| Item No. |
Part Number |
Name | Remarks | Carrier | Qty | Price |
Buy |
|
| 130 |
KIT2638QG
|
Nut - drive pinion
| | All | 1 | Log in to see
prices |
|
|
| 130A |
MER 1229N1730
|
Washer - pinion nut
| | All | 1 | Log in to see
prices |
|
|
| 132 |
3264-P-172
|
Deflector - input yoke
| Incl. in KIT 2826 | All | 1 | Log in to see
prices |
|
|
| 133 |
A1205Q2591QG
|
Oil seal - pinion bearing cage assy
| | ALL | 1 | Log in to see
prices |
|
|
| 134 |
KOY H715334
|
Cone - drive pinion outer bearing
| | ALL | 1 | Log in to see
prices |
|
|
| 135 |
KOY H715311
|
Cup - drive pinion outer bearing
| | All | 1 | Log in to see
prices |
|
|
| 136 |
41-X-1043
|
Capscrew - pinion bearing cage
| | 1381 | 8 | Log in to see
prices |
|
|
| 136 |
MER MS212045-1
|
Capscrew - pinion bearing cage
| | All others | 8 | Log in to see
prices |
|
|
| 137 |
MER 1229D4632
|
Washer - pinion bearing cage
| | 1899 | 8 | Log in to see
prices |
|
|
| 137 |
MWA-512
|
Washer - pinion bearing cage
| | All others | 8 | Log in to see
prices |
|
|
| 138,135,141 |
A-3226-V-1010
|
Pinion bearing cage assembly
| | 1752 & 1753 | 1 | Log in to see
prices |
|
|
| 138,135,141 |
MER A-3226B860
|
Pinion bearing cage assembly
| | All Except 1752 & 1753 | 1 | Log in to see
prices |
|
|
| 139 |
MER 2803Y2755
|
Shims - pinion bearing cage .003" /.075mm
| | All | Use As Required | Log in to see
prices |
|
|
| 139 |
MER 2803Z2756
|
Shims - pinion bearing cage .005" /.125mm
| | All | Use As Required | Log in to see
prices |
|
|
| 139 |
MER 2803A2757
|
Shims - pinion bearing cage .008" /.200mm
| | All | Use As Required | Log in to see
prices |
|
|
| 139 |
MER 2803B2758
|
Shims - pinion bearing cage .020" /.500mm
| | All | Use As Required | Log in to see
prices |
|
|
| 140 |
MER 2803D2500
|
Spacers - pinion bearing .250" /6.35mm
| Incl. In KIT 1593 | All | Use 2 As Required | Log in to see
prices |
|
|
| 140 |
MER 2803E2501
|
Spacers - pinion bearing .251" /6.38mm
| Incl. In KIT 1593 | All | Use 2 As Required | Log in to see
prices |
|
|
| 140 |
MER 2803F2502
|
Spacers - pinion bearing .252" /6.40mm
| Incl. In KIT 1593 | All | Use 2 As Required | Log in to see
prices |
|
|
| 140 |
MER 2803N2510
|
Spacers - pinion bearing .254" /6.45mm
| Incl. In KIT 1593 | All | Use 2 As Required | Log in to see
prices |
|
|
| 140 |
MER 2803H2504
|
Spacers - pinion bearing .256" /6.50mm
| Incl. In KIT 1593 | All | Use 2 As Required | Log in to see
prices |
|
|
| 140 |
MER 2803J2506
|
Spacers - pinion bearing .260" /6.60mm
| Incl. In KIT 1593 | All | Use 2 As Required | Log in to see
prices |
|
|
| 140 |
MER 2803K2507
|
Spacers - pinion bearing 261" /6.63mm
| Incl. In KIT 1593 | All | Use 2 As Required | Log in to see
prices |
|
|
| 140 |
MER 2803L2508
|
Spacers - pinion bearing .262" /6.65mm
| Incl. In KIT 1593 | All | Use 2 As Required | Log in to see
prices |
|
|
| 140 |
MER 2803M2509
|
Spacers - pinion bearing .263" /6.68mm
| Incl. In KIT 1593 | All | Use 2 As Required | Log in to see
prices |
|
|
| 140 |
2803-P-2512
|
Spacers - pinion bearing .264" /6.70mm
| Incl. In KIT 1593 | All | Use 2 As Required | Log in to see
prices |
|
|
| 141 |
NTN 9220
|
Cup - drive pinion inner bearing
| | All | 1 | Log in to see
prices |
|
|
| 142 |
NTN 9278
|
Cone - drive pinion inner bearing
