| Item No. |
Part Number |
Name | Remarks | Carrier | Qty | Price |
Buy |
|
| 43 |
NTN JM515610
|
Cup - rear side gear bearing
| Incl. in KITS RR380, RP380 & RP180 1625 | All | 1 | Log in to see
prices |
|
|
| 44 |
NTN JM515649
|
Cone - rear side gear bearing
| Incl. in KITS RR380, RP380 & RP180 1625 | All | 1 | Log in to see
prices |
|
|
| 45 |
MER 2234F890
|
Side gear - inter-axle differential rear
| Incl. in KITS RR380, RP380 & RP180 1625 | All | 1 | Log in to see
prices |
|
|
| 46, 47, 48, 49 |
MER A1-3235X1532
|
Case assembly - inter-axle differential
| | All | 1 | Log in to see
prices |
|
|
| 46, 47, 48, 49, 50, 51, 52 |
MER A-3235X1532
|
Case & nest assembly - inter-axle differential
| | All | 1 | Log in to see
prices |
|
|
| 47 |
S-2626-2
|
Bolt - inter-axle differential case
| | All | 8 | Log in to see
prices |
|
|
| 48 |
MER 1229K1597
|
Washer - inter-axle differential case
| | All | 16 | Log in to see
prices |
|
|
| 49 |
NL-26-1
|
Nut - inter-axle differential case
| | All | 8 | Log in to see
prices |
|
|
| 50 |
1229Q2929QG
|
Thrust washer - inter-axle pinion
| Incl. in KITS 2421, 2422, RP180 1625 & RP380 | All | 4 | Log in to see
prices |
|
|
| 51 |
2233K245QG
|
Gear - inter-axle pinion
| Incl. in KITS 2421, 2422, RP180 1625 & RP380 | All | 4 | Log in to see
prices |
|
|
| 52 |
3278N300QG
|
Spider (cross) - inter-axle differential
| | All | 1 | Log in to see
prices |
|
|
| 53 |
MER 3892W4963
|
Helical drive & forward side gear
| forward-rear | RP-xx-180 carriers | 1 | Log in to see
prices |
|
|
| 53 |
MER 3892Y4965
|
Helical drive & forward side gear
| forward-rear | RP-xx-380 carriers | 1 | Log in to see
prices |
|
|
| 53 |
3892-M-5213
|
Helical drive & forward side gear
| forward-rear .756 overdrive | RP-180/380 | 1 | Log in to see
prices |
|
|
| 54 |
MER 1229L2742
|
Thrust washer - helical drive gear
| Incl. in KITS 2421, 2422, RP180 1625 & RP380 | All | 1 | Log in to see
prices |
|
|
| 55 |
MER A1-3297N1288
|
Input shaft, nut, ball & pin assembly
| | All after 11/93 | 1 | Log in to see
prices |
|
|
| 55 |
MER A1-3297K115
|
Input shaft, nut, ball & pin assembly
| | All prior to 11/93 | 1 | Log in to see
prices |
|
|
| 56 |
KIT 2268
|
Roll pin - shift fork
| | All prior to 11/93 | 1 | Log in to see
prices |
|
|
| 57 |
MER 3296Q1187
|
Shift fork - inter-axle differential
| | All after 11/93 | 1 | Log in to see
prices |
|
|
| 57 |
MER 3296L90
|
Shift fork - inter-axle differential
| | All prior to 11/93 | 1 | Log in to see
prices |
|
|
| 58 |
MER 3107P16
|
Clutch collar - inter-axle differential
| | All | 1 | Log in to see
prices |
|
|
| 59 |
MER S-2812-2
|
Adjusting screw - shift shaft
| | All | 1 | Log in to see
prices |
|
|
| 60 |
N-68-1
|
Jam nut - adjusting screw
| | All | 1 | Log in to see
prices |
|
|
| 61 |
NTN HM813844
|
Forward Carrier W Iad & Pump -
| Incl. in KITS 4440, RP180 1625 & RP380 | All | 1 | Log in to see
prices |
|
|
| 62 |
KOY HM813810
|
Forward Carrier W Iad & Pump -
| Incl. in KITS 4440, RP180 1625 & RP380 | All | 1 | Log in to see
prices |
|
|
| 63 |
MER 2203C6607
|
e .003"/.076mm
| Incl. in KIT 1573 & 2432 | All prior to 11/93 | Use as req. | Log in to see
prices |
|
|
| 63 |
MER 2203K9241
|
e .003" /.076Mm
| Incl. in KIT 2885 & 2886 | All after 11/93 | Use as req. | Log in to see
prices |
|
|
| 63 |
MER 2203D6608
|
e .005" /.127Mm
| Incl. in KIT 1573 & 2432 | All prior to 11/93 | Use as req. | Log in to see
prices |
|
|
| 63 |
MER 2203L9242
|
e .005" /.127Mm
| Incl. in KIT 2885 & 2886 | All after 11/93 | Use as req. | Log in to see
