| Item No. |
Part Number |
Name | Remarks | Axle Model | Qty | Price |
Buy |
|
| A153 |
MER A1-3226T1112S
|
Output (Thru) Shaft, Bearing Cage And Seal Assembly
| (Includes Items 154, 156, 159, 160, 161, 162, 163, 164, 165) | All | 1 | Log in to see
prices |
|
|
| A154 |
3297E1019QG
|
Shaft - Output (Thru)
| | All others | 1 | Log in to see
prices |
|
|
| A154 |
3297-N-1158
|
Shaft - Output (Thru)
| | Original design 140 tandem | 1 | Log in to see
prices |
|
|
| A155 |
MER 2297A7021
|
Silastic Gasket
| 3 oz. tube | All | 1 | Log in to see
prices |
|
|
| A156 |
MER A-3226T1112
|
Bearing Cage And Inner Cup Assembly - Output
| | All others | 1 | Log in to see
prices |
|
|
| A156 |
MER A1-3226T1112S
|
Bearing Cage And Inner Cup Assembly - Output
| Must change yoke to 2"-39 spline | Original design 140 tandem | 1 | Log in to see
prices |
|
|
| A156A |
KIT 2583
|
Deflector (No Longer Used
| | | 1 | Log in to see
prices |
|
|
| A157 |
MER 1229K1597
|
Washer - Output Bearing Cage
| | All | 4 | Log in to see
prices |
|
|
| A158 |
15-X-387
|
Capscrew - Output Bearing Cage
| | All | 4 | Log in to see
prices |
|
|
| A159 |
KOY JLM104910
|
Cup - Inner And Outer Output Bearing
| | All others | 2 | Log in to see
prices |
|
|
| A159 |
KOY LM603011
|
Cup - Inner And Outer Output Bearing
| | Original design 140 tandem | 2 | Log in to see
prices |
|
|
| A160 |
KOY LM104949
|
Cone - Inner And Outer Output Bearing
| | All others | 2 | Log in to see
prices |
|
|
| A160 |
KOY LM603049
|
Cone - Inner And Outer Output Bearing
| | Original design 140 tandem | 2 | Log in to see
prices |
|
|
| A161 |
MER 1229P2590
|
Snap Ring Spacer - Output Bearing
| 3.94mm/.155 inch | All others | 1 | Log in to see
prices |
|
|
| A161 |
MER 1229A2237
|
Snap Ring Spacer - Output Bearing
| 3.94mm/.155 inch | Original design 140 tandem | 1 | Log in to see
prices |
|
|
| A161 |
MER 1229Q2591
|
Snap Ring Spacer - Output Bearing
| 4.01mm/.158 inch | All others | 1 | Log in to see
prices |
|
|
| A161 |
MER 1229B2238
|
Snap Ring Spacer - Output Bearing
| 4.01mm/.158 inch | Original design 140 tandem | 1 | Log in to see
prices |
|
|
| A161 |
MER 1229R2592
|
Snap Ring Spacer - Output Bearing
| 4.09mm/.161 inch | All others | 1 | Log in to see
prices |
|
|
| A161 |
MER 1229C2239
|
Snap Ring Spacer - Output Bearing
| 4.09mm/.161 inch | Original design 140 tandem | 1 | Log in to see
prices |
|
|
| A161 |
MER 1229S2593
|
Snap Ring Spacer - Output Bearing
| 4.17mm/.164 inch | All others | 1 | Log in to see
prices |
|
|
| A161 |
MER 1229D2240
|
Snap Ring Spacer - Output Bearing
| 4.17mm/.164 inch | Original design 140 tandem | 1 | Log in to see
prices |
|
|
| A161 |
MER 1229T2594
|
