| Item No. |
Part Number |
Name | Qty. Per Axle | Price |
Buy |
|
| * |
110560
|
Basic Overhaul Kit (Contents Identified With *)
| 1 | Log in to see
prices |
|
|
| ^ |
99044
|
Bearing Kit (Contents Identified With ^)
| 1 | Log in to see
prices |
|
|
| A-1 |
120923
|
Diff. Carrier & Bearing Caps 120923 Carrier Casting No. (Nss) 115690 Includes Items 2-4,9-10 120923,120924 Include Items 2-4, 9-10, 35-37
| 1 | Log in to see
prices |
|
|
| A-1 |
128107
|
Diff. Carrier & Bearing Caps Carrier Casting No. (Nss) 115690 Includes Items 2-4,9-10 120923,120924 Include Items 2-4, 9-10, 35-37
| 1 | Log in to see
prices |
|
|
| A-2 |
127179
|
Bearing Cap Screw
| 4 | Log in to see
prices |
|
|
| A-3 |
26772
|
Flat Washer
| 4 | Log in to see
prices |
|
|
| A-4 |
90538
|
Lockwire
| 4 | Log in to see
prices |
|
|
| A-5 |
14275
|
Bearing Adjuster Lock (Rh)
| 1 | Log in to see
prices |
|
|
| A-6 |
90876
|
Cotter Pin (Rh)
| 1 | Log in to see
prices |
|
|
| A-7 |
7641
|
Carrier Cover Dowel Pin
| 2 | Log in to see
prices |
|
|
| A-8 |
90325
|
Filler Plug
| 1 | Log in to see
prices |
|
|
| A-9 |
31562
|
Diff. Bearing Adjuster (Rh)
| 1 | Log in to see
prices |
|
|
| A-10 |
27842
|
Diff. Bearing Adjuster (Lh)
| 1 | Log in to see
prices |
|
|
| A-11 |
KOY 563
|
Diff. Bearing Cup (Rh)
| 1 | Log in to see
prices |
|
|
| A-11 |
KOY 493
|
Diff. Bearing Cup (Lh)
| 1 | Log in to see
prices |
|
|
| A-12*^ |
KOY 567
|
Diff. Bearing Cone (Rh)
| 1 | Log in to see
prices |
|
|
| A-12*^ |
KOY 497
|
Diff. Bearing Cone (Lh)
| 1 | Log in to see
prices |
|
|
| A-13*^ |
70745
|
Ring Gear Bolt & Nut Kit (5/8")
| 1 | Log in to see
prices |
|
|
| A-13*^ |
70745QG
|
Bolt
| 16 | Log in to see
prices |
|
|
| A-15 |
60600
|
Nut
| 16 | Log in to see
prices |
|
|
| A-15 |
69957
|
Ring Gear Bolt & Nut Kit (1/2")
| 1 | Log in to see
prices |
|
|
| A-15 |
69117
|
Bolt
| 16 | Log in to see
prices |
|
|
| A-15 |
70745QG
|
Nut
| 16 | Log in to see
prices |
|
|
|
96794
|
12" O.D. -1/2" Bolt Flanged Half 91114
| 1 | Log in to see
prices |
|
|
|
96795
|
11-1/2" O.D. -1/2" Bolt Flanged Half 91116
| 1 | Log in to see
prices |
|
|
|
124374
|
5/8" Bolt Flanged Half 88677
| 1 | Log in to see
prices |
|
|
| A-16 |
210017
|
Diff. Case (Plain Half) (Nss)
| 1 | Log in to see
prices |
|
|
| A-17 |
96271
|
Diff. Case Cap Screw
| 12 | Log in to see
prices |
|
|
|
98850
|
Wheel Diff. Side Gear, Pinion Kit Includes Items 18-22 1 Models: 34,340,341
| 1 | Log in to see
prices |
|
|
|
85358
|
Wheel Diff. Side Gear, Pinion Kit Models: 38,380,381,402
| 1 | Log in to see
prices |
|
|
|
118748
|
Wheel Diff. Kit Less Side Gears Includes Items 19-22
| 1 | Log in to see
prices |
|
|
| A-18 |
37072
|
Diff, Side Gear Models: 34, 340, 341
| 2 | Log in to see
prices |
|
|
| A-18 |
37069
|
Diff, Side Gear Models: 38, 380,381,402
| | Log in to see
prices |
|
|
| A-19* |
27827QG
|
Side Gear Thrust Washer
| 2 | Log in to see
prices |
|
|
| A-20 |
104139
|
Side Pinion 104139 Replaces 37071
| 4 | Log in to see
prices |
|
|
| A-21* |
27810QG
|
Side Pinion Thrust Washer
| 4 | Log in to see
prices |
|
|
| A-22 |
128003
|
Spider
| 1 | Log in to see
prices |
|
|
| A-23 |
95205QG
|
Output Shaft Nut
| 1 | Log in to see
prices |
|
|
| A-24* |
FUL 4327
|
Flat Washer
| 1 | Log in to see
prices |
|
|
| A-26 |
75336