prices |
|
|
| 63 |
MER 2203E6609
|
e .010" /.254Mm
| Incl. in KIT 1573 & 2432 | All prior to 11/93 | Use as req. | Log in to see
prices |
|
|
| 63 |
MER 2203M9243
|
e .010" /.254Mm
| Incl. in KIT 2885 & 2886 | All after 11/93 | Use as req. | Log in to see
prices |
|
|
| 64, 62 |
MER A-3226H1126
|
nput
| | All after 11/93 | 1 | Log in to see
prices |
|
|
| 64, 62 |
MER A3226J790
|
nput
| | All prior to 11/93 | 1 | Log in to see
prices |
|
|
| 64A |
MER 2297U5273
|
Forward Carrier W Iad & Pump -
| | All after to 11/93 | 1 | Log in to see
prices |
|
|
| 64B |
MER 2258Z1118
|
lve
| | All after 11/93 | 1 | Log in to see
prices |
|
|
| 64C |
MER 1229F4062
|
Forward Carrier W Iad & Pump -
| | 11/93 thru 5/97 | 1 | Log in to see
prices |
|
|
| 64D |
MER 1250N1080
|
Forward Carrier W Iad & Pump -
| | 11/93 thru 5/97 | 1 | Log in to see
prices |
|
|
| 65 |
MER 1229C1511
|
Forward Carrier W Iad & Pump -
| | All after 11/93 | 7 | Log in to see
prices |
|
|
| 65 |
MER 1229C1511
|
Forward Carrier W Iad & Pump -
| | All prior to 11/93 | 6 | Log in to see
prices |
|
|
| 66 |
S-2814-A2
|
Forward Carrier W Iad & Pump -
| | All after 11/93 | 7 | Log in to see
prices |
|
|
| 66 |
10-X-1669
|
Forward Carrier W Iad & Pump -
| | All prior to 11/93 | 6 | Log in to see
prices |
|
|
| 67 |
MER A1-1205X2728
|
Forward Carrier W Iad & Pump -
| | RP-180/380 | 1 | Log in to see
prices |
|
|
| 70 |
MER 1229N1730
|
Washer - input yoke & shaft
| | All | 1 | Log in to see
prices |
|
|
| 71 |
1227D940QG
|
Nut - input yoke & shaft
| Incl. in KITS RP180 1625 & RP380 | All | 1 | Log in to see
prices |
|
|
| 72 |
3266-M-1313
|
Cover assembly - helical gear
| Direct drive (1:1) & Reduction (1.48:1) | All after 11/93 | 1 | Log in to see
prices |
|
|
| 72 |
3266-Q-1317
|
Cover assembly - helical gear
| Overdrive (.756:1) | All after 11/93 | 1 | Log in to see
prices |
|
|
| 72 |
KIT 2679
|
Cover assembly - helical gear
| Updates to current design overdrive (.756:1) | All prior to 11/93 | 1 | Log in to see
prices |
|
|
| 72 |
KIT 2678
|
Cover assembly - helical gear
| Updates to current design direct drive (1:1) & Reduction (1.48:1) | All prior to 11/93 | 1 | Log in to see
prices |
|
|
| 73 |
MER 1229C1511
|
Washer - gear cover to carrier
| | All | 14 | Log in to see
prices |
|
|
| 74 |
MER S-2812-2
|
Capscrew - gear cover to carrier
| | All | 14 | Log in to see
prices |
|
|
| 75 |
MER 2258U411
|
Spring - shift shaft return
| | All | 1 | Log in to see
prices |
|
|
| 76 |
MER KIT2825
|
Shift shaft - inter-axle differential
| | All after 11/93 | 1 | Log in to see
prices |
|
|
| 76 |
MER 2297X2494
|
Shift shaft - inter-axle differential
| | All prior to 11/93 | 1 | Log in to see
prices |
|
|
| 77 |
MER KIT2825
|
Shift assembly - inter-axle differential air
| | All after 11/93 | 1 | Log in to see
prices |
|
|
| 77 |
MER KIT2266
|
Shift assembly - inter-axle differential air
| | All prior to 11/93 | 1 | Log in to see
prices |
|
|
| 78 |
10-X-1334
|
Capscrew - air shift assembly
| | All prior to 11/93 | 4 | Log in to see
prices |
|
|
| 79 |
S-256P-2
|
Capscrew - filter shield
| | All prior to 11/93 | 2 | Log in to see
prices |
|
|
| 80 |
MER 1229E1669
|
Washer - filter shield
| | All prior to 11/93 | 2 | Log in to see
prices |
|
|
| 81 |
MER 3264N1522
|
Shield - oil filter
| | All after 11/93 | 1 | Log in to see
prices |
|
|
| 81 |
MER A-3280F8430
|
Shield - oil filter
| | All prior to 11/93 | 1 | Log in to see
prices |
|
|
| 82 |
MER A-3380W1687
|
Filter - oil
| | All after 11/93 | 1 | Log in to see
prices |
|
|