Snap Ring Spacer - Output Bearing
| 4.24mm/.167 inch | All others | 1 | Log in to see
prices |
|
|
| A161 |
MER 1229E2241
|
Snap Ring Spacer - Output Bearing
| 4.24mm/.167 inch | Original design 140 tandem | 1 | Log in to see
prices |
|
|
| A161 |
MER 1229U2595
|
Snap Ring Spacer - Output Bearing
| 4.32mm/.170 inch | All others | 1 | Log in to see
prices |
|
|
| A161 |
MER 1229F2242
|
Snap Ring Spacer - Output Bearing
| 4.32mm/.170 inch | Original design 140 tandem | 1 | Log in to see
prices |
|
|
| A161 |
MER 1229V2596
|
Snap Ring Spacer - Output Bearing
| 4.39mm/.173 inch | All others | 1 | Log in to see
prices |
|
|
| A161 |
MER 1229G2243
|
Snap Ring Spacer - Output Bearing
| 4.39mm/.173 inch | Original design 140 tandem | 1 | Log in to see
prices |
|
|
| A161 |
MER 1229W2597
|
Snap Ring Spacer - Output Bearing
| 4.47mm/.176 inch | All others | 1 | Log in to see
prices |
|
|
| A161 |
MER 1229H2244
|
Snap Ring Spacer - Output Bearing
| 4.47mm/.176 inch | Original design 140 tandem | 1 | Log in to see
prices |
|
|
| A161 |
MER 1229X2598
|
Snap Ring Spacer - Output Bearing
| 4.55mm/.179 inch | All others | 1 | Log in to see
prices |
|
|
| A161 |
MER 1229J2246
|
Snap Ring Spacer - Output Bearing
| 4.55mm/.179 inch | Original design 140 tandem | 1 | Log in to see
prices |
|
|
| A161 |
MER 1229Y2599
|
Snap Ring Spacer - Output Bearing
| 4.62mm/1.82 inch | All others | 1 | Log in to see
prices |
|
|
| A161 |
MER 1229K2247
|
Snap Ring Spacer - Output Bearing
| 4.62mm/1.82 inch | Original design 140 tandem | 1 | Log in to see
prices |
|
|
| A162 |
MER 1229W4131
|
Snap Ring Spacer - Output Bearing/Yoke
| | All others | 1 | Log in to see
prices |
|
|
| A162 |
MER 1829A859
|
Snap Ring Spacer - Output Bearing/Yoke
| | Original design 140 tandem | 1 | Log in to see
prices |
|
|
| A163 |
MER A-1205G2425
|
Oil Seal - Output Bearing Cage
| | Original design 140 tandem | 1 | Log in to see
prices |
|
|
| A163 |
A1205P2590QG
|
Oil Seal - Output Bearing Cage
| | All others | 1 | Log in to see
prices |
|
|
| A164 |
1229A2653QG
|
Washer - Output Yoke And Shaft
| Included in KIT 2636 | Original design 140 tandem | 1 | Log in to see
prices |
|
|
| A164 |
MER 1229T1736
|
Washer - Output Yoke And Shaft
| Included in KIT 2637 | All others | 1 | Log in to see
prices |
|
|
| A165 |
MER KIT2636
|
Nut - Output Yoke And Shaft
| Included in KIT 2636 | Original design 140 tandem | 1 | Log in to see
prices |
|
|
| A165 |
KIT2637QG
|
Nut - Output Yoke And Shaft
| Included in KIT 2637 | All others | 1 | Log in to see
prices |
|
|
| A167 |
MER A-1199W4053
|
Breather Assembly
| | All | 1 | Log in to see
prices |
|
|
| A168 |
4-X-1921
|
Stud - Housing To Carrier.
