| Item No. |
Part Number |
Name | Description | Model | Qty | Price |
Buy |
|
| A67 |
S-268-2
|
Capscrew-Input Shaft Rear Bearing Cage
| 0.38"-16, 1.00" long, grade 8. | All | 4 | Log in to see
prices |
|
|
| A68 |
1229-K-1597
|
Washer-Input Shaft Rear Brg.
| 0.75" O.D., 0.41" I.D., 0.09" thick. | A1 | 4 | Log in to see
prices |
|
|
| A68 |
WA-16
|
Cage
| 0.67" O.D., 0.32" I.D., 0.09" thick. | All others | 4 | Log in to see
prices |
|
|
| A69 |
3866-R-746
|
Cage-Input Shaft Rear Brg.
| 4 holes on 4.25" bolt circle, closed end, 1.31" long. | All | 1 | Log in to see
prices |
|
|
| A70 |
2297-Z-6656
|
Gasket-Input Shaft Rear Cap
| Silicone gasket, use as required.* | All | | Log in to see
prices |
|
|
| A71 |
1828-P-94
|
Bearing-Input Shaft Rear
| Ball bearing, with shield, 2.44" O.D., 1.18" I.D., 0.63" wide | All | 1 | Log in to see
prices |
|
|
| A71A |
332
|
Cup-Input Shaft Rear
| Not used on 221 models in this book | | 1 | Log in to see
prices |
|
|
| A71B |
339
|
Cone-Input Shaft Rear
| Not used on 221 models in this book. | | 1 | Log in to see
prices |
|
|
| A72 |
1829-X-726
|
Washer-Input Shaft Rear Brg.
| 2.00" O.D., 1.20" I.D., 0.12" thick. | All | 1 | Log in to see
prices |
|
|
| A73 |
1825-W-205
|
Bushing-Direct Drive Gear
| 1.50" O.D., 1.36" I.D., 1.28" wide, split, 4 holes and 8 grooves, included in item 74. Not sold separately. Sold with direct drive gear only | All | 1 | Log in to see
prices |
|
|
| A74 |
A-3892-U-1711
|
Gear Assy.-Direct Drive (1.796-1)
| 33T, spur, 4.98" O.D., 20T spline, 1.49" bushing bore, includes item 73. No longer available. | All | 1 | Log in to see
prices |
|
|
| A74 |
A-3892-X-1714
|
Gear Assy.-Direct Drive (1.94-1)
| 33T, spur, 4.98" O.D., 19T spline, 1.49" bushing bore, includes item 73. | All | 1 | Log in to see
prices |
|
|
| A75 |
1829-Y-727
|
Washer-Direct Drive Gear
| 2.00" O.D., 1.41" I.D., 0.12" thick. | All | 1 | Log in to see
prices |
|
|
| A76 |
3892-V-1712
|
Gear-Low Speed Sliding (1.796-1)
| 20T, spur, 3.68" O.D., 1.63"-10 spline, with shift groove, no longer available. | All | 1 | Log in to see
prices |
|
|
| A76 |
3892-Y-1715
|
Gear-Low Speed Sliding (1.94-1)
| 19T, spur, 3.51" O.D., 1.63"-10 spline. | | 1 | Log in to see
prices |
|
|
| A77 |
3880-P-744
|
Shaft-Input
| 9.09" long with threaded end | A1, M, M6, M7 | 1 | Log in to see
prices |
|
|
| A77 |
3880-J-1128
|
Shaft-Input
| 8.14" long, no threads. | All others | 1 | Log in to see
prices |
|
|
| A78 |
1844-C-809
|
Spacer-Input Shaft
| Not used on 221 models in this book | | 1 | Log in to see
prices |
|
|
| A79 |
1828-L-142
|
Bearing-Input Shaft Front
| Ball bearing with shield, 2.83" O.D., 1.38" I.D., 0.67" long. | All | 1 | Log in to see
prices |
|
|
| A79A |
357
|
Cone-Input Shaft Front
| Not used on 221 models in this book. | | 1 | Log in to see
prices |
|
|
| A79B |
353
|
Cup-Input Shaft Front
| Not used on 221 models in this book. | | 1 | Log in to see
prices |
|
|
| A79C |
1229-F-3048
|
Washer-Input Shaft Front
| Not used on 221 models in this book. | | 1 | Log in to see
prices |
|
|
| A80 |
2803-S-1865
|
Shim-Input Shaft Front Brg. Cap
| .003", use as required, 3 holes. | A1, M, M6 M7 | 1,1 | Log in to see
prices |
|
|
| A80 |
2803-T-1866
|
Shim-Input Shaft Front Brg. Cap
| .005", use as required, 3 holes. | A1, M, M6 M7 | 1 | Log in to see
prices |
|
|
| A80 |
2803-U-1867
|
Shim-Input Shaft Front Brg. Cap
| .010", use as required, 3 holes | A1, M, M6, M7 | 3 | Log in to see
prices |
|
|
| A80 |
2803-D-2162
|
Shim-Input Shaft Front Brg. Cap
| .003", use as required, 9 holes | All others | 2 | Log in to see
prices |
|
|
| A80 |
2803-E-2163
|
Shim-Input Shaft Front Brg. Cap
| .005", use as required, 9 holes. | All others | 3 | Log in to see
prices |
|
|
| A80 |
2803-F-2164
|
Shim-Input Shaft Front Brg. Cap
| .010", use as required, 9 holes. | All others | 2 | Log in to see
prices |
|
|
| A81 |
A3-3866-U-749
|
Cap Assy.-Input Shaft Front Brg.
