Item No. |
Part Number |
Name | Qty | Price |
Buy |
|
A1 |
1P437
|
Housing, Standard Mount
| 1 | Log in to see prices |
|
|
|
1P460
|
Housing, Special Mount For Jatco
| 1 | Log in to see prices |
|
|
A2 |
68P2
|
Name Plate
| 1 | Log in to see prices |
|
|
A3 |
378422
|
Drive Screw
| 2 | Log in to see prices |
|
|
A5 |
9P54
|
Shaft, Input Idler (Pressure Lube)
| 1 | Log in to see prices |
|
|
|
9P55
|
Shaft, Input Idler (No Pressure Lube)
| 1 | Log in to see prices |
|
|
A6 |
31P61
|
Thrust Washer (0.031" Thick)
| 2 | Log in to see prices |
|
|
A7 |
560920
|
Bearing, Needle Thrust
| 2 | Log in to see prices |
|
|
A8 |
31P62
|
Thrust Washer (0.125" Thick)
| 2 | Log in to see prices |
|
|
A9 |
550886
|
Roller Bearing (Idler Pin)
| 2 | Log in to see prices |
|
|
A10 |
14P54
|
Spacer, Needle Bearing (Idler Shaft)
| 1 | Log in to see prices |
|
|
A11 |
379231
|
Pipe Plug (0.125"-27 N.P.T.F.)
| 1 | Log in to see prices |
|
|
A12 |
378452-7
|
Set Screw (0.250"-20 X 0.312")
| 1 | Log in to see prices |
|
|
A14 |
3P679
|
Output Shaft, Standard Output 1-.250" Rd. (Assemblies 3 & 5)
| 1 | Log in to see prices |
|
|
N.S. |
3P677
|
Output Shaft, Standard Output 1-.250" Rd. (Assemblies 4 & 6)
| 1 | Log in to see prices |
|
|
N.S. |
3P678X
|
Shaft, Output 0.875" 13 Tooth Internal Spline (“XK” & “XP” Assemblies 4 & 6)
| 1 | Log in to see prices |
|
|
N.S. |
3P686X
|
Shaft, Output 0.875" 13 Tooth Internal Spline (“XK” & “XP” Assemblies 3 & 5)
| 1 | Log in to see prices |
|
|
N.S. |
3P703X
|
Shaft, Output 0.875" 13 Tooth Internal Spline (“RA” & “RB” & “XR” Assemblies 3 & 5)
| 1 | Log in to see prices |
|
|
N.S. |
3P787X
|
Shaft, Output 1.250 Tapered -.312 key way (“XX” Assemblies 3 & 5)
| 1 | Log in to see prices |
|
|
N.S. |
3P788X
|
Shaft, Output 1.250 Tapered -.312 key way (“XX” Assemblies 4 & 6)
| 1 | Log in to see prices |
|
|
N.S. |
3P896X
|
Shaft, Output 1" 15 Tooth Internal Spline (“AF” Assemblies 3 & 5)
| 1 | Log in to see prices |
|
|
N.S. |
3P895X
|
Shaft, Output 1" 15 Tooth Internal Spline (“AF” Assemblies 4 & 6)
| 1 | Log in to see prices |
|
|
A15 |
379746
|
Snap Ring
| 1 | Log in to see prices |
|
|
A16 |
14P49
|
Spacer, Needle Bearing (Drive Shaft)
| 1 | Log in to see prices |
|
|
A17 |
560918
|
Roller Bearing (Output Shaft)
| 2 | Log in to see prices |
|
|
A18 |
31P57
|
Thrust Washer (Output Shaft)
| 1 | Log in to see prices |
|
|
A19 |
550010
|
Ball Bearing (Output Shaft)
| 2 | Log in to see prices |
|
|
A20 |
2P858
|
Inner Clutch Gear
| 1 | Log in to see prices |
|
|
A21 |
37P39
|
Clutch Spring
| 1 | Log in to see prices |
|
|
A22 |
379485
|
Friction Disc
| 8 | Log in to see prices |
|
|
A23 |
379595
|
Clutch Plate
| 7 | Log in to see prices |
|
|
|
328676X
|
Clutch Piston & Ball Assembly
| 1 | Log in to see prices |
|
|
A24 |
379133
|
Piston
| 1 | Log in to see prices |
|
|
A25 |
378856
|
Wiggler Wire (.012" Diameter)
| 1 | Log in to see prices |
|
|
A26 |
28P244
|
O-Ring
| 2 | Log in to see prices |
|
|
A27 |
28P121
|
Block Vee Ring
| 1 | Log in to see prices |
|
|
A28 |
378760
|
Clutch Back-Up Cylinder
| 1 | Log in to see prices |
|
|
A29 |
378576
|
Snap Ring
| 1 | Log in to see prices |
|
|
A30 |
329014-1X
|
Bearing Cover, Open End (Assemblies 3 & 5)
| 1 | Log in to see prices |
|
|
|
21P297
|
Bearing Cover, Open End (Assemblies 4 & 6)
| 1 | Log in to see prices |
|
|
A31 |
28P119
|
Oil Seal
| 1 | Log in to see prices |
|
|
A32 |
22P53
|
Gasket, Bearing Cover
| 2 | Log in to see prices |
|
|
|
328806X
|