| | All | 1 | Log in to see
prices |
|
|
| 140,130 |
B-41592-1
|
Drive gear, pinion & nut assembly 2.93 ratio
| Use KIT 2608 Bolt Kit With These Gearsets | All 180/185/186 Series Rear-Rear Carriers (Except 3.73-4.30 Ratios In 1752 & 1753 Carriers | 1 | Log in to see
prices |
|
|
| 140,130 |
B-41806-1
|
Drive gear, pinion & nut assembly 3.07 ratio
| Use KIT 2608 Bolt Kit With These Gear Sets | All 180/185/186 Series Rear-Rear Carriers(Except 3.73-4.30 Ratios In 1752 & 1753 Carriers | 1 | Log in to see
prices |
|
|
| 140,130 |
MER B-41026-3
|
Drive gear, pinion & nut assembly 3.21 ratio
| Use KIT 2608 bolt kit with these gearsets | All 180/185/186 series rear-rear carriers(except 3.73-4.30 ratios in 1752 & 1753 carriers) | 1 | Log in to see
prices |
|
|
| 143,130 |
B-41004-3
|
Drive gear, pinion & nut assembly 3.42 ratio
| Use KIT 2608 bolt kit with these gearsets | All 180/185/186 series rear-rear carriers(except 3.73-4.30 ratios in 1752 & 1753 carriers) | 1 | Log in to see
prices |
|
|
| 143,130 |
B-41030-3
|
Drive gear, pinion & nut assembly 3.58 ratio
| Use KIT 2608 bolt kit with these gearsets | All 180/185/186 series carriers(except 3.73-4.30 ratios in 1752 & 1753 carriers) | 1 | Log in to see
prices |
|
|
| 143,130 |
B-41016-3
|
Drive gear, pinion & nut assembly 3.73 ratio
| Use KIT 2608 bolt kit with these gearsets | All 180/185/186 series carriers(except 3.73-4.30 ratios in 1752 & 1753 carriers) | 1 | Log in to see
prices |
|
|
| 143,130 |
B-41006-3
|
Drive gear, pinion & nut assembly 3.91 ratio
| Use KIT 2608 bolt kit with these gearsets | All 180/185/186 series carriers(except 3.73-4.30 ratios in 1752 & 1753 carriers) | 1 | Log in to see
prices |
|
|
| 143,130 |
B-41018-3
|
Drive gear, pinion & nut assembly 4.10 ratio
| Use KIT 2608 bolt kit with these gearsets | All 180/185/186 series carriers(except 3.73-4.30 ratios in 1752 & 1753 carriers) | 1 | Log in to see
prices |
|
|
| 143,130 |
B-41014-3
|
Drive gear, pinion & nut assembly 4.30 ratio
| Use KIT 2608 bolt kit with these gearsets | All 180/185/186 series carriers(except 3.73-4.30 ratios in 1752 & 1753 carriers) | 1 | Log in to see
prices |
|
|
| 143,130 |
B-41008-3
|
Drive gear, pinion & nut assembly 4.56 ratio
| Use KIT 2608 bolt kit with these gearsets | All 180/185/186 series carriers(except 3.73-4.30 ratios in 1752 & 1753 carriers) | 1 | Log in to see
prices |
|
|
| 143,130 |
B-41034-3QG
|
Drive gear, pinion & nut assembly 4.89 ratio
| Use KIT 2608 bolt kit with these gearsets | All 180/185/186 series carriers(except 3.73-4.30 ratios in 1752 & 1753 carriers) | 1 | Log in to see
prices |
|
|
| 143,130 |
B-41010-3
|
Drive gear, pinion & nut assembly 5.13 ratio
| Use KIT 2608 bolt kit with these gearsets | All 180/185/186 series carriers(except 3.73-4.30 ratios in 1752 & 1753 carriers) | 1 | Log in to see
prices |
|
|
| 143,130 |
B-41028-3QG
|
Drive gear, pinion & nut assembly 5.38 ratio
| Use KIT 2608 bolt kit with these gearsets | All 180/185/186 series carriers(except 3.73-4.30 ratios in 1752 & 1753 carriers) | 1 | Log in to see
prices |
|
|
| 143,130 |
MER B-41032-3
|
Drive gear, pinion & nut assembly 5.63 ratio
| Use KIT 2608 bolt kit with these gearsets | All 180/185/186 series carriers(except 3.73-4.30 ratios in 1752 & 1753 carriers) | 1 | Log in to see