| 3866-J-1258 cast, 3 holes on 3.75" bolt circle, open end, includes item 86. Replaces A-3866-U-749 with oil seal A-1805-N-378 which replaced A1-3866-U-749 with oil seal A-1805-W-413. | A1, M, M6, M7 | 1 | Log in to see
prices |
|
|
| A81 |
A-3866-U-1113
|
Cap Assy.-Input Shaft Front Brg.
| Shipping cover only. | All others | 1 | Log in to see
prices |
|
|
| A82 |
P-42
|
Plug-Input Shaft Front Brg. Cap
| Hex socket-female, 0.125"-27 thread. | | 1 | Log in to see
prices |
|
|
| A83 |
1229-K-1597
|
Washer-Input Shaft Front Brg. Cap
| 0.75" O.D., 0.41" I.D., 0.09" thick | A1 | 3 | Log in to see
prices |
|
|
| A83 |
WA-16
|
Washer-Input Shaft Front Brg. Cap
| 0.67" O.D., 0.39" I.D., 0.09" thick. | All others | 3 | Log in to see
prices |
|
|
| A84 |
S-2612-2
|
Capscrew-Front Brg. Cap
| 0.38"-16, 1.50" long, grade 8. Replaces S-2611-1 which is 1.38" long. | All | 3 | Log in to see
prices |
|
|
| A84 |
S-268-2
|
Capscrew-Input Shaft Front Brg.
| 0.38"-16, 1.00" long, grade 8. | All others | 3 | Log in to see
prices |
|
|
| A85 |
PW-226
|
Plug-Input Shaft Shipping Cover
| 1.63" diameter, 0.08" thick. Part no longer available. | N4, N7 | 1 | Log in to see
prices |
|
|
| A86 |
A-1805-E-447
|
Oil Seal-Input Shaft Front Brg.Cap
| 2.50" O.D., 1.75" I.D., 0.77" wide, double seal lip, and case, included in item 81. | A1 | 1 | Log in to see
prices |
|
|
| A87 |
1829-V-100
|
Washer-Input Shaft
| Not used on 221 models in this book. | | 1 | Log in to see
prices |
|
|
| A88 |
1827-H-242
|
Nut-Input Shaft
| 0.88"-14, 5.00" height, slotted. | A1, M, M6, M7 | 1 | Log in to see
prices |
|
|
| A89 |
K-2412
|
Cotter-Input Shaft Nut
| 0.13" diameter, 1.50" long. | A1, M, M6, M7 | 1 | Log in to see
prices |
|
|
| A90 |
2847-P-640
|
Deflector-Input Yoke
| Hook shape (cross section), 2.75" O.D., 1.76" I.D., 0.50" wide, included in item 91. | M, M6, M7 | 1 | Log in to see
prices |
|
|
| A91 |
A1-3897-A-1431
|
Flange/Yoke-Input
| 1310 series, 3.69" long, includes item 90, 1.25"-10T spline | M, M6, M7 | 1 | Log in to see
prices |
|
|
| A92 |
A1-3897-A-1431
|
Flange/Yoke-Rear Output
| 1310 series, 3.69" long, includes item 93, 1.25"-10 spline. | M, M6 | 1 | Log in to see
prices |
|
|
| A92 |
A1-3897-Q-1655
|
Flange/Yoke-Rear Output
| 1310 series, 3.53" long, 1.25"-10T spline, includes item 93. | M7, N4, N7 | 1 | Log in to see
prices |
|
|
| A93 |
2847-P-640
|
Deflector-Rear Output Yoke
| Included in item 92. | M, M6, M7, N4, N7 | 1 | Log in to see
prices |
|
|
| A94 |
1827-H-242
|
Nut-Rear Output Shaft
| 1.81" O.D., 1.03" I.D., 0.25" thick. | All | 1 | Log in to see
prices |
|
|
| A95 |
1229-E-1331
|
Washer-Rear Output Shaft Nut
| Not used on 221 models in this book | | 1 | Log in to see
prices |
|
|
| A96 |
A-1805-E-447
|
Oil Seal-Rear Output Shaft
| 2.50" O.D., 1.75" I.D., 0.77" wide, double seal lip and case, included in item 97. | All | 1 | Log in to see
prices |
|
|
| A97 |
A-3866-Y-805
|
Cap Assy.-Rear Output Shaft
| 4 holes on 3.88" bolt circle, includes item 96 and 98. | All | 1 | Log in to see
prices |
|
|
| A98 |
1199-M-1105
|
Bushing-Speedometer Driven Gear
