Item No. |
Part Number |
Name | Notes | Price |
Buy |
|
1 |
NV95472
|
Magnet
| | Log in to see prices |
|
|
2 |
NV16358
|
Case, Rear Half
| 1989-91 | Log in to see prices |
|
|
2 |
NV16254
|
Case, Rear Half
| 1987-98 W/ Getrag - Same As Automatic | Log in to see prices |
|
|
2 |
NV17458
|
Case, Rear Half
| 1992-99 W/ New Process Trans. | Log in to see prices |
|
|
3 |
NV22398
|
Plug, Drain/ Fill
| 2 Req'D | Log in to see prices |
|
|
4 |
NV15142
|
Washer, Case Dowel
| | Log in to see prices |
|
|
4 |
NV61573
|
Bolt, Case Half
| | Log in to see prices |
|
|
5 |
NV21654
|
Retainer, Rear Output
| All Exc. Below | Log in to see prices |
|
|
5 |
NV16359
|
Retainer, Rear Output
| 1989 | Log in to see prices |
|
|
5 |
NV16969
|
Retainer, Rear Output
| 1990-91 | Log in to see prices |
|
|
5 |
NV16255
|
Retainer, Rear Output
| 1992-98 w/ Getrag, 1987-91 Auto Trans | Log in to see prices |
|
|
5 |
NV17459
|
Retainer, Rear Output
| 1992-95 W/ New Process Trans, 1999-00 Manual Trans | Log in to see prices |
|
|
6 |
6500318
|
Screw, Rear Retainer
| | Log in to see prices |
|
|
7 |
BRG 6207
|
Bearing, Rear Output
| | Log in to see prices |
|
|
8 |
1300-139-027
|
Ring, Retaining
| | Log in to see prices |
|
|
9 |
NV17477
|
Housing, Rear Extension
| 1987-91 All, 1992-98 W/ Getrag | Log in to see prices |
|
|
9 |
NV17462
|
Housing, Rear Extension
| 1992-98 W/ New Process Trans., 1999-Up Manual Trans | Log in to see prices |
|
|
10 |
NV61573
|
Bolt, Extension Housing
| | Log in to see prices |
|
|
11 |
NV15346
|
Bushing, Extension Housing
| | Log in to see prices |
|
|
12 |
CRS 18992
|
Seal, Rear Output
| 1987-91 .5625" Deep | Log in to see prices |
|
|
12 |
FUL 18507
|
Seal, Rear Output
| 1992-Up 1.50" Deep | Log in to see prices |
|
|
13 |
NV13955
|
Ring, Retaining
| 1.50" Od 2 Req'D | Log in to see prices |
|
|
14 |
NV16253
|
Wheel, Speed Sensor
| | Log in to see prices |
|
|
15 |
NV16209
|
Oil Pump
| | Log in to see prices |
|
|
16 |
CRS 22306
|
Seal, Oil Pump
| 1.657" Od | Log in to see prices |
|
|
17 |
NV17268
|
Mainshaft
| 1987-93 34T-37-38-32 Spl. 1.37" Od, 18.50" Oal | Log in to see prices |
|
|
17 |
NV19014
|
Mainshaft
| 1995-98 | Log in to see prices |
|
|
18 |
B5020
|
Bearing, Drive Sprocket Needle
| | Log in to see prices |
|
|
19 |
NV16247
|
Sprocket, Drive
| 1987-94 K12/25 - 34T-25 Synchro Teeth 5.16" Od, 1.98" Id | Log in to see prices |
|
|
19 |
1356-144-003
|
Sprocket, Drive
| 1987-94 K3500 | Log in to see prices |
|
|
19 |
NV17711
|
Sprocket, Drive
| 1995-Up | Log in to see prices |
|
|
20 |
NV15547
|
Ring, Synchronizer
| 48T | Log in to see prices |
|
|
21 |
NV33403
|
Assy, Synchronizer
| K15/2500 48T | Log in to see prices |
|
|
22 |
NV15658
|
Spring, Synchronizer
| 2 Req'D | Log in to see prices |
|
|
23 |
NV15213
|
Key, Synchronizer
| | Log in to see prices |
|
|
24 |
NV16205
|
Ring, Synchro Retaining
| | Log in to see prices |
|
|
25 |
NV17824
|
Hub, Range Shift
| 1997 | Log in to see prices |
|
|
25 |
NV19114
|
Hub, Range Shift
| 1987-89 29T, 34 Spl., 2.41" Oal, 2.80" Od, 1.775" Id | Log in to see prices |
|
|
25 |
NV17521
|
Hub, Range Shift
| 1996-Up 21 Ext. Teeth, 34 Spl. 2.24" Od, 1.76" Id | Log in to see prices |
|
|
25 |
NV19114
|
Hub, Range Shift
| 1987-95 29T, 34 Spl., 2.41" Oal, 2.80" Od, 1.775" Id | Log in to see prices |