prices |
|
|
| 143,130 |
B-41012-3
|
Drive gear, pinion & nut assembly 5.86 ratio
| Use KIT 2608 bolt kit with these gearsets | All 180/185/186 series carriers(except 3.73-4.30 ratios in 1752 & 1753 carriers) | 1 | Log in to see
prices |
|
|
| 143,130 |
MER B-41036-3
|
Drive gear, pinion & nut assembly 6.14 ratio
| Use KIT 2608 bolt kit with these gearsets | All 180/185/186 series carriers(except 3.73-4.30 ratios in 1752 & 1753 carriers) | 1 | Log in to see
prices |
|
|
| 143,130 |
B-41024-4
|
Drive gear, pinion & nut assembly 6.43 ratio
| Use KIT 2608 bolt kit with these gearsets | All 180/185/186 series carriers(except 3.73-4.30 ratios in 1752 & 1753 carriers) | 1 | Log in to see
prices |
|
|
| 143,130 |
B-41022-1
|
Drive gear, pinion & nut assembly 6.83 ratio
| Use KIT 2608 bolt kit with these gearsets | All 180/185/186 series carriers(except 3.73-4.30 ratios in 1752 & 1753 carriers) | 1 | Log in to see
prices |
|
|
| 143,130 |
MER B-41020-1
|
Drive gear, pinion & nut assembly 7.17 ratio
| Use KIT 2608 bolt kit with these gearsets | All 180/185/186 series carriers(except 3.73-4.30 ratios in 1752 & 1753 carriers) | 1 | Log in to see
prices |
|
|
| 143,130 |
B-41002-1
|
Drive gear, pinion & nut assembly 7.40 ratio
| Use KIT 2608 bolt kit with these gearsets | All 180/185/186 series carriers(except 3.73-4.30 ratios in 1752 & 1753 carriers) | 1 | Log in to see
prices |
|
|
| 143,130 |
B-41650-1
|
Drive gear, pinion & nut assembly 7.83 ratio
| Use KIT 2608 bolt kit with these gearsets | All 180/185/186 series carriers(except 3.73-4.30 ratios in 1752 & 1753 carriers) | 1 | Log in to see
prices |
|
|
| 143,130 |
B-41806-1
|
Drive gear, pinion & nut assembly 3.07 ratio
| | 1752 & 1753 | 1 | Log in to see
prices |
|
|
| 143,130 |
A-40636-1
|
Drive gear, pinion & nut assembly 3.73 ratio
| | 1752 & 1753 | 1 | Log in to see
prices |
|
|
| 143,130 |
A-40638-1
|
Drive gear, pinion & nut assembly 3.91 ratio
| | 1752 & 1753 | 1 | Log in to see
prices |
|
|
| 143,130 |
A-40632-1
|
Drive gear, pinion & nut assembly 4.10 ratio
| | 1752 & 1753 | 1 | Log in to see
prices |
|
|
| 143,130 |
A-40634-1
|
Drive gear, pinion & nut assembly 4.30 ratio
| | 1752 & 1753 | 1 | Log in to see
prices |
|
|
| 144 |
1228-A-261
|
Bearing - drive pinion spigot
| 6.83, 7.17, 7.40, & 7.83 ratios only | All | 1 | Log in to see
prices |
|
|
| 144 |
MER 1228S1267
|
Bearing - drive pinion spigot
| All other ratios | All | 1 | Log in to see
prices |
|
|
| 144A |
MER 1229K1623
|
Snap ring - drive pinion spigot bearing
| 6.83, 7.17, 7.40, & 7.83 ratios only | All | 1 | Log in to see
prices |
|
|
| 144A |
MER 1229L1624
|
Snap ring - drive pinion spigot bearing
| All other ratios | | 1 | Log in to see
prices |
|
|
| 145 |
41-X-1020
|
Screw - thrust
| | 1381 | 1 | Log in to see
prices |
|
|
| 145 |
MER 15X1167
|
Screw - thrust
| | 1752, 1839, 1910 | 1 | Log in to see
prices |
|
|
| 146 |
40-X-1015
|
Nut - thrust screw jam
| | 1381 | 1 | Log in to see
prices |
|
|
| 146 |
MER 1227D472
|
Nut - thrust screw jam
| | 1752, 1839, 1910 | 1 | Log in to see
prices |
|
|
| 147 |
A2-3200-C-1381
|
Differential carrier & cap assembly
| Aluminum | | 1 | Log in to see
prices |
|
|
| 147 |
KIT 2732
|
Differential carrier & cap assembly