| Flanged, 0.44" flange O.D., 0.03" flange width, 0.31" O.D., 0.25" I.D. 0.34" wide, | All | 1 | Log in to see
prices |
|
|
| A99 |
1898-N-846
|
Gear-Speedometer Driven
| 15T, R.H., helical, 0.74" O.D. | A1 | 1 | Log in to see
prices |
|
|
| A100 |
1898-U-671
|
Sleeve-Speedometer Driven Gear
| 0.38" thru-hole, 1.26" long, 0.81"-20 UNEF 2A threads one end, 0.88"-18 NS 2A threads other end. | A1 | 1 | Log in to see
prices |
|
|
| A101 |
A-1850-R-18
|
Plug-Speedometer Hole
| Not used on 221 models in this book. | | 1 | Log in to see
prices |
|
|
| A102 |
K-2412
|
Cotter-Rear Output Shaft Nut
| 0.13" diameter, 1.50" long | A1, M, M6, M7 | 1 | Log in to see
prices |
|
|
| A102 |
K-2410
|
Cotter-Rear Output Shaft Nut
| 0.13" diameter, 1.25" long. | All others | 1 | Log in to see
prices |
|
|
| A103 |
S-268-2
|
Capscrew-Rear Output Cap
| 0.38"-16, 1.00" long, grade 8. | A1, M, M6, M7 | 2 | Log in to see
prices |
|
|
| A103 |
S-2614-2
|
Capscrew-Rear Output Cap
| 0.38"-16, 1.75" long, grade 8. | A1, M, M6, M7 | 1 | Log in to see
prices |
|
|
| A103 |
10-X-665
|
Capscrew-Rear Output Cap
| 0.38"-16, 1.00" long, flat head | A1, M, M6, M7 | 1 | Log in to see
prices |
|
|
| A103 |
S-269-1
|
Capscrew-Rear Output Cap
| 0.38"-16, 1.12"long, grade 8. | N4, N7 | 2 | Log in to see
prices |
|
|
| A103 |
S-2614-2
|
Capscrew-Rear Output Cap
| 0.38"-16, 1.75" long, grade 8. | N4, N7 | 1 | Log in to see
prices |
|
|
| A103 |
10-X-665
|
Capscrew-Rear Output Cap
| 0.38"-16, 1.00" long, flat head. | N4, N7 | 1 | Log in to see
prices |
|
|
| A104 |
1229-K-1597
|
Washer-Rear Output Cap
| 0.75" O.D., 0.41" I.D., 0.09" thick. | A1 | 3 | Log in to see
prices |
|
|
| A104 |
1229-E-525
|
Washer-Rear Output Cap
| 0.78" O.D., 0.39" I.D., external teeth. | A1 | 1 | Log in to see
prices |
|
|
| A104 |
WA-16
|
Washer-Rear Output Cap
| 0.67" O.D., 0.39" I.D., 0.09" thick. | All others | 3 | Log in to see
prices |
|
|
| A104 |
1229-E-525
|
Washer-Rear Output Cap
| 0.78" O.D., 0.39" I.D., external teeth. | All others | 1 | Log in to see
prices |
|
|
| A105 |
A-1199-C-1043
|
Breather-Rear Output Shaft Cap
| Not used on 221 models in this book. | | 1 | Log in to see
prices |
|
|
| A106 |
2297-Z-6656
|
Gasket-Rear Output Cap
| Silicone gasket, use as required.* | All | 1 | Log in to see
prices |
|
|
| A107 |
1898-Q-849
|
Gear-Speed Driven
| 4T, R.H., Helical, 1.78" O.D. | A1 | 1 | Log in to see
prices |
|
|
| A107 |
1898-P-848
|
Gear-Speed Driven
| 4T, R.H., Helical, 1.88" O.D. | All others | 1 | Log in to see
prices |
|
|
| A109 |
15245
|
Cup-Rear Output Shaft Rear Brg.
| 2.44" O.D. | All | 1 | Log in to see
prices |
|
|
| A110 |
15126
|
Cone-Rear Output Shaft Rear Brg.
| 1.25" bore. | All | 1 | Log in to see
prices |
|
|
| A111 |
3892-R-1708
|
Gear-Rear Output Shaft
| 33T, L.H., Helical, 4.97" O.D., 1.63"-10T spline. | All | 1 | Log in to see
prices |
|
|
| A112 |
3880-Q-745
|
Shaft-Rear Output
| 9.06" long, threaded one end, 1.25"-10 spline, 1.63"-10T spline. | All | 1 | Log in to see
prices |
|
|
| A113 |
15126
|
Cone-Rear Output Shaft Fwd. Brg.
| 1.25" bore. | All | 1 | Log in to see
prices |
|
|
| A114 |
15245
|
Cup-Rear Output Shaft Fwd. Brg.
