| Item No. |
Part Number |
Name | Req | Table Name | Price |
Buy |
|
| 1 |
12471387
|
Case, Differential (Loaded, Posi)
| 1 | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 2 |
NSS
|
Pin, Gov Stop (Part of #1,11)
| 1 | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 3 |
14039027
|
Lockscrew (M10 x 1.5)
| 1 | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 4 |
462776
|
Bushing, Differential Engagement
| 1 | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 5 |
14048409
|
Bushing, Differential Lockout
| 1 | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 6 |
14039026
|
Washer, Pinion
| 2 | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 7 |
14012698
|
Gear, Pinion
| 2 | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 8 |
15599626
|
Washer, Side Gear LH (.010)
| Ar | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 8 |
15599627
|
Washer, Side Gear LH (.015)
| Ar | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 8 |
15599628
|
Washer, Side Gear LH (.020)
| Ar | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 8 |
15599629
|
Washer, Side Gear LH (.025)
| Ar | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 8 |
15599630
|
Washer, Side Gear LH (.030)
| Ar | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 8 |
15599631
|
Washer, Side Gear LH (.035)
| Ar | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 8 |
15599632
|
Washer, Side Gear LH (.040)
| Ar | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 8 |
15599633
|
Washer, Side Gear LH (.045)
| Ar | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 9 |
15599624
|
Plate Kit, Locking, LH (Includes #19)
| 1 | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 10 |
15599647
|
Gear, Splined Side (LH)
| 1 | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 11 |
14022121
|
Governor Kit, Differential (Includes #2)
| 1 | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 12 |
26005079
|
Plate Kit, Locking, LH
| 1 | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 13 |
14039035
|
Washer, Side Gear LH (.022)
| Ar | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 13 |
462769
|
Washer, Side Gear LH (.027)
| Ar | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 13 |
14039036
|
Washer, Side Gear LH (.032)
| Ar | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 13 |
462770
|
Washer, Side Gear RH (.037)
| Ar | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 13 |
14039037
|
Washer, Side Gear LH (.040)
| Ar | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 13 |
462771
|
Washer, Side Gear RH (.042)
| Ar | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 13 |
14039038
|
Washer, Side Gear LH (.044)
| Ar | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 13 |
462772
|
Washer, Side Gear RH (.048)
| Ar | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 13 |
14039039
|
Washer, Side Gear LH (.052)
| Ar | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 14 |
462786
|
Sleeve, Diff Side Thrust
| 1 | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 15 |
NSS
|
Washer, Wave (Part of #12)
| 1 | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 16 |
12471412
|
Cam, Plate Diff
| 1 | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 17 |
14039029
|
Block, Thrust (1.598" Thick)
| 1 | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 17 |
15599672
|
Block, Thrust (1.602" Thick)
| 1 | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 17 |
15599673
|
Block, Thrust (1.606" Thick)
| 1 | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 17 |
14039031
|
Block, Thrust (1.610" Thick)
| 1 | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 17 |
15599675
|
Block, Thrust (1.614" Thick)
| 1 | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 17 |
15599676
|
Block, Thrust (1.618" Thick)
| 1 | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 17 |
14039033
|
Block, Thrust (1.622" Thick)
| 1 | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 17 |
15599679
|
Block, Thrust (1.626" Thick)
| 1 | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 17 |
15599680
|
Block, Thrust (1.630" Thick)
| 1 | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 18 |
14012700
|
Shaft, Pinion (Length: 5.824")
| 1 | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 19 |
462787
|
Clip Guide, RH
| 1 | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 20 |
15599623
|
Clip Guide, LH
| 1 | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| 21 |
15599648
|
Gear, Side Cam, LH
| 1 | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
| Ni |
M-19546-A-1
|
Posi Additive
| 1 | GM 9 1/2" 14 Bolt Semi Float Posi Differential (1981 & UP) | Log in to see
prices |
|
|
 |