| Malleable (Original design) | Less diff. lock (3.07-4.30 ratios) | 1 | Log in to see
prices |
|
|
| 147 |
KIT 2732A
|
Differential carrier & cap assembly
| Less diff. lock (4.56-7.40 ratios) | Malleable (original design) | 1 | Log in to see
prices |
|
|
| 147 |
A2-3200-J-1804
|
Differential carrier & cap assembly
| Malleable less diff. lock | 180 & early 185/186 series | 1 | Log in to see
prices |
|
|
| 147 |
A2-3200-A-1899S
|
Differential carrier & cap assembly
| Malleable with diff. lock | 180 & early 185/186 series | 1 | Log in to see
prices |
|
|
| 147 |
MER A2-3200J1752
|
Differential carrier & cap assembly
| Malleable with or without diff. lock | Current 185/186 series | 1 | Log in to see
prices |
|
|
| 147 |
A2-3200-K-1753
|
Differential carrier & cap assembly
| Malleable with or without diff. lock | Current 185/186 series | 1 | Log in to see
prices |
|
|
| 147 |
KIT 2731
|
Differential carrier & cap assembly
| With diff. lock (3.07-4.30 ratios) | Malleable (original design) | 1 | Log in to see
prices |
|
|
| 147 |
KIT 2731A
|
Differential carrier & cap assembly
| With diff. lock (4.56-7.40 ratios) | Malleable (original design) | 1 | Log in to see
prices |
|
|
| 148 |
42-X-1024
|
Washer - differential bearing cap
| | All | 4 | Log in to see
prices |
|
|
| 149 |
41-X-1037
|
Capscrew - differential bearing cap
| | Aluminum carriers | 4 | Log in to see
prices |
|
|
| 149 |
41-X-1018
|
Capscrew - differential bearing cap
| | Malleable carriers | 4 | Log in to see
prices |
|
|
| 150 |
45-X-1008
|
Plug
| Magnetic | All | Use 1as req. | Log in to see
prices |
|
|
| 150 |
45-X-1003
|
Plug
| plain | All | Use 1 as req. | Log in to see
prices |
|
|
| 151 |
MER 2214W1011
|
Adjusting ring
| Left hand | 1752 & 1753 | 1 | Log in to see
prices |
|
|
| 151 |
MER 2214G1125
|
Adjusting ring
| Left hand (small) 1840, 1899 | All exc. 1752 & 1753 | 1 | Log in to see
prices |
|
|
| 151 |
MER 2214S279
|
Adjusting ring
| Left hand (small) original design | All exc. 1752 & 1753 | 1 | Log in to see
prices |
|
|
| 151 |
MER 2214X1012
|
Adjusting ring
| Right hand | 1752 & 1753 | 1 | Log in to see
prices |
|
|
| 151 |
MER 2214S1137
|
Adjusting ring
| Right hand (large) 1804, 1899 | All exc. 1752 & 1753 | 1 | Log in to see
prices |
|
|
| 151 |
MER 2214Q277
|
Adjusting ring
| Right hand (large) orginal design | All exc. 1752 & 1753 | 1 | Log in to see
prices |
|
|
| 152 |
1199R2176QG
|
Cotter pin - adjusting ring left hand
| | All exc. 1752 & 1753 | 1 | Log in to see
prices |
|
|
| 152 |
MER 43X1015
|
Locking pin - adjusting ring
| | 1752 & 1753 | 1 | Log in to see
prices |
|
|
| 153 |
MER 1220K89
|
Lock - adjusting ring right hand
| | All | 1 | Log in to see
prices |
|
|
| 153A |
MER 43X1015
|
Locking pin - adjusting ring
| | 1752 & 1753 | 1 | Log in to see
prices |
|
|
| 153A |
MER 1246P1134
|
Locking pin - adjusting ring right hand
| | 1899 | 1 | Log in to see
prices |
|
|
| 154 |
MWA-508
|
Washer - adjusting ring lock
| | All | 2 | Log in to see
prices |
|
|
| 155 |
MS-208020-1
|
Capscrew - adjusting ring lock
| | All | 2 | Log in to see
prices |
|
|
| 156 |
MER 3266M897
|
Cover - special carrier
| | | 1 | Log in to see
prices |
|
|
| 156A |
MER 1250U1217
|
Plug
| | 1899 | 1 | Log in to see
prices |
|
|
| 157 |
MER MWA-506
|
Washer - cover