| 2.44" O.D | All | 1 | Log in to see
prices |
|
|
| A115 |
2803-V-1868
|
Shim-Rear Output Forward Brg. Cap
| .003", use as required, 3 holes. | A1, M | 1 | Log in to see
prices |
|
|
| A115 |
2803-W-1869
|
Shim-Rear Output Forward Brg. Cap
| .005", use as required, 3 holes. | A1, M | 1 | Log in to see
prices |
|
|
| A115 |
2803-X-1870
|
Shim-Rear Output Forward Brg. Cap
| .010", use as required, 3 holes. | A1, M | 3 | Log in to see
prices |
|
|
| A115 |
2803-V-1868
|
Shim-Rear Output Forward Brg. Cap
| .003", use as required, 3 holes. | M6, M7 | 2 | Log in to see
prices |
|
|
| A115 |
2803-W-1869
|
Shim-Rear Output Forward Brg. Cap
| .005", use as required, 3 holes. | M6, M7 | 3 | Log in to see
prices |
|
|
| A115 |
2803-X-1870
|
Shim-Rear Output Forward Brg.Cap
| .010", use as required, 3 holes. | M6, M7 | 2 | Log in to see
prices |
|
|
| A115 |
2803-G-2165
|
Shim-Rear Output Forward Brg.Cap
| .003", use as required, 4 holes. | All others | 2 | Log in to see
prices |
|
|
| A115 |
2803-H-2166
|
Shim-Rear Output Forward Brg.Cap
| .005", use as required, 4 holes | All others | 3 | Log in to see
prices |
|
|
| A115 |
2803-J-2168
|
Shim-Rear Output Forward Brg.Cap
| .010", use as required, 4 holes. | All others | 2 | Log in to see
prices |
|
|
| A116 |
3866-T-748
|
Cap-Rear Output Forward Cap
| Stamping, 3 holes on 3.25" bolt circle, closed end | All | 1 | Log in to see
prices |
|
|
| A117 |
1229-K-1597
|
Washer-Rear Output Forward Cap
| 0.75" O.D., 0.41" I.D., 0.09" thick. | A1 | 3 | Log in to see
prices |
|
|
| A117 |
WA-16
|
Washer-Rear Output Forward Cap
| 0.67" O.D., 0.39" I.D., 0.09" thick. | All others | 3 | Log in to see
prices |
|
|
| A118 |
S-267-2
|
Capscrew-Rear Output Fwd. Cap
| 0.38"-16", 0.88" long, grade 8. | All | 3 | Log in to see
prices |
|
|
| A119 |
S-267-2
|
Capscrew-Idler Shaft Rear Cap
| 0.38"-16", 0.88" long, grade 8. | All | 3 | Log in to see
prices |
|
|
| A120 |
1229-K-1597
|
Washer-Idler Shaft Rear Cap
| 0.75" O.D., 0.41" I.D., 0.09" thick. | A1 | 3 | Log in to see
prices |
|
|
| A120 |
WA-16
|
Washer-Idler Shaft Rear Cap
| 0.67" O.D., 0.39" I.D., 0.09" thick. | All others | 3 | Log in to see
prices |
|
|
| A121 |
3866-T-748
|
Cap-Idler Shaft Rear
| Stamping, 3 holes on 3.25" bolt circle, closed end. | All | 1 | Log in to see
prices |
|
|
| A122 |
2297-Z-6656
|
Gasket-Idler Shaft Rear Cap
| Silicone gasket, use as required.* | All | | Log in to see
prices |
|
|
| A123 |
1854-E-187
|
Snap Ring-Idler Shaft
| Not used on 221 models in this book. | | 1 | Log in to see
prices |
|
|
| A124 |
15245
|
Cup-Idler Shaft Rear Brg.
| 2.44" bore. | All | 1 | Log in to see
prices |
|
|
| A125 |
15126
|
Cone-Idler Shaft Rear Brg.
| 1.25" bore | All | 1 | Log in to see
prices |
|
|
| A126 |
3892-W-1713
|
Gear-Idler Shaft
| 34T, R.H., Helical, 5.12" O.D., 1.63"-10T spline. | All | 1 | Log in to see
prices |
|
|
| A127 |
1844-D-498
|
Spacer-Idler Shaft Gear
| 2.13" O.D., 1.69" I.D., 1.16" wide. | All | 1 | Log in to see
prices |
|
|
| A128 |
3892-W-1713
|
Gear-Low Speed (1.796-1)
| 37T, spur, 6.44" O.D., 1.63"-10T spline. | All | 1 | Log in to see
prices |
|
|
| A128 |
3892-Z-1716
|
Gear-Low Speed (1.94-1)
| 38T, spur, 6.61" O.D., 1.63"-10T spline. | All | 1 | Log in to see
prices |
|
|
| A129 |
3880-N-742
|
Shaft-Idler
| 5.38" long, 1.25" bearing diameter both ends, 1.63"-10T spline. | All | 1 | Log in to see
prices |
|
|
| A130 |
2476
|
Cone Idler Shaft Front Brg.
| 1.25" bore. | All | 1 | Log in to see
prices |
|
|
| A131 |
2420
|
Cup-Idler Shaft Front Brg.
| 2.69" O.D. | All | 1 | Log in to see
prices |
|
|
| A132 |
1829-H-788
|
Washer-Idler Shaft Brg.
| Not used on 221 models in this book. | | 1 | Log in to see
prices |
|
|
| A133 |
10-X-1292
|
Capscrew-Idler Shaft Brg.Washer
| Not used on 221 models in this book. | | 1 | Log in to see
prices |
|
|
| A134 |
LW-163
|
Lockwire-Idler Shaft Brg. Washer
| Not used on 221 models in this book. | | 1 | Log in to see
prices |
|
|
| A135 |
2803-V-1868
|
Shim-Idler Shaft Front Brg. Cap
| .003", use as required, 3 holes. | A1, M | 1 | Log in to see
prices |
|
|
| A135 |
2803-W-1869
|
Shim-Idler Shaft Front Brg. Cap
| .005", use as required, 3 holes | A1, M | 1 | Log in to see
prices |
|
|
| A135 |
2803-X-1870
|
Shim-Idler Shaft Front Brg. Cap
| .010", use as required, 3 holes. | A1, M | 3 | Log in to see
prices |
|
|
| A135 |
2803-V-1868
|
Shim-Idler Shaft Front Brg. Cap
| .003", use as required, 3 holes. | All others | 2 | Log in to see
prices |
|
|
| A135 |
2803-W-1869
|
Shim-Idler Shaft Front Brg. Cap
| .005", use as required, 3 holes. | All others | 3 | Log in to see
prices |
|
|
| A135 |
2803-X-1870
|
Shim-Idler Shaft Front Brg. Cap
| .010", use as required, 3 holes. | All others | 2 | Log in to see
prices |
|
|
| A136 |
3866-T-748
|
Cap-Idler Shaft Front Brg.
