| Item No. |
Part Number |
Name | Notes | Price |
Buy |
|
| 1 |
1354 672 001
|
Assy, Front Adapter
| All Exc. Below | Log in to see
prices |
|
|
| 1 |
1354 672 002
|
Assy, Front Adapter
| Assy# 1354-022,023 | Log in to see
prices |
|
|
| 1A |
1354 172 001
|
Adapter, Front
| All Exc. Below | Log in to see
prices |
|
|
| 1A |
1354 172 002
|
Adapter, Front
| Assy# 1354-022,023 | Log in to see
prices |
|
|
| 1B |
16485
|
Seal, Input
| Can Use 1900 044 009 | Log in to see
prices |
|
|
| 1C |
1000 043 017
|
Pin
| | Log in to see
prices |
|
|
| 1D |
1000 139 039
|
Ring, Retaining
| | Log in to see
prices |
|
|
| Ni |
1900 183 010
|
Bolt, Adapter Mount
| All Exc. Below (M10X1.5X31) 6 Req'D | Log in to see
prices |
|
|
| Ni |
1300 183 018
|
Bolt, Adapter Mount
| Assy# 1354-005,014 (M10X1.5X30) 6 Req'D | Log in to see
prices |
|
|
| 2 |
1000 139 040
|
Ring, Retaining
| | Log in to see
prices |
|
|
| 3 |
6009NR
|
Bearing, Input
| Can Use 1000 130 011 | Log in to see
prices |
|
|
| 4 |
1350 193 001
|
Washer, Thrust
| | Log in to see
prices |
|
|
| 5 |
1354 659 002
|
Assy, Planetary Complete
| All Exc. Below | Log in to see
prices |
|
|
| 5 |
1350 659 008
|
Assy, Planetary Complete
| Assy# 1354-005,014 | Log in to see
prices |
|
|
| 5A |
1354 659 001
|
Carrier, Planetary
| All Exc. Below | Log in to see
prices |
|
|
| 5A |
1350 659 001
|
Carrier, Planetary
| Assy# 1354-005,014 | Log in to see
prices |
|
|
| 5B |
1350 165 001
|
Gear, Planetary Sun
| | Log in to see
prices |
|
|
| 5C |
1350 014 001
|
Plate, Thrust
| | Log in to see
prices |
|
|
| 5D |
1000 139 043
|
Ring, Retaining
| | Log in to see
prices |
|
|
| 6 |
1354 689 001
|
Assy, Input Shaft
| | Log in to see
prices |
|
|
| 6A |
1354 189 001
|
Shaft, Input
| | Log in to see
prices |
|
|
| 6B |
M18161
|
Bearing, Input Pocket
| | Log in to see
prices |
|
|
| 6C |
1345 127 002
|
Bushing, Input Pocket
| | Log in to see
prices |
|
|
| 7 |
1900 072 005
|
Breather
| | Log in to see
prices |
|
|
| 8 |
1354 089 002
|
Hub, Reduction
| All Exc. Below | Log in to see
prices |
|
|
| 8 |
1350 089 001
|
Hub, Reduction
| Assy# 1354-005,014 | Log in to see
prices |
|
|
| 9 |
1354 671 006
|
Assy, Mainshaft & Pump
| All Exc. Below | Log in to see
prices |
|
|
| 9 |
1354 671 003
|
Assy, Mainshaft & Pump
| Assy# 1354-005,014 | Log in to see
prices |
|
|
| 9A |
1354 171 006
|
Mainshaft
| All Exc. Below | Log in to see
prices |
|
|
| 9A |
1354 171 003
|
Mainshaft
| Assy#1354-005,014 | Log in to see
prices |
|
|
| 9B |
1345 043 007
|
Pin, Pump
| Assy# 1354-005,014 - 2 Req'D | Log in to see
prices |
|
|
| Ni |
1900 043 004
|
Pin, Pump Spring
| W/ Gerotor Pump | Log in to see
prices |
|
|
| 9C |
1345 156 004
|
Spring
| Assy# 1354-005,014 | Log in to see
prices |
|
|
| 9D |
1345 039 007
|
Cover, Front Pump
| Assy# 1354-005,014 | Log in to see
prices |
|
|
| 9E |
1345 097 004
|
Housing, Pump
| Assy# 1354-005,014 | Log in to see
prices |
|
|
| 9F |
1345 039 005
|