Bearing Cover Assembly, Closed End (Assemblies 3 & 5)
| 1 | Log in to see prices |
|
|
|
328988X
|
Bearing Cover Assembly, Closed End (Assemblies 4 & 6) (Includes Items 33 Thru 36)
| 1 | Log in to see prices |
|
|
A33 |
328806X
|
Bearing Cover, Closed End (Assemblies 3 & 5)
| 1 | Log in to see prices |
|
|
|
21P449
|
Bearing Cover, Closed End (Assemblies 4 & 6)
| 1 | Log in to see prices |
|
|
A34 |
28P119
|
Oil Seal
| 1 | Log in to see prices |
|
|
A35 |
378811
|
Back-Up Plate
| 1 | Log in to see prices |
|
|
A36 |
378849
|
Snap Ring
| 1 | Log in to see prices |
|
|
A37 |
378430-10
|
Capscrew, Hex Head (.312"-18 X 1") Assemblies 4 & 6, Open End
| 4 | Log in to see prices |
|
|
|
378430-12
|
Capscrew, Hex Head (.312"-18 X 1.250") Assemblies 3 & 5, Closed End
| 4 | Log in to see prices |
|
|
A38 |
378430-10
|
Capscrew, Hex Head (.312"-18 X 1") Assemblies 3 & 5, Open End
| 4 | Log in to see prices |
|
|
|
378430-12
|
Capscrew, Hex Head (.312"-18 X 1.250") Assemblies 4 & 6, Closed End
| 4 | Log in to see prices |
|
|
A39 |
28P171
|
O-Ring, Speed Sensor
| 1 | Log in to see prices |
|
|
A40 |
379243
|
Speed Sensor (Transducer) Included W/Electronic Overspeed Control
| 1 | Log in to see prices |
|
|
A41 |
379242
|
Adapter Plug With E.O.C.
| 1 | Log in to see prices |
|
|
Or |
379242
|
Adapter Plug Without E.O.C.
| 2 | Log in to see prices |
|
|
A42 |
379231
|
Pipe Plug (.125"-27 N.P.T.F.) With E.O.C.
| 1 | Log in to see prices |
|
|
Or |
379231
|
Pipe Plug (.125"-27 N.P.T.F.) Without E.O.C.
| 2 | Log in to see prices |
|
|
|
328951-6X
|
Mounting Gasket & Installation Instructions
| 1 | Log in to see prices |
|
|
A43 |
35P41
|
Gasket, Mounting
| 1 | Log in to see prices |
|
|
|
328170-101X
|
Mounting Parts Kit (Items 44 Thru 47)
| 1 | Log in to see prices |
|
|
A44 |
379457-13
|
Shoulder Stud (.375"-16 & .375"-24; "1.75")
| 1 | Log in to see prices |
|
|
N.S. |
379423-14
|
Stud (.375"-16 & .375"-24; "1.75")
| 2 | Log in to see prices |
|
|
A45 |
379423-16
|
Stud (.375"-16 & .375"-24; "1.875")
| 2 | Log in to see prices |
|
|
N.S. |
379224
|
Tab-Lock Washer
| 1 | Log in to see prices |
|
|
A46 |
379774
|
Flange Nut (.375"-24)
| 5 | Log in to see prices |
|
|
A47 |
378935
|
Capscrew (.375"-16 X 3 .250")
| 1 | Log in to see prices |
|
|
Or |
328170-205X
|
Mounting Parts Kit, Aisin A445 Only
| 1 | Log in to see prices |
|
|
Or |
7170-87X
|
Mounting Parts Kit, Jatco 270J
| 1 | Log in to see prices |
|
|
Or |
7170-103X
|
Mounting Parts Kit, Allison 1000, 2000/2400
| 1 | Log in to see prices |
|
|
N.S. |
379111
|
Square Key (“XX” Output)
| 1 | Log in to see prices |
|
|
Or A48 |
500007-29
|
Woodruff Key
| 1 | Log in to see prices |
|
|
A49 |
328075X
|
Pressure Lube Hose, Allison
| 1 | Log in to see prices |
|
|
|
329087X
|
Pressure Lube Hose, Jatco 270J
| 1 | Log in to see prices |
|
|
A50 |
378840
|
Street Tee, Allison At Series
| 1 | Log in to see prices |
|
|
|
378970
|
Street Tee, Allison Mt Series 1975 & After
| 1 | Log in to see prices |
|
|
|
378880
|
Street Tee, Allison Mt Series 1974 & Before
| 1 | Log in to see prices |
|
|
|
378897
|
Street Tee, Allison Clt, Clbt & Ht Series
| 1 | Log in to see prices |
|
|
N.S. |
329049X
|
Fitting Kit, Jatco
| 1 | Log in to see prices |
|
|
N.S. |
329297X
|
Fitting Kit, Allison 1000, 2000/2400 (High Pressure Port)
| 1 | Log in to see prices |
|
|
N.S. |
329246X
|
Fitting Kit, Aisin
| 1 | Log in to see prices |
|
|
|
328748X
|
Pump Mounting Kit (“XR” Output Only)
| 1 | Log in to see prices |
|
|
 |
