| Item No. |
Part Number |
Name | Qty Per Axle | Price |
Buy |
|
|
110593
|
Basic Overhaul Kit (Contents Identified With *)*
| 1 | Log in to see
prices |
|
|
| A1 |
120924
|
Diff. Carrier & Bearing Caps
| 1 | Log in to see
prices |
|
|
|
106845
|
Bearing Kit (Contents Identified With)
| 1 | Log in to see
prices |
|
|
| A1 |
128107
|
Carrier Casting No. (Nss)
| | Log in to see
prices |
|
|
| A1 |
--
|
115690 Includes Items 2-4,9-10 120923,120924 include Items 2-4, 9-10, 35-37
| | Log in to see
prices |
|
|
| A2 |
127179
|
Bearing Cap Screw
| 4 | Log in to see
prices |
|
|
| A3 |
26772
|
Flat Washer
| 4 | Log in to see
prices |
|
|
| A4 |
90538
|
Lockwire
| 4 | Log in to see
prices |
|
|
| A5 |
14275
|
Bearing Adjuster Lock (Rh)
| 1 | Log in to see
prices |
|
|
| A6 |
90876
|
Cotter Pin (Rh)
| 1 | Log in to see
prices |
|
|
| A7 |
13377
|
Bearing Adjuster Lock (Lh)
| 1 | Log in to see
prices |
|
|
| A8 |
90873
|
Cotter Pin (Lh)
| 1 | Log in to see
prices |
|
|
| A9 |
7641
|
Carrier Cover Dowel Pin
| 2 | Log in to see
prices |
|
|
| A10 |
90325
|
Filler Plug
| 1 | Log in to see
prices |
|
|
| A11 |
31562
|
Diff. Bearing Adjuster (Rh)
| 1 | Log in to see
prices |
|
|
| A11 |
27842
|
Diff. Bearing Adjuster (Lh)
| 1 | Log in to see
prices |
|
|
| A12 |
KOY 563
|
Diff. Bearing Cup (Rh)*
| 1 | Log in to see
prices |
|
|
| A12 |
KOY 493
|
Diff. Bearing Cup (Lh)*
| 1 | Log in to see
prices |
|
|
| A13 |
6082
|
Diff. Bearing Cone (Rh)*
| 1 | Log in to see
prices |
|
|
| A13 |
KOY 497
|
Diff. Bearing Cone (Lh)*
| 1 | Log in to see
prices |
|
|
| A15 |
70745
|
Ring Gear Bolt & Nut Kit (5/8")
| 1 | Log in to see
prices |
|
|
| A15 |
70745QG
|
Bolt
| 16 | Log in to see
prices |
|
|
| A15 |
60600
|
Nut
| 16 | Log in to see
prices |
|
|
| A15 |
106397
|
Ratios 3.36-5.29
| 1 | Log in to see
prices |
|
|
| A15 |
124374
|
Ratios 5.57-7.17 Includes Items 16,17 & 110243 Adjuster
| 1 | Log in to see
prices |
|
|
| A16 |
210017
|
Diff. Case (Plain Half) (Nss)
| 1 | Log in to see
prices |
|
|
| A16 |
103865
|
Ratios 3.36-5.29
| | Log in to see
prices |
|
|
| A16 |
88677
|
Ratios 5.57-7.17
| | Log in to see
prices |
|
|
| A17 |
96271
|
Diff. Case Cap Screw
| 12 | Log in to see
prices |
|
|
| A17 |
98850
|
WHEEL DIFF. SIDE GEAR, PINION KIT Includes Items 18-22 Models: 34,340,341
| 1 | Log in to see
prices |
|
|
| A17 |
85358
|
38,380,381,402
| | Log in to see
prices |
|
|
| A17 |
98853
|
400,401,451
| | Log in to see
prices |
|
|
| A17 |
118748
|
Wheel Diff. Kit Less Side Gears Includes Items 19-22
| 1 | Log in to see
prices |
|
|
| A18 |
37072
|
Diff, Side Gear Models: 34, 340, 341
| 2 | Log in to see
prices |
|
|
| A18 |
37069
|
Diff, Side Gear Models: 38,380,381,402
| | Log in to see
prices |
|
|
| A18 |
85486
|
Diff, Side Gear Models: 400,401,451
| | Log in to see
prices |
|
|
| A19 |
27827QG
|
Side Gear Thrust Washer*
| 2 | Log in to see
prices |
|
|
| A20 |
104139
|
Side Pinion 104139 Replaces 37071
| 4 | Log in to see
prices |
|
|
| A21 |
27810QG
|
Side Pinion Thrust Washer*
| 4 | Log in to see
prices |
|
|
| A22 |
128003
|
Spider
| 1 | Log in to see
prices |
|
|
| A23 |
95205QG
|
Output Shaft Nut
| 1 | Log in to see
prices |
|
|
| A24 |
FUL 4327
|