|
Axle Housing Cover Assy Includes Items 27-30 (Casting# 127708) 1 Cover (127781 Nss) 3/4" (Cover 127874)
| | Log in to see
prices |
|
|
| A-26 |
77750
|
Axle Housing Cover Assy Includes Items 27-30 (Casting# 127708) 1 Cover (127781 Nss)1" (Cover 77749 Nss)
| | Log in to see
prices |
|
|
| A-26* |
46583
|
Rear Bearing Retaining Washer Not Illustrated
| 1 | Log in to see
prices |
|
|
| A-27*^ |
127720
|
Output Shaft Oil Seal Note 9
| 1 | Log in to see
prices |
|
|
| A-28* |
45516
|
Bearing Snap Ring
| 1 | Log in to see
prices |
|
|
| A-29 |
46584
|
Output Shaft Bearing & Sleeve Assy
| | Log in to see
prices |
|
|
| A-29*^ |
118789
|
Inner Bearing Race
| 1 | Log in to see
prices |
|
|
| A-29*^ |
118790
|
Outer Bearing Race
| 1 | Log in to see
prices |
|
|
| A-30 |
54254
|
Magnetic Filler Plug 3/4
| 1 | Log in to see
prices |
|
|
| A-30 |
75130
|
Magnetic Filler Plug 3/4" 1"
| 1 | Log in to see
prices |
|
|
| A-31 |
98603
|
Output Shaft, Nut & Bushing Kit Includes Items 23, 32-33; 115123 Also Includes Items 38-39
| 1 | Log in to see
prices |
|
|
| A-31 |
85441
|
Shaft (Nss) 10 Splines, 1.750" Dia.
| | Log in to see
prices |
|
|
| A-32* |
48922QG
|
Output Shaft Bushing
| 1 | Log in to see
prices |
|
|
| A-33* |
46526QG
|
Output Shaft O Ring
| 2 | Log in to see
prices |
|
|
| A-34* |
85994QG
|
Side Gear Snap Ring
| 2 | Log in to see
prices |
|
|
| A-35*^ |
51232
|
Output Shaft Bearing Cup (Inner)
| 1 | Log in to see
prices |
|
|
| A-36*^ |
NTN 34274
|
Output Shaft Bearing Cone (Inner)
| 1 | Log in to see
prices |
|
|
| A-37 |
85909
|
Output Shaft Side Gear
| 1 | Log in to see
prices |
|
|
| A-40 |
95213
|
Inter-Axle Diff. Assy W/O Lube Pump
| | Log in to see
prices |
|
|
| A-41 |
91850
|
Diff Case Kit W/O Lube Pump
| | Log in to see
prices |
|
|
| A-41 |
88029
|
Case Half (Nss) W/O Lube Pump
| 2 | Log in to see
prices |
|
|
| A-42 |
85438
|
Bolt
| 8 | Log in to see
prices |
|
|
| A-43 |
57637
|
Nut
| 8 | Log in to see
prices |
|
|
|
96380
|
Diff Side Pinion & Spider Kit (Includes Items 44-47) 1 W/O Lube Pump
| 1 | Log in to see
prices |
|
|
| A-44 |
95210
|
Side Pinion W/O Lube Pump
| 4 | Log in to see
prices |
|
|
| A-45* |
95211QG
|
Side Pinion Bushing W/O Lube Pump
| 4 | Log in to see
prices |
|
|
| A-46* |
25968QG
|
Side Pinion Thrust Wisher W/O Lube Pump
| 4 | Log in to see
prices |
|
|
| A-47 |
95212
|
Spider W/O Lube Pump
| | Log in to see
prices |
|
|
| A-48 |
45476
|
Helical Side Gear & Bushing Assy Includes Item 49
| 1 | Log in to see
prices |
|
|
| A-48 |
45474
|
Side Gear (Nss)
| | Log in to see
prices |
|
|
| A-49* |
48921QG
|
Helical Side Gear Bushing
| 2 | Log in to see
prices |
|
|
| A-50* |
46983
|
Helical Side Gear Snap Ring
| 1 | Log in to see
prices |
|
|
| A-51* |
45477
|
Helical Side Gear Thrust Washer
| 1 | Log in to see
prices |
|
|
| A-52* |
45478QG
|
Helical Side Gear "D" Washer
| 1 | Log in to see
prices |
|
|
| A-53 |
128016
|
Lockout Sliding Clutch
| 1 | Log in to see
prices |
|
|
| A-54 |
98693
|
Input Shaft, Washer & Nut Kit Includes Item 52 & 63 Models W/O Lube Pump
| 1 | Log in to see
prices |
|
|
| A-55* |
83469
|
Input Shaft Bearing Cone
| 1 | Log in to see
prices |
|
|
| A-56 |
86813
|
Input Bearing Cover, Cup & Seal Assy Includes Items 57 & 61 Models W/O Lube Pump
| 1 | Log in to see
