| Item No. |
Part Number |
Name | Qty | Price |
Buy |
|
| B1 |
1P591
|
Housing Ass'y 3 (Includes Item # 11)
| 1 | Log in to see
prices |
|
|
| B2 |
560972
|
Needle Bearing
| 1 | Log in to see
prices |
|
|
| B3 |
550439
|
Tapered Bearing Cone
| 2 | Log in to see
prices |
|
|
| B5 |
14P74-1
|
Spacers (.112 - .114)
| A.R. | Log in to see
prices |
|
|
|
14P74-2
|
Spacers (.115 - .117)
| A.R. | Log in to see
prices |
|
|
|
14P74-3
|
Spacers (.118 - .120)
| A.R. | Log in to see
prices |
|
|
|
14P74-4
|
Spacers (.121 - .123)
| A.R. | Log in to see
prices |
|
|
|
14P74-5
|
Spacers (.124 - .126)
| A.R. | Log in to see
prices |
|
|
| B6 |
28P191
|
O-Ring
| 1 | Log in to see
prices |
|
|
| B7 |
9P91
|
Idler Shaft, Pressure Lube
| 1 | Log in to see
prices |
|
|
| B8 |
379672
|
NWD Plug
| 1 | Log in to see
prices |
|
|
| B9 |
9P102
|
Thrust Washer
| 1 | Log in to see
prices |
|
|
| B11 |
500597-16
|
Slotted Pin
| 1 | Log in to see
prices |
|
|
|
329352-12X
|
Valve And Valve Cap Assembly (12 Volt)
| 1 | Log in to see
prices |
|
|
|
329352-24X
|
Valve And Valve Cap Assembly (24 Volt)
| 1 | Log in to see
prices |
|
|
| B12 |
28P193
|
Assemblies Include Items 12 Thru 19 Block Ring
| 1 | Log in to see
prices |
|
|
| B13 |
329144X
|
Valve Cap Assembly (12 Volt)
| 1 | Log in to see
prices |
|
|
|
329144-1X
|
Valve Cap Assembly (24 Volt)
| 1 | Log in to see
prices |
|
|
| B14 |
379604-1
|
Solenoid Valve (12 Volt)
| 1 | Log in to see
prices |
|
|
|
379604-2
|
Solenoid Valve (24 Volt)
| 1 | Log in to see
prices |
|
|
| B15 |
34P278
|
Valve Cover
| 1 | Log in to see
prices |
|
|
| B16 |
379565
|
Hex Capscrew (.250"-20 X .750")
| 4 | Log in to see
prices |
|
|
| B17 |
28P119
|
Oil Seal
| 1 | Log in to see
prices |
|
|
| B18 |
378811
|
Washer
| 1 | Log in to see
prices |
|
|
| B19 |
378849
|
Retaining Ring
| 1 | Log in to see
prices |
|
|
| B20 |
22P112
|
Gasket, Valve Cover
| 1 | Log in to see
prices |
|
|
| B21 |
378447-6
|
Socket Head Capscrew (.312"-18 X 1.000")
| 3 | Log in to see
prices |
|
|
| B22 |
14P49
|
Output Shaft & Clutch Assembly (Includes Items 22 Thru 34) Spacer
| 1 | Log in to see
prices |
|
|
| B23 |
379746
|
Retaining Ring
| 1 | Log in to see
prices |
|
|
| B25 |
2P858
|
Clutch Gear
| 1 | Log in to see
prices |
|
|
| B26 |
379485
|
Friction Disc
| 8 | Log in to see
prices |
|
|
| B27 |
379595
|
Clutch Plate
| 7 | Log in to see
prices |
|
|
| B28 |
28P244
|
O-Ring
| 2 | Log in to see
prices |
|
|
| B29 |
37P39
|
Return Spring
| 1 | Log in to see
prices |
|
|
|
328895X
|
Piston & Cylinder Assembly (Includes Items 30-32)
| 1 | Log in to see
prices |
|
|
| B30 |
28P121
|
Block Vee Ring
| 1 | Log in to see
prices |
|
|
|
328676X
|
