| Item No. |
Part Number |
Name | Qty | Price |
Buy |
|
| A1 |
1P467
|
Housing, Standard Mount (X)
| 1 | Log in to see
prices |
|
|
|
1P468
|
Housing, Extra Deep Mount (Q)
| 1 | Log in to see
prices |
|
|
|
1P469
|
Housing, Deep Mount (Z)
| 1 | Log in to see
prices |
|
|
|
1P470X
|
Housing, Low Profile (R)
| 1 | Log in to see
prices |
|
|
| A2 |
3P202
|
Driveshaft, Standard Output (1.25" Round)
| 1 | Log in to see
prices |
|
|
| A3 |
500007-29
|
Woodruff Key (.3125" X 1.125")
| 1 | Log in to see
prices |
|
|
| A7 |
4P45
|
Spacer, Driveshaft (1.410" Wide)
| 1 | Log in to see
prices |
|
|
| A8 |
9P55
|
Shaft, Input Idler (4.812" Long)
| 1 | Log in to see
prices |
|
|
| N.S. |
9P54
|
Shaft, Pressure Lube Input Idler (4.812" Long)
| 1 | Log in to see
prices |
|
|
| N.S. |
379231
|
Pipe Plug, Pressure Lube (.125"-27 NPTF)
| 1 | Log in to see
prices |
|
|
| N.S. |
328075X
|
Hose Assembly, Pressure Lube (24" Long)
| 1 | Log in to see
prices |
|
|
| A9 |
14P50
|
Spacer, Caged Needle Bearing (.587")
| 1 | Log in to see
prices |
|
|
| A10 |
328273X
|
Bearing Cap, Open End, Standard Output ("XD")
| 1 | Log in to see
prices |
|
|
| A11 |
328274X
|
Bearing Cap, Closed End, Standard Output
| 1 | Log in to see
prices |
|
|
| A12 |
22P127-1
|
Gasket, Bearing Cover (.010")
| A.R. | Log in to see
prices |
|
|
|
22P127-2
|
Gasket, Bearing Cover (.020")
| A.R. | Log in to see
prices |
|
|
|
22P127-3
|
Gasket, Bearing Cover (.015")
| A.R. | Log in to see
prices |
|
|
| A13 |
28P216
|
Oil Seal, Output Shaft ("XD")
| 1 | Log in to see
prices |
|
|
| A14 |
31P58
|
Thrust Washer
| 1 | Log in to see
prices |
|
|
| A15 |
31P47
|
Thrust Washer
| 1 | Log in to see
prices |
|
|
| A16 |
35P8
|
Gasket, Cover (.032") (Use 2 For Wire Shift)
| 1 | Log in to see
prices |
|
|
| A17 |
378391
|
Retaining Ring, Driveshaft
| 1 | Log in to see
prices |
|
|
| A18 |
550886
|
Bearing, Caged Needle Roller
| 2 | Log in to see
prices |
|
|
| A19 |
378430-10
|
Capscrew, Bearing Cap Hex Head (.3125"-18 X 1")
| 8 | Log in to see
prices |
|
|
| A20 |
378452-7
|
Setscrew, Standard Mount Housing (.250"-20 X .500")
| 1 | Log in to see
prices |
|
|
|
378452-4
|
Setscrew, Deep Mount Housing (.250"-20 X .312")
| 1 | Log in to see
prices |
|
|
| A21 |
550221
|
Bearing Cup
| 2 | Log in to see
prices |
|
|
| A22 |
550397
|
Bearing Cone, Output End
| 1 | Log in to see
prices |
|
|
| A23 |
550532
|
Bearing Cone, Closed End
| 1 | Log in to see
prices |
|
|
|
328805-1X
|
Cable Shift Cover Assembly (Assemblies 3 & 6)
| 1 | Log in to see
prices |
|
|
|
328805-2X
|
Cable Shift Cover Assembly (Assemblies 4 & 5) (Includes Items 24 Thru 34)
| 1 | Log in to see
prices |
|
|
| A24 |
34P74
|
Cover, Shifter
| 1 | Log in to see
prices |
|
|
| A25 |
500365-22
|
Flat Washer
| 1 | Log in to see
prices |
|
|
| A26 |
37P19
|
Poppet Spring, Shifter
| 1 | Log in to see
prices |
|
|
| A27 |
51P22
|
Shift Lever
| 1 | Log in to see
prices |
|
|
| A28 |
63P16
|
Shift Poppet
| 1 | Log in to see
prices |
|
|
| A29 |
500356-10
|
Lockwasher, Shift Lever
| 1 | Log in to see
prices |
|
|
| A30 |
380515
|
Indicator Switch (Normally Off)
| 1 | Log in to see
prices |
|
|
| A31 |
378004
|
Flat Washer
| 1 | Log in to see
prices |
|
|
| A32 |
500409-6
|
Screw, Shift Lever Hex (.3125"-24 X .625")
| 1 | Log in to see
prices |
|
|
| A33 |
328803-1X
|
Post & Plate Assembly (Assemblies 3 & 6)
| 1 | Log in to see
prices |
|
|
|
328803-2X
|
Post & Plate Assembly (Assemblies 4 & 5)