Cover, Rear Pump
| Assy# 1354-005,014 | Log in to see
prices |
|
|
| 9G |
1350 056 004
|
Retainer, Pump
| Assy# 1354-005,014 | Log in to see
prices |
|
|
| Ni |
1345 183 003
|
Screw, Pump Housing
| Assy# 1354-005,014 (M5X0.8X20) 4 Req'D | Log in to see
prices |
|
|
| Ni |
4400 508 001
|
Assy, Gerotor Pump
| All Exc. Assy# 1354-005,014 | Log in to see
prices |
|
|
| Ni |
4400 008 001
|
Pump, Gerotor
| All Exc. Assy# 1354-005,014 | Log in to see
prices |
|
|
| Ni |
4400 039 001
|
Cover, Gerotor Pump
| All Exc. Assy# 1354-005,014 | Log in to see
prices |
|
|
| Ni |
1900 138 001
|
Gear, Pump
| All Exc. Assy# 1354-005,014 | Log in to see
prices |
|
|
| Ni |
1900 183 005
|
Screw, Gerotor Pump
| All Exc. Assy# 1354-005,014 (M5) 4 Req'D | Log in to see
prices |
|
|
| 10 |
1345 056 005
|
Clamp, Hose
| | Log in to see
prices |
|
|
| 11 |
1350 034 002
|
Hose
| | Log in to see
prices |
|
|
| 12 |
1345 238 001
|
Filter
| | Log in to see
prices |
|
|
| 13 |
1350 144 002
|
Sprocket, Chain Drive
| All Exc. Below | Log in to see
prices |
|
|
| 13 |
1354 144 004
|
Sprocket, Chain Drive
| Assy# 1354-014 | Log in to see
prices |
|
|
| 14 |
1350 589 003
|
Assy, Lockup
| | Log in to see
prices |
|
|
| 14A |
1900 089 001
|
Hub, Lockup
| | Log in to see
prices |
|
|
| 14B |
1350 156 007
|
Spring
| | Log in to see
prices |
|
|
| 14C |
4400 055 002
|
Collar
| | Log in to see
prices |
|
|
| 14D |
1000 139 041
|
Ring, Retaining
| | Log in to see
prices |
|
|
| 15 |
1350 090 001
|
Hub, Shift Collar
| | Log in to see
prices |
|
|
| 16 |
1354 212 001
|
Housing, Clutch
| | Log in to see
prices |
|
|
| 17 |
1900 139 059
|
Ring, Retaining
| Assy #1354-022, 023 | Log in to see
prices |
|
|
| 18 |
1900 149 001
|
Nut, Yoke
| | Log in to see
prices |
|
|
| 19 |
1000 047 016
|
Washer, Yoke
| | Log in to see
prices |
|
|
| 20 |
1000 044 012
|
Washer, Rubber
| | Log in to see
prices |
|
|
| 21 |
1300 031 006
|
Flange, Companion
| All Exc, Assy# 1354-022,023 | Log in to see
prices |
|
|
| 22 |
16485
|
Seal, Oil
| All Exc, Assy# 1354-022,023 | Log in to see
prices |
|
|
| 23 |
1350 110 002
|
Gear, Speedo
| All Exc, Assy# 1354-022,023 (7T) | Log in to see
prices |
|
|
| 23 |
1900 053 023
|
Spacer
| Assy# 1354-022, 023 | Log in to see
prices |
|
|
| 24 |
1354 539 002
|
Assy, Rear Case Half
| All Exc. Below | Log in to see
prices |
|
|
| 24 |
1354 539 003
|
Assy, Rear Case Half
| Assy# 1354-017 | Log in to see
prices |
|
|
| 24 |
1354 539 006
|
Assy, Rear Case Half
| Assy# 1354-022, 023 | Log in to see
prices |
|
|
| 24A |
1354 039 002
|
Case, Rear Half
| All Exc. Below | Log in to see
prices |
|
|
| 24A |
1354 039 003
|
Case, Rear Half
| Assy# 1354-017 | Log in to see
prices |
|
|
| 24A |
1354 039 006
|
Case, Rear Half
| Assy# 1354-022,023 | Log in to see
prices |
|
|
| 24B |
6206NR
|
Bearing, Rear Output
| Can Use 1000 130 008 | Log in to see
prices |
|
|
| 24C |
R6A-7.5
|
Ring, Retaining
| | Log in to see
prices |
|
|
| 24D |
JH1612