| | Items 156 thru 160 for 1381 & 1399 carriers without diff lock | 4 | Log in to see
prices |
|
|
| 158 |
MER 41X1080
|
Capscrew - cover
| | Items 156 thru 160 for 1381 & 1399 carriers without diff lock | 4 | Log in to see
prices |
|
|
| 159 |
MER 41X1022
|
Plug - special carrier capscrew
| | Items 156 thru 160 for 1381 & 1399 carriers without diff lock | 1 | Log in to see
prices |
|
|
| 160 |
1229U1503QG
|
Washer - plug
| | Items 156 thru 160 for 1381 & 1399 carriers without diff lock | 1 | Log in to see
prices |
|
|
| 161 |
NTN JHM720210
|
Cups - differential bearing LH
| | 1381, 1399, 1539, 1752, & 1753 only | 1 | Log in to see
prices |
|
|
| 161 |
MER KIT2744
|
Cups - differential bearing LH
| | All others | 1 | Log in to see
prices |
|
|
| 161 |
NTN 64700
|
Cups - differential bearing RH
| | 1381, 1399, 1539, 1752 & 1753 only | 1 | Log in to see
prices |
|
|
| 161 |
KOY JM822010
|
Cups - differential bearing RH
| | All others | 1 | Log in to see
prices |
|
|
| 161A |
2297-T-4180
|
Adhesive - bearing cap
| | All | 1 | Log in to see
prices |
|
|
| 162 |
NTN JHM720249
|
Cones - differential bearing LH
| | 1381, 1399, 1539, 1752 & 1753 only | 1 | Log in to see
prices |
|
|
| 162 |
MER KIT2744
|
Cones - differential bearing LH
| | All others | 1 | Log in to see
prices |
|
|
| 162 |
NTN 64450
|
Cones - differential bearing RH
| | 1381, 1399, 1539, 1752 & 1753 | 1 | Log in to see
prices |
|
|
| 162 |
KOY JM822049
|
Cones - differential bearing RH
| | All others | 1 | Log in to see
prices |
|
|
| 163 |
MER 40X1182
|
Nut - differential case to gear
| | All | 16 | Log in to see
prices |
|
|
| 164 |
MER 1229W1557
|
Washer - plug
| | 1899 | 16 | Log in to see
prices |
|
|
| 164 |
1229U1503QG
|
Washer - plug
| | All others | 16 | Log in to see
prices |
|
|
| 165 |
41-X-1358
|
Bolt - differential case to gear
| Used in KIT 1594 | All others | 16 | Log in to see
prices |
|
|
| 165 |
MER 41X1334
|
Bolt - differential case to gear
| Used in KIT 2608 | 1753, 1804, 1899 | 16 | Log in to see
prices |
|
|
| 166, 167, 168, 169, 170, 171, 172, 172A, 173 |
A1-3235-Y-2339
|
Differential case & nest assembly
| 2.93, 3.07, 3.21, 3.42, 3.58 ratios | 1752 & 1753 with or without diff lock (2.35"-46 spline) | 1 | Log in to see
prices |
|
|
| 166, 167, 168, 169, 170, 171, 172, 172A, 173 |
A2-3235-Y-2339
|
Differential case & nest assembly
| 2.93, 3.07, 3.21, 3.42, 3.58 ratios | 1752 & 1753 with or without diff lock (2.56"-50 spline) | 1 | Log in to see
prices |
|
|
| 166, 167, 168, 169, 170, 171, 172, 172A, 173 |
A5-3235-F-1618
|
Differential case & nest assembly
| 2.93, 3.08, 3.21, 3.42, 3.58, 3.91, 4.10, 4.30 ratios | 1381 & 1399 | 1 | Log in to see
prices |
|
|
| 166, 167, 168, 169, 170, 171, 172, 172A, 173 |
A3-3235-K-2143
|
Differential case & nest assembly
| 2.93, 3.08, 3.21, 3.42, 3.58, 3.91, 4.10, 4.30 ratios | 1791 & 1899 with diff lock (2.35-46 spline) | 1 | Log in to see
prices |
|
|
| 166, 167, 168, 169, 170, 171, 172, 172A, 173 |
A7-3235-K-2143
|
Differential case & nest assembly
| 2.93, 3.08, 3.21, 3.42, 3.58, 3.91, 4.10, 4.30 ratios | 1791 & 1899 with diff lock (2.56"-50 spline) | 1 | Log in to see
prices |
|
|
| 166, 167, 168, 169, 170, 171, 172, 172A, 173 |
A2-3235-K-2143
|
Differential case & nest assembly