prices |
|
|
| A-56 |
86811
|
Cover (Nss)
| | Log in to see
prices |
|
|
| A-57*^ |
83462
|
Input Bearing Cup
| 1 | Log in to see
prices |
|
|
| A-58* |
45498
|
Input Bearing Cover Shim .003"
| AR | Log in to see
prices |
|
|
| A-58* |
70709
|
Input Bearing Cover Shim .005"
| | Log in to see
prices |
|
|
| A-58* |
45499
|
Input Bearing Cover Shim .010"
| | Log in to see
prices |
|
|
| A-58* |
85406
|
Input Bearing Cover Shim .020"
| | Log in to see
prices |
|
|
| A-59 |
113324
|
Bearing Cover Cap Screw
| 5 | Log in to see
prices |
|
|
|
114465
|
Oil Seal & Shim Kit Includes Items 27,58,61,83 & Rtv
| 1 | Log in to see
prices |
|
|
| A-61*^ |
127720
|
Oil Seal
| 1 | Log in to see
prices |
|
|
| A-63 |
95206QG
|
Input Shaft Nut
| 1 | Log in to see
prices |
|
|
| A-64* |
56864
|
Flat Washer
| 1 | Log in to see
prices |
|
|
| A-65 |
45481
|
Diff. Carrier Cover Assy Models W/O Lube Pump
| 1 | Log in to see
prices |
|
|
| A-68 |
12063
|
Carrier Cover Cap Screw Models W/O Lube Pump (Long)
| 5 | Log in to see
prices |
|
|
| A-68 |
90069
|
Carrier Cover Cap Screw Models W/O Lube Pump (Short)
| 4 | Log in to see
prices |
|
|
| A-69 |
90417
|
Lockwasher
| 9 | Log in to see
prices |
|
|
| A-78*^ |
830398
|
Pinion Pilot Bearing
| 1 | Log in to see
prices |
|
|
| A-79*^ |
NTN 72200C
|
Pinion Bearing Cone (Inner)
| 1 | Log in to see
prices |
|
|
| A-79*^ |
NTN 72200C
|
Pinion Bearing Cone (Outer)
| 1 | Log in to see
prices |
|
|
| A-81 |
107322
|
Pinion Bearing Cage & Cup Assy Includes Item 82 Ratios 3.55 & 3.70
| 1 | Log in to see
prices |
|
|
| A-81 |
107321
|
Pinion Bearing Cage & Cup Assy Includes Item 82 Cage (Nss)
| | Log in to see
prices |
|
|
| A-81 |
107324
|
Pinion Bearing Cage & Cup Assy Includes Item 82 Ratios 3.08, 3.25, 3.36, 3.90-7.17
| | Log in to see
prices |
|
|
| A-81 |
107323
|
Pinion Bearing Cage & Cup Assy Includes Item 82 Cage (Nss)
| | Log in to see
prices |
|
|
| A-82*^ |
KOY 72487
|
Pinion Bearing Cup (Inner)
| 1 | Log in to see
prices |
|
|
| A-82*^ |
KOY 72487
|
Pinion Bearing Cup (Outer)
| 1 | Log in to see
prices |
|
|
| A-83* |
45461
|
Pinion Bearing Cage Shim .003"
| AR | Log in to see
prices |
|
|
| A-83* |
62829
|
Pinion Bearing Cage Shim .005"
| | Log in to see
prices |
|
|
| A-83* |
45462
|
Pinion Bearing Cage Shim .010"
| | Log in to see
prices |
|
|
| A-83* |
62830
|
Pinion Bearing Cage Shim .020"
| | Log in to see
prices |
|
|
| A-83 |
45463
|
Pinion Bearing Cage Shim .030"
| | Log in to see
prices |
|
|
| A-84 |
62158
|
Bearing Cage Cap Screw
| 6 | Log in to see
prices |
|
|
| A-85 |
37207
|
Lockwasher
| 6 | Log in to see
prices |
|
|
| A-86 |
46977
|
Pinion Helical Gear 34/38DSB,C
| | Log in to see
prices |
|
|
| A-86 |
74991
|
Pinion Helical Gear 34/38DSD,E
| | Log in to see
prices |
|
|
| A-88 |
95206QG
|
Slotted Nut
| 1 | Log in to see
prices |
|
|
| A-90 |
45859
|
Shift Fork & Push Rod Assy Models W/O Lube Pump
| 1 | Log in to see
prices |
|
|
| *^ |
RTV 1473
|
Shift Fork & Push Rod Assy Gasket Compound
| AR | Log in to see
prices |
|
|
 |
Axle Housing & Shafts.JPG "Differential Lockout (Current Production)"){kind=small}
Differential Lockout (Current Production).JPG "Differential Lockout (Non-Current Production)"){kind=small}
Differential Lockout (Non-Current Production)