Flat Washer*
| 1 | Log in to see
prices |
|
|
| A26 |
75336
|
3/4" (Cover 127874)
| | Log in to see
prices |
|
|
| A26 |
46583
|
Rear Bearing Retaining Washer Not Illustrated*
| 1 | Log in to see
prices |
|
|
| A27 |
127720
|
Output Shaft Oil Seal Note 9*
| 1 | Log in to see
prices |
|
|
| A28 |
45516
|
Bearing Snap Ring*
| 1 | Log in to see
prices |
|
|
| A29 |
46584
|
Output Shaft Bearing & Sleeve Assy
| | Log in to see
prices |
|
|
| A29 |
118789
|
Inner Bearing Race*
| 1 | Log in to see
prices |
|
|
| A29 |
118790
|
Outer Bearing Race*
| 1 | Log in to see
prices |
|
|
| A30 |
54254
|
Magnetic Filler Plug 3/4"
| 1 | Log in to see
prices |
|
|
| A31 |
98603
|
Output Shaft, Nut & Bushing Kit
| 1 | Log in to see
prices |
|
|
| A31 |
--
|
Includes Items 23, 32-33; 115123 Also Includes Items 38-39
| | Log in to see
prices |
|
|
| A32 |
48922QG
|
Output Shaft Bushing*
| 1 | Log in to see
prices |
|
|
| A33 |
46526QG
|
Output Shaft "O" Ring*
| 2 | Log in to see
prices |
|
|
| A34 |
85994QG
|
Side Gear Snap Ring*
| 2 | Log in to see
prices |
|
|
| A35 |
51232
|
Output Shaft Bearing Cup (Inner)*
| 1 | Log in to see
prices |
|
|
| A36 |
NTN 34274
|
Output Shaft Bearing Cone (Inner)*
| 1 | Log in to see
prices |
|
|
| A37 |
85436
|
Output Shaft Side Gear
| 1 | Log in to see
prices |
|
|
| A40 |
104509
|
Inter-Axle Diff. Assy W/O Lube Pump
| | Log in to see
prices |
|
|
| A40 |
104509
|
W/ Lube Pump Includes Items 41-47 Note 10
| | Log in to see
prices |
|
|
| A41 |
94810
|
Diff Case Kit W/O Lube Pump
| | Log in to see
prices |
|
|
| A41 |
94810
|
W/ Lube Pump
| | Log in to see
prices |
|
|
| A41 |
102621
|
Case Half (Nss) W/O Lube Pump
| 2 | Log in to see
prices |
|
|
| A41 |
102621
|
W/ Lube Pump
| | Log in to see
prices |
|
|
| A42 |
85438
|
Bolt
| 8 | Log in to see
prices |
|
|
| A43 |
57637
|
Nut
| 8 | Log in to see
prices |
|
|
| A43 |
96381
|
Diff Side Pinion & Spider Kit (Includes Items 44-47) W/O Lube Pump
| 1 | Log in to see
prices |
|
|
| A43 |
96381
|
W/ Lube Pump
| | Log in to see
prices |
|
|
| A44 |
95214
|
Side Pinion W/O Lube Pump
| 4 | Log in to see
prices |
|
|
| A44 |
95214
|
W/ Lube Pump
| | Log in to see
prices |
|
|
| A45 |
95215QG
|
Side Pinion Bushing W/O Lube Pump*
| 4 | Log in to see
prices |
|
|
| A45 |
95215QG
|
W/ Lube Pump*
| | Log in to see
prices |
|
|
| A46 |
85437QG
|
Side Pinion Thrust Wisher W/O Lube Pump*
| 4 | Log in to see
prices |
|
|
| A46 |
85437QG
|
W/ Lube Pump*
| | Log in to see
prices |
|
|
| A47 |
95216
|
Spider W/O Lube Pump
| | Log in to see
prices |
|
|
| A47 |
95216
|
W/ Lube Pump
| | Log in to see
prices |
|
|
| A48 |
85432
|
Helical Side Gear & Bushing Assy
| 1 | Log in to see
prices |
|
|
| A48 |
85431
|
Side Gear (Nss)
| | Log in to see
prices |
|
|
| A49 |
85991QG
|
Helical Side Gear Bushing*
| 2 | Log in to see
prices |
|
|
| A50 |
85997QG
|
Helical Side Gear Snap Ring*
| 1 | Log in to see
prices |
|
|
| A51 |
85429QG
|
Helical Side Gear Thrust Washer*
| 1 | Log in to see
prices |
|
|
| A52 |
45478QG
|
Helical Side Gear "D" Washer*
| 1 | Log in to see
prices |
|
|
| A53 |
128016
|
Lockout Sliding Clutch
| 1 | Log in to see
prices |
|
|
| A54 |
103283
|
Shaft (Nss) 16 Splines, 2.125" Dia.