| 2.93, 3.08, 3.21, 3.42, 3.58, 3.91, 4.10, 4.30 ratios | 1804 less diff lock (2.35"-46 spline) | 1 | Log in to see
prices |
|
|
| 166, 167, 168, 169, 170, 171, 172, 172A, 173 |
A5-3235-K-2143
|
Differential case & nest assembly
| 2.93, 3.08, 3.21, 3.42, 3.58, 3.91, 4.10, 4.30 ratios | 1804 less diff lock (2.56"-50 spline) | 1 | Log in to see
prices |
|
|
| 166, 167, 168, 169, 170, 171, 172, 172A, 173 |
A1-3235-U-2335
|
Differential case & nest assembly
| 3.73, 3.91, 4.10, 4.30 ratios | 1752 & 1753 with or without diff lock(2.35"-46 spline) | 1 | Log in to see
prices |
|
|
| 166, 167, 168, 169, 170, 171, 172, 172A, 173 |
A2-3235-U-2335
|
Differential case & nest assembly
| 3.73, 3.91, 4.10, 4.30 ratios | 1752 & 1753 with or without diff lock (2.56"-50 spline) | 1 | Log in to see
prices |
|
|
| 166, 167, 168, 169, 170, 171, 172, 172A, 173 |
A3-3235-H-1620
|
Differential case & nest assembly
| 4.56, 4.89, 5.13, 5.38, 5.63, 5.86, 6.14, 6.43, 6.83, 7.17, 7.40, 7.83 ratios | 1381 & 1399 | 1 | Log in to see
prices |
|
|
| 166, 167, 168, 169, 170, 171, 172, 172A, 173 |
A1-3235-W-2337
|
Differential case & nest assembly
| 4.56, 4.89, 5.13, 5.38, 5.63, 5.86, 6.14, 6.43, 6.83, 7.17, 7.40, 7.83 ratios | 1752 & 1753 with or without diff lock (2.35"-46 spline) | 1 | Log in to see
prices |
|
|
| 166, 167, 168, 169, 170, 171, 172, 172A, 173 |
A2-3235-W-2337
|
Differential case & nest assembly
| 4.56, 4.89, 5.13, 5.38, 5.63, 5.86, 6.14, 6.43, 6.83, 7.17, 7.40, 7.83 ratios | 1752 & 1753 with or without diff lock (2.56"-50 spline) | 1 | Log in to see
prices |
|
|
| 166, 167, 168, 169, 170, 171, 172, 172A, 173 |
A2-3235-M-2145
|
Differential case & nest assembly
| 4.56, 4.89, 5.13, 5.38, 5.63, 5.86, 6.14, 6.43, 6.83, 7.17, 7.40, 7.83 ratios | 1791 & 1899 with diff lock(2.35"-46 spline) | 1 | Log in to see
prices |
|
|
| 166, 167, 168, 169, 170, 171, 172, 172A, 173 |
A7-3235-M-2145
|
Differential case & nest assembly
| 4.56, 4.89, 5.13, 5.38, 5.63, 5.86, 6.14, 6.43, 6.83, 7.17, 7.40, 7.83 ratios | 1791 & 1899 with diff lock(2.56"-50 spline) | 1 | Log in to see
prices |
|
|
| 166, 167, 168, 169, 170, 171, 172, 172A, 173 |
A3-3235-M-2145
|
Differential case & nest assembly
| 4.56, 4.89, 5.13, 5.38, 5.63, 5.86, 6.14, 6.43, 6.83, 7.17, 7.40, 7.83 ratios | 1804 less diff lock(2.35"-46 spline) | 1 | Log in to see
prices |
|
|
| 166, 167, 168, 169, 170, 171, 172, 172A, 173 |
A5-3235-M-2145
|
Differential case & nest assembly
| 4.56, 4.89, 5.13, 5.38, 5.63, 5.86, 6.14, 6.43, 6.83, 7.17, 7.40, 7.83 ratios | 1804 less diff lock(2.56"-50 spline) | 1 | Log in to see
prices |
|
|
| 166, 172, 172A, 173 |
A-3235-Y-2339
|
Differential case assembly
| 2.93, 3.07, 3.21, 3.42, 3.58 ratios | 1752 & 1753 with or without diff lock | 1 | Log in to see
prices |
|
|
| 166, 172, 172A, 173 |
A-3235-F-1618
|
Differential case assembly
| 2.93, 3.08, 3.21, 3.42, 3.58, 3.91, 4.10, 4.30 ratios | 1381 & 1399 | 1 | Log in to see
prices |
|
|
| 166, 172, 172A, 173 |
MER A1-3235K2143
|
Differential case assembly
| 2.93, 3.08, 3.21, 3.42, 3.58, 3.91, 4.10, 4.30 ratios | 1791 & 1899 with diff lock | 1 | Log in to see
prices |
|
|
| 166, 172, 172A, 173 |
A-3235-K-2143
|
Differential case assembly
| 2.93, 3.08, 3.21, 3.42, 3.58, 3.91, 4.10, 4.30 ratios | 1804 less diff lock | 1 | Log in to see
prices |
|
|