|
|
26 |
NV16273
|
Assy, Planetary Carrier
| 1987-89 | Log in to see prices |
|
|
26 |
NV16550
|
Assy, Planetary Carrier
| 1990-94 29T-19 X 6 Gears, 5.437" Od, 2.360" Id W/ 5210Anrx Bearing | Log in to see prices |
|
|
26 |
NV17869
|
Assy, Planetary Carrier
| 1995-98 W/ 6010Nr Bearing | Log in to see prices |
|
|
27 |
FC66561
|
Bearing, Input Pocket
| 1991-Up | Log in to see prices |
|
|
27 |
4338913
|
Bearing, Input Pocket
| 1987-91 | Log in to see prices |
|
|
28 |
5300502
|
Plug, Input Spline
| | Log in to see prices |
|
|
29 |
NV16437
|
Washer, Thrust
| 2 Req'D | Log in to see prices |
|
|
30 |
NV16263
|
Gear, Input
| 1987-91 | Log in to see prices |
|
|
30 |
NV17118
|
Gear, Input
| 1990-93 W/ 4L80E, 5210Anrx Bearing L53T-29T-32 Spl., 5.15" Oal, 1.90" Od, 1.37" Id | Log in to see prices |
|
|
30 |
NV16959
|
Gear, Input
| 1992-94 W/ 4L80E, 5210Anrx Bearing L53T-29T-27 Spl., 1.945" Od, 1.105" Id | Log in to see prices |
|
|
30 |
NV19020
|
Gear, Input
| 1994-98 K1, K2, Mt1, Mg5 27 Spl. 6010Nr Bearing | Log in to see prices |
|
|
30 |
NV19019
|
Gear, Input
| 1994-98 K1, K2-M30 (Exc, Np1) 32 Spl. 6010Nr Bearing | Log in to see prices |
|
|
31 |
NV17483
|
Ring, Planetary Carrier Lock
| | Log in to see prices |
|
|
32 |
NV16243
|
NV16243 Ring, Retaining
| | Log in to see prices |
|
|
33 |
SKF 5210ANRX
|
Bearing, Input
| 1987-94 Thick .935" | Log in to see prices |
|
|
33 |
BRG 6010NR
|
Bearing, Input
| 1994-98 Narrow .630" | Log in to see prices |
|
|
34 |
682653
|
Ring, Retaining
| | Log in to see prices |
|
|
35 |
NV17422
|
Switch, Vacuum
| 1987-91 | Log in to see prices |
|
|
35 |
NV17347
|
Switch, Vacuum
| 1992-95 W/4L60E | Log in to see prices |
|
|
35 |
NV21971
|
Switch, Vacuum
| 1996-98 | Log in to see prices |
|
|
36 |
NV15715
|
O-Ring, Vacuum Switch
| | Log in to see prices |
|
|
37 |
NV16188
|
Retainer, Input
| | Log in to see prices |
|
|
Ni |
6500318
|
Screw, Front Input Retainer
| | Log in to see prices |
|
|
38 |
CRS 19255
|
Seal, Input
| | Log in to see prices |
|
|
39 |
NV13368
|
Nut, Flange
| | Log in to see prices |
|
|
40 |
2436163
|
Washer
| | Log in to see prices |
|
|
41 |
NV13695
|
Washer, Rubber
| | Log in to see prices |
|
|
42 |
N/A
|
Flange, Front Output
| | Log in to see prices |
|
|
Ni |
NV15099
|
Deflector
| 1987-94 K15/2500 | Log in to see prices |
|
|
Ni |
1300-044-013
|
Deflector
| 1987-94 K3500 | Log in to see prices |
|
|
Ni |
NV15577
|
Deflector
| 1995-98 | Log in to see prices |
|
|
43 |
CRS 18662
|
Seal, Front Output
| | Log in to see prices |
|
|
43 |
CRS 18994
|
Seal, Front Output
| 1987-94 K3500 | Log in to see prices |
|
|
44 |
NV16754
|
Plunger, Poppet
| | Log in to see prices |
|
|
45 |
NV16962
|
Spring, Poppet Plunger
| | Log in to see prices |
|
|
46 |
NV15715
|
O-Ring, Poppet Screw
| | Log in to see prices |
|
|
47 |
53008216
|
Screw, Poppet
| | Log in to see prices |
|
|
48 |
NV16423
|
Case, Front Half
| 1987-89 | Log in to see prices |
|
|
48 |
NV19003
|
Case, Front Half
| 1994-99 | Log in to see prices |
|
|
48 |
NV19005
|
Case, Front Half
| 1994-98 | Log in to see prices |
|
|
48 |
NV17429
|
Case, Front Half
| 1990-91 All, 1992-93 W/ Getrag 1994-95 K15/2500 W/ Getrag | Log in to see prices |
|
|
48 |
NV17456
|
Case, Front Half