| | Log in to see
prices |
|
|
| A54 |
106709
|
Models W/ Lube Pump
| 1 | Log in to see
prices |
|
|
| A54 |
102608
|
Shaft (Nss) 16 Splines, 2.125" Dia.
| | Log in to see
prices |
|
|
| A55 |
85425
|
Input Shaft Bearing Cone*
| 1 | Log in to see
prices |
|
|
| A56 |
85423
|
Input Bearing Cover, Cup & Seal Assy Includes Items 57 & 61 Models W/O Lube Pump
| 1 | Log in to see
prices |
|
|
| A56 |
85421
|
Cover (Nss)
| | Log in to see
prices |
|
|
| A56 |
102629
|
Models W/ Lube Pump
| 1 | Log in to see
prices |
|
|
| A56 |
102614
|
Cover (Nss)
| | Log in to see
prices |
|
|
| A57 |
85424
|
Input Bearing Cup*
| 1 | Log in to see
prices |
|
|
| A58 |
45498
|
Input Bearing Cover Shim .003"*
| AR | Log in to see
prices |
|
|
| A58 |
70709
|
Input Bearing Cover Shim .005"*
| | Log in to see
prices |
|
|
| A58 |
45499
|
Input Bearing Cover Shim .010"*
| | Log in to see
prices |
|
|
| A58 |
85406
|
Input Bearing Cover Shim .020"*
| | Log in to see
prices |
|
|
| A59 |
113324
|
Bearing Cover Cap Screw
| 5 | Log in to see
prices |
|
|
| A60 |
114465
|
Oil Seal & Shim Kit Includes Items 27,58,61,83 & Rtv Note 9
| 1 | Log in to see
prices |
|
|
| A61 |
127719
|
Oil Seal Note 9*
| 1 | Log in to see
prices |
|
|
| A61 |
85427
|
Input Bearing Spacer Not Illustrated
| 1 | Log in to see
prices |
|
|
| A63 |
95207QG
|
Input Shaft Nut
| 1 | Log in to see
prices |
|
|
| A64 |
85404
|
Flat Washer*
| 1 | Log in to see
prices |
|
|
| A65 |
45481
|
Models W/O Lube Pump
| 1 | Log in to see
prices |
|
|
| A65 |
102627
|
Models W/ Lube Pump Includes Item 66-67
| 1 | Log in to see
prices |
|
|
| A65 |
102606
|
Cover (Nss)
| | Log in to see
prices |
|
|
| A66 |
90325
|
Pipe Plug 1"
| 1 | Log in to see
prices |
|
|
| A67 |
9797
|
Expansion Plug Models W/ Lube Pump
| 1 | Log in to see
prices |
|
|
| A68 |
12063
|
Carrier Cover Cap Screw Models W/O Lube Pump (Long)
| 5 | Log in to see
prices |
|
|
| A68 |
90069
|
(Short)
| 4 | Log in to see
prices |
|
|
| A68 |
12063
|
Models W /Lube Pump (Long)
| 4 | Log in to see
prices |
|
|
| A68 |
90069
|
(Short)
| 4 | Log in to see
prices |
|
|
| A68 |
102605
|
(12 Pt)
| 1 | Log in to see
prices |
|
|
| A69 |
90417
|
Lockwasher
| 9 | Log in to see
prices |
|
|
| A70 |
102611
|
Magnetic Filler Screen Models W/ Lube Pump
| 1 | Log in to see
prices |
|
|
| A71 |
106368
|
Lube Pump Replacement Kit Models W/ Lube Pump Includes Items 72-77
| 1 | Log in to see
prices |
|
|
| A72 |
