429
|
Cross Shaft Lock Pin
| 1 | GM11.5 - SPGK - Internal Nest Kit | Log in to see
prices |
|
|
| 10 |
40002212
|
Pinion Gear Washer
| 2 | GM11.5 - SPGK - Internal Nest Kit | Log in to see
prices |
|
|
| 11 |
40002211
|
Side Gear Washer
| 2 | GM11.5 - SPGK - Internal Nest Kit | Log in to see
prices |
|
|
| 9, 14, 15, 16, 18, 19 |
R1150
|
Master Overhaul Kit
| 1 | GM 11.5 Rear 2001-2010 | Log in to see
prices |
|
|
| 9 |
12471484
|
Pinion Nut
| 1 | R1150 Master Rebuild Kit (2001 - 2010) | Log in to see
prices |
|
|
| 14 |
12471647
|
Crush Sleeve
| 1 | R1150 Master Rebuild Kit (2001 - 2010) | Log in to see
prices |
|
|
| 15 |
260604030
|
Pinion Seal
| 1 | R1150 Master Rebuild Kit (2001 - 2010) | Log in to see
prices |
|
|
| 16 |
KOY 3920
|
Diff Side Bearing, Cup
| 2 | R1150 Master Rebuild Kit (2001 - 2010) | Log in to see
prices |
|
|
| 16 |
KOY 3984
|
Diff Side Bearing, Cone
| 2 | R1150 Master Rebuild Kit (2001 - 2010) | Log in to see
prices |
|
|
| 18 |
KOY HM807010
|
Inner Pinion Bearing, Cup
| 1 | R1150 Master Rebuild Kit (2001 - 2010) | Log in to see
prices |
|
|
| 18 |
KOY HM807046
|
Inner Pinion Bearing, Cone
| 1 | R1150 Master Rebuild Kit (2001 - 2010) | Log in to see
prices |
|
|
| 19 |
KOY M802011
|
Outer Pinion Bearing, Cup
| 1 | R1150 Master Rebuild Kit (2001 - 2010) | Log in to see
prices |
|
|
| 19 |
KOY M802048
|
Outer Pinion Bearing, Cone
| 1 | R1150 Master Rebuild Kit (2001 - 2010) | Log in to see
prices |
|
|
| 9, 12, 14, 15, 16, 18, 19 |
R1150A
|
Master Overhaul Kit
| 1 | GM 11.5 Rear 2011-2017 | Log in to see
prices |
|
|
| 9 |
12471484
|
Pinion Nut
| 1 | R1150A Master Rebuild Kit (2011-2013) | Log in to see
prices |
|
|
| 12 |
5086783AB
|
Ring Gear Bolts
| 12 | R1150A Master Rebuild Kit (2011-2013) | Log in to see
prices |
|
|
| 15 |
26064030
|
Pinion Seal
| 1 | R1150A Master Rebuild Kit (2011-2013) | Log in to see
prices |
|
|
| 16 |
KOY 3984
|
Side Bearing, Cone
| 2 | R1150A Master Rebuild Kit (2011-2013) | Log in to see
prices |
|
|
| 16 |
KOY 3920
|
Side Bearing, Cup
| 2 | R1150A Master Rebuild Kit (2011-2013) | Log in to see
prices |
|
|
| 18 |
NTN NP516549
|
Inner Pinion Bearing, Cone
| 1 | R1150A Master Rebuild Kit (2011-2013) | Log in to see
prices |
|
|
| 18 |
NTN NP673386
|
Inner Pinion Bearing, Cup
| 1 | R1150A Master Rebuild Kit (2011-2013) | Log in to see
prices |
|
|
| 19 |
KOY STD4183KELFT
|
Outer Pinion Bearing Set
| 1 | R1150A Master Rebuild Kit (2011-2013) | Log in to see
prices |
|
|
| Ni |
1112
|
Pinion Shims
| Ar | R1150A Master Rebuild Kit (2011-2013) | Log in to see
prices |
|
|
 |