| For aluminum or iron carriers | All forward carriers | 2 | Log in to see
prices |
|
|
| A169 |
P-28-S
|
Plug - Heat Indicator
| | All | 1 | Log in to see
prices |
|
|
| A170 |
MER 1250E473
|
Plug - Magnetic Oil Drain And Fill
| Female socket | All | 1 | Log in to see
prices |
|
|
| A170 |
1250-L-1286
|
Plug - Magnetic Oil Drain And Fill
| Male socket | All | 1 | Log in to see
prices |
|
|
| A171 |
MER P-212
|
Plug - Non-Magnetic Oil Fill
| | All | 1 | Log in to see
prices |
|
|
| A172 |
MER 1229W1557
|
Washer - Carrier To Housing
| | All | 12 | Log in to see
prices |
|
|
| A173 |
MER 2297A7021
|
Silastic Gasket - Housing To Carrier
| | All | 1 | Log in to see
prices |
|
|
| A174 |
10-X-1597
|
Capscrew - Carrier To Housing
| Included in KIT 2668 | All forward carriers | 3 | Log in to see
prices |
|
|
| A174 |
MER 10X1594
|
Capscrew - Carrier To Housing
| Included in KIT 2668 | All forward carriers | 7 | Log in to see
prices |
|
|
| A174 |
MER 10X1594
|
Capscrew - Carrier To Housing
| | All other single and rear carriers | 8 | Log in to see
prices |
|
|
| A174 |
MER S-21020A-2
|
Capscrew - Carrier To Housing
| | All other single and rear carriers | 4 | Log in to see
prices |
|
|
| A174 |
MER 10X1594
|
Capscrew - Carrier To Housing
| | RR22145, RR21145 | 9 | Log in to see
prices |
|
|
| A174 |
S-21016-2
|
Capscrew - Carrier To Housing
| | RR22145, RR21145 | 4 | Log in to see
prices |
|
|
| A175 |
MER N-110-1
|
Nut - Carrier To Housing Stud
| | All forward carriers | 2 | Log in to see
prices |
|
|
| A176 |
S-258-2
|
Capscrew - Brake Line Bracket
| | All | 2 | Log in to see
prices |
|
|
| A177 |
2208-P-536
|
Gasket - Brake Line Bracket
| | All others | 2 | Log in to see
prices |
|
|
| A177 |
2208-P-536
|
Gasket - Brake Line Bracket
| | RS16140, RS17140, RS19145, RS21145 | 4 | Log in to see
prices |
|
|
| A178 |
MER 1229E1669
|
Washer - Brake Line Bracket
| | All others | 2 | Log in to see
prices |
|
|
| A178 |
MER 1229E1669
|
Washer - Brake Line Bracket
| | RS16140, RS17140, RS19145, RS21145 | 4 | Log in to see
prices |
|
|
| A179 |
MER A-1205W1349
|
Oil Seal - Wheel End
| | "L" wheel end | 2 | Log in to see
prices |
|
|
| A179 |
NAT 370003A
|
Oil Seal - Wheel End
| | "R" wheel end | 2 | Log in to see
prices |
|
|
| A180 |
KOY 47686
|
Cone - Wheel Bearing (Inner)
| | "L" wheel end | 2 | Log in to see
prices |
|
|
| A180 |
NTN 594A
|
Cone - Wheel Bearing (Inner)
| | "R" wheel end | 2 | Log in to see
prices |
|
|
| A181 |
KOY 47620
|
Cup - Wheel Bearing (Inner)
| | "L" wheel end | 2 | Log in to see
prices |
|
|
| A181 |
NTN 592A
|
Cup - Wheel Bearing (Inner)
| | "R" wheel end | 2 | Log in to see
prices |
|
|
| A182 |
KOY 39520
|
Cup - Wheel Bearing (Outer)
| | "L" wheel end | 2 | Log in to see
prices |
|
|
| A182 |
KOY 572
|
Cup - Wheel Bearing (Outer
| | "R" wheel end | 2 | Log in to see
prices |
|
|
| A183 |
NTN 39590
|
Cone - Wheel Bearing (Outer)
| | "L" wheel end | 2 | Log in to see
prices |
|
|
| A183 |
NTN 580
|
Cone - Wheel Bearing (Outer
| | "R" wheel end | 2 | Log in to see
prices |
|
|
| A184 |
MER R006142
|
Nut - Wheel Bearing (Inner)
| | "L" wheel end | 2 | Log in to see
prices |
|
|
| A184 |
MER 1227W517
|
Nut - Wheel Bearing (Inner)
| | "R" wheel end | 2 | Log in to see
prices |
|
|
| A185, 185A |
MER KIT2761
|
Lock Washer And Tanged Lock Washer
| Must purchase kit which includes both items | "L" wheel end | 2 | Log in to see
prices |
|
|
| A185, 185A |
1229-F-4634S
|
Lock Washer And Tanged Lock Washer
| Must purchase kit which includes both items | "R" wheel end | 2 | Log in to see
prices |
|
|
| A186 |
MER R002462
|
Nut - Wheel Bearing (Outer)
| | "L" wheel end | 2 | Log in to see
prices |
|
|
| A186 |
MER R002305
|
Nut - Wheel Bearing (Outer)
| | R" wheel end | 2 | Log in to see
prices |
|
|
 |
Forward Carrier
Rear Carrier