106368QG
|
Pump Drive Gear
| 1 | Log in to see
prices |
|
|
| A73 |
63028
|
Drive Gear Locknut
| 1 | Log in to see
prices |
|
|
| A73 |
81471
|
Drive Gear Woodruff Key Not Illustrated
| 1 | Log in to see
prices |
|
|
| A74 |
102620
|
Cover "O" Ring*
| 1 | Log in to see
prices |
|
|
| A75 |
102617
|
Cover Dowel Pin
| 2 | Log in to see
prices |
|
|
| A76 |
102618
|
Cover Cap Screw
| 4 | Log in to see
prices |
|
|
| A77 |
90419
|
Lockwasher
| 4 | Log in to see
prices |
|
|
| A78 |
830398
|
Pinion Pilot Bearing*
| 1 | Log in to see
prices |
|
|
| A79 |
KOY 72218C
|
Pinion Bearing Cone (Inner)*
| 1 | Log in to see
prices |
|
|
| A79 |
NTN 72200C
|
Pinion Bearing Cone (Outer)*
| 1 | Log in to see
prices |
|
|
| A81 |
107322
|
Pinion Bearing Cage & Cup Assy Includes Item 82 Ratios 3.55 & 3.70
| 1 | Log in to see
prices |
|
|
| A81 |
107321
|
Cage (Nss)
| | Log in to see
prices |
|
|
| A81 |
107324
|
Ratios 3.08, 3.25, 3.36, 3.90-7.17
| | Log in to see
prices |
|
|
| A81 |
107323
|
Cage (Nss)
| | Log in to see
prices |
|
|
| A82 |
KOY 72487
|
Pinion Bearing Cup (Inner)*
| 1 | Log in to see
prices |
|
|
| A82 |
KOY 72487
|
Pinion Bearing Cup (Outer)*
| 1 | Log in to see
prices |
|
|
| A83 |
45461
|
Pinion Bearing Cage Shim .003"*
| AR | Log in to see
prices |
|
|
|
62829
|
Pinion Bearing Cage Shim .005"*
| | Log in to see
prices |
|
|
| A83 |
62829
|
Pinion Bearing Cage Shim .005"*
| | Log in to see
prices |
|
|
| A83 |
45462
|
Pinion Bearing Cage Shim .010"*
| | Log in to see
prices |
|
|
| A83 |
61830
|
Pinion Bearing Cage Shim 0.20"*
| | Log in to see
prices |
|
|
| A83 |
45463
|
Pinion Bearing Cage Shim .030"*
| | Log in to see
prices |
|
|
| A84 |
62158
|
Bearing Cage Cap Screw
| 6 | Log in to see
prices |
|
|
| A85 |
37207
|
Lockwasher
| 6 | Log in to see
prices |
|
|
| A86 |
46977
|
Ratios 3.70
| | Log in to see
prices |
|
|
| A86 |
74991
|
Other Ratios
| | Log in to see
prices |
|
|
| A88 |
95206QG
|
Slotted Nut
| 1 | Log in to see
prices |
|
|
| A90 |
102613
|
Shift Fork & Push Rod Assy Models W/ Lube Pump
| 1 | Log in to see
prices |
|
|
| A90 |
45859
|
Models W/O Lube Pump
| 1 | Log in to see
prices |
|
|
| A90 |
RTV 1473
|
Gasket Compound*
| AR | Log in to see
prices |
|
|
 |
.JPG "Differential Lockout (Current Production)"){kind=small}
Differential Lockout (Current Production).JPG "Differential Lockout (Non-Current Production)"){kind=small}
Differential Lockout (Non-Current Production)