| Stamping, 3 holes on 3.25" bolt circle, closed end. | All | 1 | Log in to see
prices |
|
|
| A137 |
1229-K-1597
|
Washer-Idler Shaft Front Brg.
| 0.75" O.D., 0.41" I.D., 0.09" thick. | A1 | 3 | Log in to see
prices |
|
|
| A137 |
WA-16
|
Washer-Idler Shaft Front Brg.
| 0.67" O.D., 0.39" I.D., 0.09" thick. | All others | 3 | Log in to see
prices |
|
|
| A138 |
S-267-2
|
Capscrew-Idler Shaft Front Brg.
| 0.38"-16, 0.88" long, grade 8. | All | 3 | Log in to see
prices |
|
|
| A139 |
K-2412
|
Cotter-Output Shaft Nut
| 0.13" diameter, 1.50" long. | All | 1 | Log in to see
prices |
|
|
| A140 |
1827-H-242
|
Nut-Output Shaft
| 0.88"-14, 0.50" high, slotted. | A1, M, M6, M7 | 1 | Log in to see
prices |
|
|
| A140 |
N-512-1
|
Nut-Output Shaft
| 0.75"-16, slotted, grade 8. | All others | 1 | Log in to see
prices |
|
|
| A141 |
1229-V-1556
|
Washer-Output Shaft
| 1.38" O.D., 0.78" I.D., 0.12" thick | N4, N7 | 1 | Log in to see
prices |
|
|
| A142 |
10-X-830
|
Capscrew-Oil Catcher
| Not used on 221 models in this book. | | 1 | Log in to see
prices |
|
|
| A143 |
1229-K-1597
|
Washer-Front Brg. Cap
| Not used on 221 models in this book | | 1 | Log in to see
prices |
|
|
| A144 |
A1-3897-A-1431
|
Flange/Yoke-Front Output
| 1310 series, 3.69" long, 1.25"-10T spline, includes item 145 (2847-P-640). | M, M6, M7 | 1 | Log in to see
prices |
|
|
| A144 |
A-3897-C-2811
|
Flange/Yoke-Front Output
| 1310 yoke, 3.38" long, 1.25"-10T spline, includes item 145 (2847-K-791). | N4 | 1 | Log in to see
prices |
|
|
| A144 |
A-3897-D-3072
|
Flange/Yoke-Front Output
| Same as C-2811 except undercut versus radius on deflector seat, includes item 145 (2847-K-791). | N7 | 1 | Log in to see
prices |
|
|
| A145 |
2847-P-640
|
Deflector-Front Output Yoke
| Hook shape (cross section), 2.75" O.D., 1.76" I.D., 0.50" wide, included in item 144. | M, M6, M7 | 1 | Log in to see
prices |
|
|
| A145 |
2847-K-791
|
Deflector-Front Output Yoke
| "S" shape (cross section), 2.75" O.D., 1.78" I.D., 0.50" wide, included in item 144. Part no longer available. | N4, N7 | 1 | Log in to see
prices |
|
|
| A146 |
S-2612-2
|
Capscrew-Front Brg. Cap
| 0.38"-16, 1.50" long, grade 8. Replaces S-2611-1 which is 1.38" long. | All | 3 | Log in to see
prices |
|
|
| A147 |
1229-K-1597
|
Washer-Front Brg. Cap
| 0.75" O.D., 0.41" I.D., 0.09" thick. | A1 | 1 | Log in to see
prices |
|
|
| A147 |
WA-16
|
Washer-Front Brg. Cap
| 0.67" O.D., 0.39" I.D., 0.09" thick | All others | 3 | Log in to see
prices |
|
|
| A148 |
A-1805-E-447
|
Oil Seal-Output Shaft Front
| 2.50" O.D., 1.75" I.D., 0.77" wide, double seal lip and case, included in item 149. | All | 1 | Log in to see
prices |
|
|
| A149 |
A3-3866-U-749
|
Cap Assy.-Output Shaft Front
| 3 holes on 3.75" bolt circle, open end, includes item 148. | All | 1 | Log in to see
prices |
|
|
| A150 |
2297-Z-6656
|
Gasket-Output Shaft Front Cap
| Silicone gasket, use as required.* | All | | Log in to see
prices |
|
|
| A151 |
1228-V-308
|
Bearing-Output Shaft Front
| Ball bearing, with snap ring, 2.83" O.D., 1.38" bore, 0.67" wide. | All | 1 | Log in to see
prices |
|
|
| A152 |
2847-Q-849
|
Oil Catcher-Output Shaft
| Not used on 221 models in this book. | | 1 | Log in to see
prices |
|
|
| A153 |
WA-36
|
Washer-Oil Catcher
| Not used on 221 models in this book. | | 1 | Log in to see
prices |
|
|
| A154 |
K-236
|
Pin-Oil Catcher
| Not used on 221 models in this book. | | 1 | Log in to see
prices |
|
|
| A155 |
3880-R-746
|
Shaft-Front Output
| 9.50" long, 3.34" from threaded end to M7 1.70" diameter. Replaces A-3880-R-746 which has snap ring and groove. | A1, M, M6 , M7 | 1 | Log in to see
prices |
|
|
| A155 |
3880-T-1112
|
Shaft-Front Output