|
Bearing, Needle
| Can Use 1000 132 039 | Log in to see
prices |
|
|
| Ni |
1900 052 008
|
Plug, Drain/Fill
| (.50"Npt-14) | Log in to see
prices |
|
|
| 25 |
1350 100 001
|
Shift Rail
| | Log in to see
prices |
|
|
| 26 |
4400 156 001
|
Spring
| | Log in to see
prices |
|
|
| 27 |
1354 096 003
|
Fork
| | Log in to see
prices |
|
|
| 28 |
1356 235 001
|
Pad, Shift Fork
| All Exc. Below | Log in to see
prices |
|
|
| 28 |
4400 235 001
|
Pad, Shift Fork
| Assy# 1354-005, 014 | Log in to see
prices |
|
|
| 29 |
1350 543 001
|
Assy, Pin, Roller & Retainer
| | Log in to see
prices |
|
|
| 29A |
1900 043 009
|
Pin
| | Log in to see
prices |
|
|
| 29B |
1352 127 001
|
Roller
| | Log in to see
prices |
|
|
| 29C |
1350 040 002
|
Retainer
| | Log in to see
prices |
|
|
| 30 |
1354 596 001
|
Assy, Reduction Shift Fork
| All Exc. Below | Log in to see
prices |
|
|
| 30 |
1350 596 005
|
Assy, Reduction Shift Fork
| Assy# 1354-005,014 | Log in to see
prices |
|
|
| 30A |
1354 096 002
|
Fork, Reduction Shift
| All Exc. Below | Log in to see
prices |
|
|
| 30A |
1350 096 004
|
Fork, Reduction Shift
| Assy# 1354-005,014 | Log in to see
prices |
|
|
| 30B |
1356 235 001
|
Pad, Shift Fork
| All Exc. Below | Log in to see
prices |
|
|
| 30B |
4400 235 001
|
Pad, Shift Fork
| Assy# 1354-005,014 | Log in to see
prices |
|
|
| 31 |
1000 012 002
|
Magnet
| | Log in to see
prices |
|
|
| 32 |
1300 531 005
|
Assy, Front Output Yoke
| | Log in to see
prices |
|
|
| 32A |
1300 031 005
|
Yoke, Front Output
| Double Carden End | Log in to see
prices |
|
|
| 32B |
1350 035 002
|
Deflector
| All Exc. Below | Log in to see
prices |
|
|
| 33 |
1354 565 002
|
Assy, Front Case Half
| | Log in to see
prices |
|
|
| 33A |
1354 065 002
|
Case, Front Half
| | Log in to see
prices |
|
|
| 33B |
1354 162 001
|
Gear, Planetary Ring
| | Log in to see
prices |
|
|
| 33C |
16485
|
Seal, Output
| Can Use 1900 044 009 | Log in to see
prices |
|
|
| 33D |
1900 043 008
|
Dowel Pin
| 2 Req'D | Log in to see
prices |
|
|
| 33E |
6206NR
|
Bearing, Front Output
| Can Use 1000 130 008 | Log in to see
prices |
|
|
| 33F |
R6A-7.5
|
Ring, Retaining
| | Log in to see
prices |
|
|
| Ni |
1300 183 010
|
Bolt, Case
| All Exc. Below (M10X1.5X30) 9 Req'D | Log in to see
prices |
|
|
| Ni |
1900 183 018
|
Bolt, Case
| Assy# 1354-005,014 (M10X1.5X31) 9 Req'D | Log in to see
prices |
|
|
| 34 |
1354 122 002
|
Shaft, Shift
| | Log in to see
prices |
|
|
| 35 |
1350 156 008
|
Spring
| | Log in to see
prices |
|
|
| 36 |
1354 099 002
|
Cam
| | Log in to see
prices |
|
|
| 37 |
1350 053 002
|
Spacer
| | Log in to see
prices |
|
|
| 38 |
1354 671 009
|
Assy, Output Shaft
| Assy# 1354-022,023 | Log in to see
prices |
|
|
| 38 |
1354 171 004
|
Shaft, Output
| All Exc. Below | Log in to see
prices |
|
|
| 38 |
1354 171 009
|
Shaft, Output
| Assy# 1354-022,023 | Log in to see
prices |
|
|
| 39 |
1354 144 004
|
Sprocket, Chain Driven
| All Exc. Below | Log in to see