Piston Assembly (Includes Items 31 And 32)
| | Log in to see
prices |
|
|
| B31 |
379133
|
Piston
| 1 | Log in to see
prices |
|
|
| B32 |
378856
|
Wiggler Wire
| 1 | Log in to see
prices |
|
|
| B33 |
378760
|
Clutch Back Up Cylinder
| 1 | Log in to see
prices |
|
|
| B34 |
378576
|
Retaining Ring
| 1 | Log in to see
prices |
|
|
|
329005-11X / 12X
|
“B” Ratio / “B” Ratio Super Torque
| | Log in to see
prices |
|
|
|
329005-1X / 6X
|
“D” Ratio / “D” Ratio Super Torque
| | Log in to see
prices |
|
|
|
329005-2X / 7X
|
“G” Ratio / “G” Ratio Super Torque
| | Log in to see
prices |
|
|
|
329005-13X / 15X
|
“M” Ratio / “M” Ratio Super Torque
| | Log in to see
prices |
|
|
|
329005-14X / 16X
|
“S” Ratio / “S” Ratio Super Torque
| | Log in to see
prices |
|
|
|
329005-5X / 10X
|
“T” Ratio / “T” Ratio Super Torque
| | Log in to see
prices |
|
|
| B36 |
560972
|
Needle Bearing
| 1 | Log in to see
prices |
|
|
| B37 |
31P70
|
Thrust Washer
| 1 | Log in to see
prices |
|
|
| B38 |
379746
|
Retaining Ring
| 1 | Log in to see
prices |
|
|
| B39 |
4P147
|
Spacer, Drive Shaft
| 1 | Log in to see
prices |
|
|
| B40 |
550010
|
Ball Bearing
| 1 | Log in to see
prices |
|
|
| B42 |
378895
|
Retaining Ring
| 1 | Log in to see
prices |
|
|
| B43 |
378576
|
Retaining Ring
| 1 | Log in to see
prices |
|
|
| B44 |
28P225
|
Oil Seal
| 1 | Log in to see
prices |
|
|
| B45 |
500007-29
|
Woodruff Key
| 1 | Log in to see
prices |
|
|
| B46 |
22P101
|
Gasket, Bearing Cap
| 1 | Log in to see
prices |
|
|
| B47 |
378447-8
|
Socket Head Capscrew (.312"-18 X 1.500")
| 4 | Log in to see
prices |
|
|
| B48 |
379659
|
Run Tee, Pressure Lube Only
| 1 | Log in to see
prices |
|
|
| B49 |
379660
|
Steel Tubing, Pressure Lube Only
| 1 | Log in to see
prices |
|
|
| B50 |
379231
|
Pipe Plug .125"-27 NPTF, W/O E.O.C. Only
| 1 | Log in to see
prices |
|
|
| B51 |
379242
|
O-Ring Boss Plug, W/O E.O.C. Only
| 1 | Log in to see
prices |
|
|
| B52 |
28P171
|
O-Ring, W/ E.O.C. Only
| 1 | Log in to see
prices |
|
|
| B53 |
379243
|
Speed Sensor, W/ E.O.C. Only
| 1 | Log in to see
prices |
|
|
| B54 |
379502
|
Pressure Switch Assembly
| 1 | Log in to see
prices |
|
|
| B55 |
379486
|
Straight Thread Connector 90°
| 1 | Log in to see
prices |
|
|
| B56 |
35P74
|
Mounting Gasket
| 1 | Log in to see
prices |
|
|
|
7170-107X
|
Stud Kit (Includes Items 57 And 58)
| 1 | Log in to see
prices |
|
|
| B57 |
379428-18
|
Stud, M10-1.5 & .375-24 X 2.000
| 2 | Log in to see
prices |
|
|
| B58 |
379453-10
|
Ferry Capscrew (M10-1.5 X 35mm)
| 8 | Log in to see
prices |
|
|
| N.S. |
379486
|
90° Elbow Fitting w/ O-Ring
| 1 | Log in to see
prices |
|
|
| N.S. |
379744
|
Flange Nut, .375-24
| 2 | Log in to see
prices |
|
|
 |