| 166, 172, 172A, 173 |
A-3235-U-2335
|
Differential case assembly
| 3.73, 3.91, 4.10, 4.30 ratios | 1752 & 1753 with or without diff lock | 1 | Log in to see
prices |
|
|
| 166, 172, 172A, 173 |
MER A-3235H1620
|
Differential case assembly
| 4.56, 4.89, 5.13, 5.38, 5.63, 5.86, 6.14, 6.43, 6.83, 7.17, 7.40, 7.83 ratios | 1381 & 1399 | 1 | Log in to see
prices |
|
|
| 166, 172, 172A, 173 |
MER A-3235W2337
|
Differential case assembly
| 4.56, 4.89, 5.13, 5.38, 5.63, 5.86, 6.14, 6.43, 6.83, 7.17, 7.40, 7.83 ratios | 1752 & 1753 with or without diff lock | 1 | Log in to see
prices |
|
|
| 166, 172, 172A, 173 |
MER A-3235M2145
|
Differential case assembly
| 4.56, 4.89, 5.13, 5.38, 5.63, 5.86, 6.14, 6.43, 6.83, 7.17, 7.40, 7.83 ratios | 1791 & 1899 with diff lock | 1 | Log in to see
prices |
|
|
| 166, 172, 172A, 173 |
A1-3235-M-2145
|
Differential case assembly
| 4.56, 4.89, 5.13, 5.38, 5.63, 5.86, 6.14, 6.43, 6.83, 7.17, 7.40, 7.83 ratios | 1804 less diff lock | 1 | Log in to see
prices |
|
|
| 166, 172, 172A, 173, 173A |
A6-3235-F-1618
|
Differential case & NoSPIN assembly
| 2.93, 3.08, 3.21, 3.42, 3.58, 3.91, 4.10, 4.30 ratios | 1381 & 1399 | 1 | Log in to see
prices |
|
|
| 166, 172, 172A, 173, 173A |
A4-3235-K-2143
|
Differential case & NoSPIN assembly
| 2.93, 3.08, 3.21, 3.42, 3.58, 3.91, 4.10, 4.30 ratios | 1804 less diff lock(2.35"-46 spline) | 1 | Log in to see
prices |
|
|
| 166, 172, 172A, 173, 173A |
A5-3235-H-1620
|
Differential case & NoSPIN assembly
| 4.56, 4.89, 5.13, 5.38, 5.63, 5.86, 6.14, 6.43, 6.83, 7.17, 7.40, 7.83 ratios | 1381 & 1399 | 1 | Log in to see
prices |
|
|
| 166, 172, 172A, 173, 173A |
A4-3235-M-2145
|
Differential case & NoSPIN assembly
| 4.56, 4.89, 5.13, 5.38, 5.63, 5.86, 6.14, 6.43, 6.83, 7.17, 7.40, 7.83 ratios | 1804 less diff lock(2.35"-46 spline) | 1 | Log in to see
prices |
|
|
| 166, 172, 172A, 173, 173A |
A6-3235-M-2145
|
Differential case & NoSPIN assembly
| 4.56, 4.89, 5.13, 5.38, 5.63, 5.86, 6.14, 6.43, 6.83, 7.17, 7.40, 7.83 ratios | 1804 less diff lock(2.56"-50 spline) | 1 | Log in to see
prices |
|
|
| 167 |
1229L3002QG
|
Thrust washer - side gear
| | All | 2 | Log in to see
prices |
|
|
| 168 |
2234C1069QG
|
Side gear - differential
| Incl. in KIT 2318 | 2.35"- 46 spline | 2 | Log in to see
prices |
|
|
| 168 |
MER 2234P1004
|
Side gear - differential
| Incl. in KIT 2373 | 2.56"- 50 spline | 2 | Log in to see
prices |
|
|
| 169 |
1229K3001QG
|
Thrust washer - differential pinion
| | All | 4 | Log in to see
prices |
|
|
| 170 |
2233M1001QG
|
Gear - differential pinion
| | All | 4 | Log in to see
prices |
|
|
| 171 |
3278W335QG
|
Spider - differential
| | All | 1 | Log in to see
prices |
|
|
| 172 |
MER 41X1275
|
Capscrew - differential case
| | All others | 12 | Log in to see
prices |
|
|
| 172 |
41-X-1109
|
Capscrew - differential case
| | Thru-bolt design | 4 | Log in to see
prices |
|
|
| 172 |
MER 41X1275
|
Capscrew - differential case
| | Thru-bolt design | 8 | Log in to see
prices |
|
|
| 172A |
2297-C-7049
|
Thread locking liquid
| Use on 172 | All | 1 | Log in to see
prices |
|
|
| 172B |
MER 40X1182
|
Nut
| | 1899 | 4 | Log in to see
prices |
|
|
| 173 |
MER 1229W1557
|
Washer
| | 1899 | 16 | Log in to see
prices |
|
|
| 173 |
1229U1503QG
|
Washer