| 82 |
FL 10
|
Filter - oil
| | All prior to 11/93 | 1 | Log in to see
prices |
|
|
| 83 |
S-2616-2
|
Capscrew - oil pump
| Long | All prior to 11/93 | 1 | Log in to see
prices |
|
|
| 83 |
S-2610-2
|
Capscrew - oil pump
| Short | All prior to 11/93 | 6 | Log in to see
prices |
|
|
| 83 |
MS-208045-1
|
Capscrew - oil pump
| | All after 11/93 | 6 | Log in to see
prices |
|
|
| 84 |
MER 1229E1669
|
Washer - oil pump
| | All after 11/93 | 6 | Log in to see
prices |
|
|
| 84 |
MER 1229K1597
|
Washer - oil pump
| | All prior to 11/93 | 7 | Log in to see
prices |
|
|
| 85 |
MER A-3303P1030
|
Oil pump assembly
| forward-rear | All after 11/93 | 1 | Log in to see
prices |
|
|
| 85 |
MER A1-3303L12
|
Oil pump assembly
| forward-rear | All prior to 11/93 | 1 | Log in to see
prices |
|
|
| 85A |
MER 5X1034
|
O-ring - pump assembly
| | All after 11/93 | 2 | Log in to see
prices |
|
|
| 86 |
3892-V-4936
|
Gear - pump driven
| | All prior to 11/93 | 1 | Log in to see
prices |
|
|
| 87 |
MER S-2510-2
|
Capscrew - filter adapter
| | All prior to 11/93 | 2 | Log in to see
prices |
|
|
| 88 |
MER 1229E1669
|
Washer - filter adapter
| | All prior to 11/93 | 2 | Log in to see
prices |
|
|
| 89 |
MER 2297Z5278
|
Adapter - oil filter
| | All after 11/93 | 1 | Log in to see
prices |
|
|
| 89 |
MER 2297E2293
|
Adapter - oil filter
| | All prior to 11/93 | 1 | Log in to see
prices |
|
|
| 90 |
P-16
|
Plug - gear cover
| | All prior to 11/93 | 1 | Log in to see
prices |
|
|
| 91 |
3780-R-382
|
O-ring - oil tube to gear cover
| | All prior to 11/93 | 1 | Log in to see
prices |
|
|
| 92 |
MER A-2297D5334
|
Tube - gear cover oil
| | All after 11/93 | 1 | Log in to see
prices |
|
|
| 92 |
MER 3196B28
|
Tube - gear cover oil
| | All prior to 11/93 | 1 | Log in to see
prices |
|
|
| 93 |
1246-Q-615
|
Pin - oil restriction (not shown)
| | All prior to 11/93 | 1 | Log in to see
prices |
|
|
| 94 |
NL-210-1
|
Nut - pump idler shaft
| | All prior to 11/93 | 1 | Log in to see
prices |
|
|
| 95 |
MER A-1228Z572
|
Bearing assembly - pump idler gear
| | All prior to 11/93 | 1 | Log in to see
prices |
|
|
| 96 |
2297-L-5420
|
Shaft - pump idler gear
| | All prior to 11/93 | 1 | Log in to see
prices |
|
|
| 97 |
MER 3892W4937
|
Gear - pump idler drive
| | All prior to 11/93 | 1 | Log in to see
prices |
|
|
| 98 |
1829-J-738
|
Washer - pump idler shaft
| | All prior to 11/93 | 1 | Log in to see
prices |
|
|
| 99, 115 |
NTO A3297M117
|
Input shaft & nut assembly
| forward-rear | RN-xx-380 carriers | 1 | Log in to see
prices |
|
|
| 99, 115 |
A-3297-S-97
|
Input shaft & nut assembly
| rear-rear | RR-xx-380 carriers | 1 | Log in to see
prices |
|
|
| 100 |
KOY 29685
|
Cones - input shaft bearing Inner
| | All | 1 | Log in to see
prices |
|
|
| 100 |
KOY 496
|
Cones - Input Shaft Bearing Outer
| | All | 1 | Log in to see
prices |
|
|
| 101 |
KOY 29620
|
Cups - Input Shaft Bearing Inner
| | All | 1 | Log in to see
prices |
|
|
| 101 |
KOY 493
|
Cups - Input Shaft Bearing Outer
| | All | 1 | Log in to see
prices |
|
|
| 102 |
3221-H-8
|
Oil scoop - helical gear cover
| | All | 1 | Log in to see
prices |
|
|
| 103, 101, 102 |
A1-3266-B-834
|
Cover assembly - helical gear
| | All except rear-rear with pump | 1 | Log in to see
prices |
|
|
| 103, 101, 102, 116, 117, 118, 119, 120, 127, 128, 129 |
A-3266-L-792
|
Cover assembly - helical gear
| | RR-xx-380 carrier (rear-rear) with oil pump | 1 | Log in to see
prices |
|
|
| 104 |
MER 1229C1511
|
Washer - Gear Cover To Carrier
| | All | 14 | Log in to see
prices |
|
|
 |