prices |
|
|
| 39 |
1354 144 001
|
Sprocket, Chain Driven
| Assy# 1354-014 | Log in to see
prices |
|
|
| 40 |
1350 193 003
|
Spacer
| | Log in to see
prices |
|
|
| 41 |
1000 139 038
|
Ring, Retaining
| | Log in to see
prices |
|
|
| 42 |
1350 143 001
|
Chain
| 1.25" Wide | Log in to see
prices |
|
|
| 43 |
1300 127 002
|
Bushing, Shift Motor
| | Log in to see
prices |
|
|
| 44 |
3687
|
Seal
| Can Use 1300 044 001 | Log in to see
prices |
|
|
| 45 |
1354 648 006
|
Assy, Motor
| All Exc. Below | Log in to see
prices |
|
|
| 45 |
1354 648 005
|
Assy, Motor
| Assy# 1354-017,022 | Log in to see
prices |
|
|
| 45 |
1354 648 008
|
Assy, Motor
| Assy# 1354-023 | Log in to see
prices |
|
|
| Ni |
1300 149 002
|
Connector, Wire
| All Exc. Assy# 1354-017,022 023 | Log in to see
prices |
|
|
| Ni |
1000 056 007
|
Wire Clip
| Assy# 1354-005,014 | Log in to see
prices |
|
|
| 46 |
1350 640 003
|
Assy, Sensor & O-Ring
| Assy# 1354-005,013,014,019 | Log in to see
prices |
|
|
| 46A |
1350 140 002
|
Pickup, Magnetic
| Assy# 1354-005,013,014,019 | Log in to see
prices |
|
|
| 46B |
1000 141 014
|
O-Ring
| Assy# 1354-005,013,014,019 | Log in to see
prices |
|
|
| Ni |
1900 183 012
|
Bolt, Shift Motor
| 3 Req'D | Log in to see
prices |
|
|
| Ni |
1350 140 011
|
Terminal, Wire
| Assy# 1354-005,013,014,019 | Log in to see
prices |
|
|
| 47 |
1354 056 004
|
Bracket
| Assy# 1354-005,013,014,019 | Log in to see
prices |
|
|
| 47 |
1354 056 005
|
Bracket
| Assy# 1354-017,022,023 | Log in to see
prices |
|
|
| 48 |
1900 645 002
|
Assy, Electric Coil
| All Exc. Below | Log in to see
prices |
|
|
| 48 |
4400 645 006
|
Assy, Electric Coil
| Assy# 1354-017,022,023 | Log in to see
prices |
|
|
| Ni |
1900 145 002
|
Clutch, Coil
| All Exc. Assy# 1354-017,022,023 | Log in to see
prices |
|
|
| Ni |
1350 140 010
|
Nut
| 3 Req'D | Log in to see
prices |
|
|
| Ni |
1000 141 475
|
O-Ring
| All Exc. Assy# 1354-017,022,023 - 3 Req'D | Log in to see
prices |
|
|
| Ni |
1300 141 461
|
O-Ring
| All Exc. Assy# 1354-017,022,023 | Log in to see
prices |
|
|
| Ni |
1900 056 010
|
Spacer
| Assy# 1354-017,022,023 | Log in to see
prices |
|
|
| Ni |
1900 183 002
|
Screw, Hex Head Cap
| | Log in to see
prices |
|
|
| Ni |
PK 1356
|
Kit, Pump Repair
| W/O Gerotor Pump | Log in to see
prices |
|
|
| Ni |
TC1354
|
Kit, Bearing & Seal
| | Log in to see
prices |
|
|
| Ni |
SK1354
|
Kit, Seal & Gasket
| | Log in to see
prices |
|
|
 | |
BW 1345 (1980-91 Ford F150-350 & Bronco)
BW 1350 (1986-97 Ranger & Bronco II Electric Shift)
BW 1350 (1983-97 Ranger & Bronco II Mechanical Shift)
BW 1354 (1983-97 Ford Ranger, Bronco II, & Explorer Mechanical Shift)
BW 1356 (1987-96 Ford F150-350 Electric Shift)
BW 1356 (1987-96 Ford F150-350 & Bronco Mechanical Shift)
BW 1360 (Ford Motorhome)
BW 1370 (1989-91 Chevrolet Pickup)
BW 4401 (1991-97 GMC Pickup K30 Mechanical Shift)
BW 4404 (1997-Up Ford Explorer & Mountaineer w/ 5.0L & Full Time)