| 9.69" long, 3.53" from 0.75"-16, threaded end to 1.75" diameter. | All others | 1 | Log in to see
prices |
|
|
| A156 |
1854-P-146
|
Snap Ring-Front Output Shaft
| Fits over 1.75" diameter shaft. Part no longer available. | N4, N7 | 1 | Log in to see
prices |
|
|
| A157 |
3892-T-1710
|
Clutch-Front Output Sliding
| 19T, spur, 2.57" O.D., 1.63"-10T spline, with shift groove | All | 1 | Log in to see
prices |
|
|
| A158 |
3892-S-1709
|
Gear-Front Output Shaft
| 33T, L.H., Helical, 4.97" O.D., on shaft with 16T spline, 1.77" O.D. | All | 1 | Log in to see
prices |
|
|
| A159 |
1828-F-110
|
Bearing-Front Output Shaft Rear
| Ball bearing, with snap ring, 3.35" O.D., 1.77" I.D., 0.75" wide. | All | 1 | Log in to see
prices |
|
|
| A160 |
A-1205-Z-1768
|
Oil Seal-Front Output Shaft Rear
| 2.88" O.D., 2.19" I.D., included in item 163. | A1 | 1 | Log in to see
prices |
|
|
| A160 |
A-1805-E-447
|
Oil Seal-Front Output Shaft Rear
| 2.50" O.D., 1.75" I.D., 0.77" wide, double seal lip, and case, with spring. | M, M6, M7 | 1 | Log in to see
prices |
|
|
| A161 |
1844-G-501
|
Spacer-Front Output Shaft
| 2.13" O.D., 1.81" I.D., 1.38" wide. Part no longer available. | N4, N7 | 1 | Log in to see
prices |
|
|
| A162 |
2297-Z-6656
|
Gasket-Front Output Rear Cap
| Silicone gasket, use as required.* | All | | Log in to see
prices |
|
|
| A163 |
A1-3866-S-747
|
Cap Assy.-Front Output Shaft
| 3866-H-1256 cast, internal brake mounting, rear 4 holes on 4.25" bolt circle, 4 threaded holes on 3.75" bolt circle, includes item 160 (A-1205-Z-1768). No longer available. | A1 | 1 | Log in to see
prices |
|
|
| A164 |
1229-K-1597
|
Washer-Front Output Shaft Rear Cap
| 0.75" O.D., 0.41" I.D., 0.09" thick. | A1 | 4 | Log in to see
prices |
|
|
| A164 |
WA-16
|
Washer-Front Output Shaft Rear Cap
| 0.67" O.D., 0.39" I.D., 0.09" thick. | All others | 4 | Log in to see
prices |
|
|
| A165 |
S-268-2
|
Capscrew-Front Output Shaft Rear Cap
| 0.38"-16, 1.00" long, grade 8. | A1, N4, N7 | 4 | Log in to see
prices |
|
|
| A165 |
S-269-1
|
Capscrew-Front Output Shaft Rear Cap
| 0.38"-16, 1.12" long, grade 8. | All others | 4 | Log in to see
prices |
|
|
| A166 |
4-X-840
|
Stud-Rear Output Shaft
| Not used on 221 model in this book. | | 1 | Log in to see
prices |
|
|
| A167 |
N-16-1
|
Nut-Rear Output Shaft
| Not used on 221 model in this book | | 1 | Log in to see
prices |
|
|
| A168 |
PW-221
|
Expansion Plug-Front Output Shaft
| 31" O.D., 0.08" thick. | A1 | 1 | Log in to see
prices |
|
|
| A169 |
3897-F-1332
|
Hub-Brake
| Not used on 221 model in this book. | | 1 | Log in to see
prices |
|
|
| A170 |
1854-P-146
|
Snap Ring-Brake Hub
| 1.63" assembled, 0.09" thick. Part no longer available. | A1, M, M6, M7 | 1 | Log in to see
prices |
|
|
| A171 |
PW-221
|
171 Expansion Plug-Brake Hub
| 1.31" O.D., 0.08" thick. | A1 | 1 | Log in to see
prices |
|
|
| A188 |
3875-B-444
|
Case-Transfer
| 3875-A-443 rough part, less interlock, A, D, E, and F mounting bosses. | A1 | 1 | Log in to see
prices |
|
|
| A188 |
3875-W-491
|
Case-Transfer
| 5875-L-506 rough part, with interlock, C, D, E, and F mounting bosses. | M | 1 | Log in to see
prices |
|
|
| A188 |
3875-L-558
|
Case-Transfer
| 5875-S-513 rough part, with interlock, B, E, and F mounting bosses. | M6, M7 | 1 | Log in to see
prices |
|
|
| A188 |
3875-M-793
|
Case-Transfer
| 5875-L-792 rough part, with interlock, D (modified), E and F mounting bosses. | N4, N7 | 1 | Log in to see
prices |
|
|
| A189 |
1199-K-1493
|
Name Plate
| Not used on 221 models in this book. | | 1 | Log in to see
prices |
|
|
| A190 |
9-X-16
|
Screw-Name Plate
| Not used on 221 models in this book. | | 2 | Log in to see
prices |
|
|
| A191 |
PW-216
|