| 1992-93 W/ New Process Trans, 1994-95 K15/2500 W/ New Process Trans | Log in to see prices |
|
|
48 |
12544065
|
Case, Front Half
| 1994-95 K3500 | Log in to see prices |
|
|
Ni |
NV16166
|
Gear, Planetary Ring(Annulus)
| 1987-91 24T | Log in to see prices |
|
|
Ni |
nss
|
Gear, Planetary Ring(Annulus)
| 1992-98 Sold with Front Case Half | Log in to see prices |
|
|
Ni |
NV13863
|
Ring, Retaining
| K15/2500 | Log in to see prices |
|
|
Ni |
1300-139-012
|
Ring, Retaining
| K3500 | Log in to see prices |
|
|
49 |
NV17988
|
Vent
| | Log in to see prices |
|
|
50 |
NV13795
|
Pad, Shift Fork
| 4 Req'D Use Nv15866 Insert Kit | Log in to see prices |
|
|
51 |
NV15221
|
Pad, Shift Fork Center
| 1 Req'D Can Use Nv15866 Insert Kit | Log in to see prices |
|
|
52 |
NV16337
|
Fork, Range
| Suburban Stamped #338 | Log in to see prices |
|
|
52 |
NV17833
|
Fork, Range
| Pickup Cast # C17833 | Log in to see prices |
|
|
53 |
NV15556
|
Pad, Shift Fork Center
| 1 Req'D Use Nv15866 Insert Kit | Log in to see prices |
|
|
54 |
NV17502
|
Fork, Mode
| 1987-91 W/ Rail | Log in to see prices |
|
|
54 |
NV17237
|
Fork, Mode
| 1992-98 W/ Rail W/ Pads Cast# C16196 | Log in to see prices |
|
|
54 |
NV17025
|
Fork, Mode
| 1987-91 W/ Rail Cast # C16342 | Log in to see prices |
|
|
55 |
NV16269
|
Rail, Shift Fork
| | Log in to see prices |
|
|
56 |
NV17556
|
Spring, Shift Rail
| | Log in to see prices |
|
|
57 |
NV16193
|
Bushing, Range Fork
| | Log in to see prices |
|
|
58 |
NV17349
|
Assy, Sector & Shaft
| | Log in to see prices |
|
|
59 |
NV13725
|
O-Ring, Shift Shaft
| | Log in to see prices |
|
|
60 |
NV13726
|
Retainer, Shift Shaft O-Ring
| | Log in to see prices |
|
|
61 |
NV17910
|
Assy, Shift Lever
| | Log in to see prices |
|
|
62 |
NV13992
|
Nut, Shift Lever
| | Log in to see prices |
|
|
63 |
NV16214
|
Seal, Suction Tube
| | Log in to see prices |
|
|
64 |
NV16346
|
Tube, Oil Suction
| 1987-91 | Log in to see prices |
|
|
64 |
NV16252
|
Tube, Oil Suction
| 1992-Up | Log in to see prices |
|
|
65 |
NV16218
|
Connector, Tube to Screen
| | Log in to see prices |
|
|
66 |
NV16347
|
Filter
| 1987-91 | Log in to see prices |
|
|
66 |
NV16217
|
Filter
| 1992-Up | Log in to see prices |
|
|
67 |
BRG 6207
|
Bearing, Front Output
| | Log in to see prices |
|
|
68 |
1300-139-027
|
Ring, Retaining
| | Log in to see prices |
|
|
69 |
NV17881
|
Shaft, Front Output
| 1995-Up | Log in to see prices |
|
|
69 |
NV25847
|
Shaft, Front Output
| 1999-02 Silverado | Log in to see prices |
|
|
69 |
NV16249
|
Shaft, Front Output
| 1987-94 34T-61 Spl. 8.75" Oal, 1.37" Od | Log in to see prices |
|
|
70 |
NV15307
|
Sprocket, Driven
| 34T-32 Spl. 2.58" Id | Log in to see prices |
|
|
71 |
NV13068
|
Ring, Retaining
| | Log in to see prices |
|
|
72 |
NTN J2416
|
Bearing, Front Output Inner
| | Log in to see prices |
|
|
73 |
4401-143-001
|
Chain
| 1.25" Wide K15/2500 | Log in to see prices |
|
|
73 |
4470-143-001
|
Chain
| 1.50" Wide K3500 | Log in to see prices |
|
|
Ni |
TC241U
|
Kit, Bearing & Seal
| | Log in to see prices |
|
|
Ni |
SK241
|
Kit, Seal & Gasket
| | Log in to see prices |
|
|
Ni |
SFI207
|
Kit, Shift Fork Insert
| | Log in to see prices |
|
|
Ni |
SK241DHD
|
Kit, Seal & Gasket
| | Log in to see prices |
|
|
73 |
NV16262
|
Sending Unit | Speed Sensor
| | Log in to see prices |
|
|
| |