| 1 | Log in to see
prices |
|
|
| A34 |
28P191
|
O-Ring, Shifter Post
| 1 | Log in to see
prices |
|
|
| A35 |
378430-10
|
Capscrew, Hex Head (.3125" - 18 X 1")
| 4 | Log in to see
prices |
|
|
| A36 |
5A125X
|
Spacer, Shifter Cover (Wire Shift Only)
| 1 | Log in to see
prices |
|
|
|
68P2
|
Name Plate
| 1 | Log in to see
prices |
|
|
| A37 |
328948-6X
|
Gasket & Installation Instructions
| 1 | Log in to see
prices |
|
|
|
35P9-1
|
Gasket, Mounting (.010" Thick)
| 2 | Log in to see
prices |
|
|
|
35P9-2
|
Gasket, Mounting (.020" Thick)
| 2 | Log in to see
prices |
|
|
| N.S. |
328346-10X
|
Cable Control Assembly (Includes 378441-10 10' Cable & 378502 Knob)
| 1 | Log in to see
prices |
|
|
|
328380X
|
Mounting Parts Kit (Cable Control) (Includes Items 38 Thru 41)
| 1 | Log in to see
prices |
|
|
| A38 |
50P17
|
Bracket, Cable Control
| 1 | Log in to see
prices |
|
|
| A39 |
50P19
|
Bracket, Swivel
| 1 | Log in to see
prices |
|
|
| N.S. |
378019
|
Pin, Pivot
| 1 | Log in to see
prices |
|
|
| A40 |
378326
|
Nut, Hex (.25"-20)
| 1 | Log in to see
prices |
|
|
| N.S. |
500568-4
|
Setscrew (.25"-20 X .50")
| 1 | Log in to see
prices |
|
|
| A41 |
500396-8
|
Capscrew, Hex Head (.25"-20 X .75")
| 1 | Log in to see
prices |
|
|
| N.S. |
328170-1X
|
Stud Kit, Standard Mount
| 1 | Log in to see
prices |
|
|
|
379286-30
|
Capscrew (.375"-16 X 4")
| 1 | Log in to see
prices |
|
|
|
379286-42
|
Capscrew (.375"-16 X 7")
| 1 | Log in to see
prices |
|
|
|
379423-18
|
Stud (.375"-16 & .375"-24 X 2.00")
| 2 | Log in to see
prices |
|
|
|
378018
|
Copper Washer
| 6 | Log in to see
prices |
|
|
|
379744
|
Nut, Flange (.375"-24)
| 2 | Log in to see
prices |
|
|
|
378774
|
Washer, Tab Lock
| 4 | Log in to see
prices |
|
|
|
379286-13
|
Capscrew, Hex Head (.375"-16)
| 2 | Log in to see
prices |
|
|
| N.S. |
328170-26X
|
Stud Kit, Deep Mount .
| 1 | Log in to see
prices |
|
|
|
379286-29
|
Capscrew (.375"-16 X 3.75")
| 1 | Log in to see
prices |
|
|
|
379286-41
|
Capscrew (.375"-16 X 6.75")
| 1 | Log in to see
prices |
|
|
|
379423-14
|
Stud (.375"-16 & .375"-24 X 1.75")
| 2 | Log in to see
prices |
|
|
|
378018
|
Copper Washer
| 6 | Log in to see
prices |
|
|
|
379744
|
Nut, Flange (.375"-16 X 1")
| 2 | Log in to see
prices |
|
|
|
379286-11
|
Capscrew (.375"-16 X 1")
| 2 | Log in to see
prices |
|
|
|
378774
|
Washer, Tab Lock
| 4 | Log in to see
prices |
|
|
| N.S. |
328170-155X
|
Stud Kit, Low Profile
| 1 | Log in to see
prices |
|
|
|
379286-42
|
Capscrew (.375"-16 X 7")
| 1 | Log in to see
prices |
|
|
|
379286-14
|
Capscrew (.375"-16 X 1.5")
| 2 | Log in to see
prices |
|
|
|
379423-18
|
Stud (.375"-16 & .375"-24 X 2.00")
| 2 | Log in to see
prices |
|
|
|
378018
|
Copper Washer
| 5 | Log in to see
prices |
|
|
|
379744
|
Nut, Flange (.375"-24)
| 2 | Log in to see
prices |
|
|
|
378774
|
Washer, Tab Lock
| 5 | Log in to see
prices |
|
|
|
328751-1X
|
Installation Kit, Cable Or Lever Indicator Light
| 1 | Log in to see
prices |
|
|
|
328388-47X
|
Installation Kit, 12-Volt Electric Over Air
| 1 | Log in to see
prices |
|
|
|
328388-48X
|
Installation Kit, 24-Volt Electric Over Air
| 1 | Log in to see
prices |
|
|
|
328356-13X
|
Gasket & Seal Kit
| 1 | Log in to see
prices |
|
|
|
328356-15X
|
Seal Kit, Cable Shift
| 1 | Log in to see
prices |
|
|
|
328356-18X
|
Seal Kit, Lever Shift
| 1 | Log in to see
prices |
|
|
|
328356-19X
|
Seal Kit, Air Shift
| 1 | Log in to see
prices |
|
|
 |
Air Control
Lever Control