Expansion Plug-Shift Shaft All
| 1.00" O.D., 0.08" thick. | All | 1 | Log in to see
prices |
|
|
| A192 |
P-24
|
Plug-Oil Drain
| Female, non-magnetic, 0.25"-18 thread. | N4, N7 | 1 | Log in to see
prices |
|
|
| A193 |
1850-X-76
|
Expansion Plug-Shift Shaft
| 0.06" thick, 1.00" long. | All | 1 | Log in to see
prices |
|
|
| A194 |
P-112
|
Plug-Oil Drain
| Male, square head, 0.75"-14 thread. | All | 1 | Log in to see
prices |
|
|
| A195 |
P-112
|
Plug-oil level
| Male, square head, 0.75"-14 thread | All | 1 | Log in to see
prices |
|
|
| A196 |
1898-X-856
|
Oil Catcher-Input
| Not used on 221 models in this book. | | 1 | Log in to see
prices |
|
|
| A197 |
P-112
|
Plug-Oil High Level
| Not used on 221 models in this book. | | 1 | Log in to see
prices |
|
|
| A198 |
1898-X-258
|
Elbow-High Oil Level
| Not used on 221 models in this book. | | 1 | Log in to see
prices |
|
|
| A199 |
P-112
|
Plug-Oil Level
| Not used on 221 models in this book. | | 1 | Log in to see
prices |
|
|
| A200 |
A-1205-N-1132
|
Oil Seal-Shift Shaft
| 1.25" O.D., 0.75" I.D., single lip and dirt lip. Replaces A-1805-S-305 with single lip only. | All | 1 | Log in to see
prices |
|
|
| A201 |
A-1205-N-1132
|
Oil Seal-Shift Shaft
| 1.25" O.D., 0.75" I.D., single lip and dirt lip. Replaces A-1805-S-305 with single lip only. | All | 1 | Log in to see
prices |
|
|
| A202 |
2849-E-239
|
Shift Fork-Declutch
| 2849-X-336 forging, 2.03" shift fork opening. | All | | Log in to see
prices |
|
|
| A203 |
LW-166
|
Lockwire-Shift Fork
| 16 gage, 6.00" long. | All | 1 | Log in to see
prices |
|
|
| A204 |
26-X-54
|
Lockscrew-Shift Fork
| 0.38"-24, 1.16" long, square head. | All | 1 | Log in to see
prices |
|
|
| A205 |
2843-A-417
|
Shift Shaft-Declutch
| 4.88" long. No longer available | A1 | 1 | Log in to see
prices |
|
|
| A205 |
2843-C-419
|
Shift Shaft-Declutch
| 5.06" long. No longer available. | All | 1 | Log in to see
prices |
|
|
| A206 |
2843-Z-416
|
Shift Shaft-Hi-Low
| Setscrew hole 150 degrees left of vertical. No longer available. | A1 | 1 | Log in to see
prices |
|
|
| A206 |
2843-B-418
|
Shift Shaft-Hi-Low
| Set screw hole 30 degrees right of vertical. No longer available. | All others | 1 | Log in to see
prices |
|
|
| A207 |
2849-E-239
|
Shift Fork-Hi-Low
| 2849-X-336 forging, 2.03" shift fork opening. | All | 1 | Log in to see
prices |
|
|
| A208 |
LW-166
|
Lockwire-Shift Fork
| 16 gage, 6.00" long | All | 1 | Log in to see
prices |
|
|
| A209 |
26-X-54
|
Lockscrew-Shift Fork
| 0.38"-24, 1.16" long, square head. | All | 1 | Log in to see
prices |
|
|
| A210 |
1229-K-1597
|
Washer-Case And Top Cover
| 0.75" O.D., 0.41" I.D., 0.09" thick. | A1 | 10 | Log in to see
prices |
|
|
| A210 |
WA-16
|
Washer-case and top cover
| 0.67" O.D., 0.39" I.D., 0.09" thick. | All others | 9 | Log in to see
prices |
|
|
| A211 |
S-268-2
|
Washer-Case And Top Cover
| 0.38"-16, 1.00" long, grade 8. | All others | 9 | Log in to see
prices |
|
|
| A212 |
A-1199-C-1043
|
Breather-Oil
| 0.13"-27 N.P.T.F., 1.03" long. | All | 1 | Log in to see
prices |
|
|
| A213 |
S-2610-2
|
Capscrew-Case Top Cover
| 0.38"-16, 1.25" long, grade 8. | | 1 | Log in to see
prices |
|
|
| A214 |
1846-X-284
|
Dowel-T -Case And Cover
| Not used on 221 models in this book. | | 1 | Log in to see
prices |
|
|
| A215 |
1846-E-265
|
Pin-Brake Bellcrank
| 0.63" O.D., 1.66" long with 1 hole 0.16" diameter. | A1 | 1 | Log in to see
prices |
|
|
| A216 |
1898-E-57
|
Ball-Shift Shaft Lock
| 0.44" diameter ball. | All | 1 | Log in to see
prices |
|
|
| A217 |
2858-A-1
|
Spring-Shift Shaft Lock
| 13 coils, 1.88" free length. | A1, M, M6, M7 | 1 | Log in to see
prices |
|
|
| A217 |
2858-Q-277
|
Spring-Shift Shaft Lock
| 0.44" diameter, 1.52" free length. Part no longer available. | All others | | Log in to see
prices |
|
|
| A218 |
1898-E-57
|
Ball-Shift Shaft Lock
| 0.44" diameter. | All | 1 | Log in to see
prices |
|
|
| A219 |
2858-A-1
|
Spring-Shift Shaft Lock
| 13 coils, 1.88" free length. | A1, M, M6, M7 | 1 | Log in to see
prices |
|
|
| A219 |
2858-Q-277
|
Spring-Shift Shaft Lock
| 0.44" diameter, 1.52" free length. Part no longer available. | All others | 1 | Log in to see
prices |
|
|
| A220 |
1845-A-27
|
Pull Rod-Brake
| 1.65" diameter shaft, 0.10" thick. | A1 | 1 | Log in to see
prices |
|
|
| A221 |
WA-36
|
Washer-Brake Pull Rod
| 0.81" O.D., 0.40" I.D., 0.06" thick. | A1 | 1 | Log in to see
prices |
|
|
| A222 |
WA-36
|
Washer-Brake Pull Rod
| 0.81" O.D., 0.40" I.D., 0.06" thick. | A1 | 1 | Log in to see
prices |
|
|
| A223 |
302-T-540
|
Bellcrank-Brake Operating
| 0.63" dia. ream, 0.38" thick. | A1 | 1 | Log in to see
prices |
|
|
| A224 |
K-248
|
Cotter-Bellcrank Pin
| 0.13" diameter, 1.00" long. | A1 | 1 | Log in to see
prices |
|
|
| A225 |
WA-310
|
Washer-Bellcrank Pin
| 1.31" O.D., 0.66" I.D., 0.10" thick. | A1 | 1 | Log in to see
prices |
|
|
| A226 |
K-236
|
Cotter-Brake Pull Rod
| 1,0.10" diameter, 0.75" long. | A1 | | Log in to see
prices |
|
|
| A227 |
K-236
|
Cotter-Brake Pull Rod
| 0.10" diameter, 0.75" long. | A1 | 1 | Log in to see
prices |
|
|
| A228 |
2297-Z-6656
|
Gasket-Cover
| Silicone gasket, use as required.* | All | 1 | Log in to see
prices |
|
|
| A229 |
A-3855-G-267
|
Cover Assy.-T -Case Top
| No cast bosses on underside. Part no longer available. | A1 | 1 | Log in to see
prices |
|
|
| A229 |
3855-X-258
|
Cover Assy.-T -Case Top
| 3855-L-506 cast, breather hole in center and 2 cast interlock bosses on underside. | All others | 1 | Log in to see
prices |
|
|
| A230 |
1846-H-268
|
Shaft-Shift Interlock
| 0.38" diameter, 6.16" long. | M, M6, M7, N4, N7 | 1 | Log in to see
prices |
|
|
| A172 |
2297-Z-6656
|
Gasket-Brake Oil Deflector
| Not used on 221 models in this book. | | | Log in to see
prices |
|
|
| A173 |
2847-S-617
|
Oil Deflector-Brake
| Not used on 221 models in this book. | | 1 | Log in to see
prices |
|
|
| A174 |
1829-Z-754
|
Washer-Brake Oil Deflector
| Not used on 221 models in this book. | | 1 | Log in to see
prices |
|
|
| A175 |
A-3736-R-200
|
Backing Plate Assy.
| 7.25" x 1.50" DLM, 0.40" diameter-4 holes on 3.70" bolt circle. | A1 | 1 | Log in to see
prices |
|
|
| A176 |
1229-E-1513
|
Washer-Brake Mtg. Capscrew
| Not used on 221 models in this book. | | 4 | Log in to see
prices |
|
|
| A177 |
S-266-2
|
Capscrew-Brake Mounting
| 0.38"-16, 0.75" long, grade 8 | A1 | 4 | Log in to see
prices |
|
|
| A178 |
372-D-134
|
Lever-Brake
| 372-K-89 stamping, 0.38" diameter. | A1 | 1 | Log in to see
prices |
|
|
| A179 |
1779-P-94
|
Roller-Brake
| 0.75" O.D., 0.44" I.D., 0.25" thick. | A1 | 2 | Log in to see
prices |
|
|
| A180 |
2258-Q-719
|
Spring-Brake Shoe Return
| Tension spring, 0.50" O.D., 12 coils 2.63" length at 20 lb. load. Part no longer available. | A1 | 2 | Log in to see
prices |
|
|
| A181 |
A13-3722-T-202
|
Brake Shoe And Lining Assy.
| Includes lining. | A1 | 2 | Log in to see
prices |
|
|
| A184 |
3719-F-58
|
Drum-Brake
| 2.50" pilot diameter, 0.38" diameter- 4 holes on 3.13" bolt circle. | A1 | 1 | Log in to see
prices |
|
|
| A185 |
1229-E-1513
|
Washer-Brake Drum Capscrew
| Not used on 221 models in this book. | | 4 | Log in to see
prices |
|
|
| A186 |
LW-1610
|
Lockwire-Brake Drum Capscrew
| 16 gage, 10" long. | A1 | 1 | Log in to see
prices |
|
|
| A187 |
10-X-1254
|
Capscrew-Brake Drum
| 0.38"-16, 0.75" long, with drilled hole, grade 8. | A1 | 4 | Log in to see
prices |
|
|
 |