| | All others | 12 | Log in to see
prices |
|
|
| 173A |
A-3230-C-1043
|
NoSPIN Assembly
| | 2.35"- 46 spline | 1 | Log in to see
prices |
|
|
| 173A |
A-3230-A-1041
|
NoSPIN Assembly
| | 2.56"- 50 spline | 1 | Log in to see
prices |
|
|
| 174 |
MER 3107A1041
|
Shift collar
| 2.35"- 46 spline | 1752 & 1753 | 1 | Log in to see
prices |
|
|
| 174 |
MER 3107L1104
|
Shift collar
| 2.35- 46 spline | All others | 1 | Log in to see
prices |
|
|
| 174 |
MER 3107Z78
|
Shift collar
| 2.37"-46 spline | 1381 & 1399 | 1 | Log in to see
prices |
|
|
| 174 |
3107-V-1010
|
Shift collar
| 2.56"-50 spline | 1752 & 1753 | 1 | Log in to see
prices |
|
|
| 174 |
MER 3107N1106
|
Shift collar
| 2.56"- 50 spline | All others | 1 | Log in to see
prices |
|
|
| 175 |
3296-N-1184
|
Shift fork
| One pc. style | 1381, 1399, 1791 | 1 | Log in to see
prices |
|
|
| 175 |
MER 3296A1197
|
Shift fork
| One pc. style | 1752 & 1753 | 1 | Log in to see
prices |
|
|
| 175 |
MER 3296D1174
|
Shift fork
| One pc. style | 1899 | 1 | Log in to see
prices |
|
|
| 176 |
MER 43X1007
|
Pin - shift fork
| Used with 3 pc. style fork (3296V178) | 1381 & 1399 | 2 | Log in to see
prices |
|
|
| 177 |
MER 2258N1262
|
Spring - shift shaft
| | 1899 | 1 | Log in to see
prices |
|
|
| 177 |
MER 2258L714
|
Spring - shift shaft
| | All others | 1 | Log in to see
prices |
|
|
| 178 |
MER 2244Z52
|
Shift shaft
| | 1752 & 1753 | 1 | Log in to see
prices |
|
|
| 178 |
MER KIT2824
|
Shift shaft
| | 1899 | 1 | Log in to see
prices |
|
|
| 178 |
MER 2244Y51
|
Shift shaft
| | All others | 1 | Log in to see
prices |
|
|
| 179 |
MER 43X1006
|
Pin - shift shaft
| | All except 1899 | 1 | Log in to see
prices |
|
|
| 180 |
MER 42X1027
|
Washer - piston
| | All except 1752, 1753 & 1899 | 1 | Log in to see
prices |
|
|
| 181 |
MER 3261A1067
|
Tube - air cylinder
| | 1899 | 1 | Log in to see
prices |
|
|
| 181 |
MER 3196F32
|
Tube - air cylinder
| | All others | 1 | Log in to see
prices |
|
|
| 182 |
MER KIT2824
|
Piston
| | 1899 | 1 | Log in to see
prices |
|
|
| 182 |
MER 2230N170
|
Piston
| | All others | 1 | Log in to see
prices |
|
|
| 183 |
MER 5X1198
|
O-ring
| | 1899 | 1 | Log in to see
prices |
|
|
| 183 |
MER 5X1153
|
O-ring
| | All others | 1 | Log in to see
prices |
|
|
| 184 |
MER 2208H944
|
Gasket - cylinder cover
| | All except 1899 | 1 | Log in to see
prices |
|
|
| 185 |
MER 41X1368
|
Capscrew - manual engaging (shipping)
| | 1899 | 1 | Log in to see
prices |
|
|
| 185 |
MER 41X1333
|
Capscrew - manual engaging (shipping)
| | All others | 1 | Log in to see
prices |
|
|
| 185A |
MER 5X521
|
O-ring
| | 1899 | 1 | Log in to see
prices |
|
|
| 186 |
MER 3266F1020
|
Cover cylinder
| | All except 1899 | 1 | Log in to see
prices |
|
|
| 187 |
MER 41X1364
|
Capscrew - cylinder cover
| | All others except 1899 | 4 | Log in to see
prices |
|
|
| 188 |
MER MWA-506
|
Washer - cylinder cover
| | All except 1899 | 4 | Log in to see
prices |
|
|
| 189 |
MER 2208L1000
|
Gasket - plug
| | All except 1899 | 1 | Log in to see
prices |
|
|
| 190 |
MER MS210016-1
|
Plug - cylinder cover
| | All except 1899 | 1 | Log in to see
prices |
|
|
| 191 |
MER KIT4429
|
Switch - sensor
| | All | 1 | Log in to see
prices |
|
|
| 191A |
1229U1503QG
|
Washer - sensor switch
| | 1752 & 1753 | 2 | Log in to see
prices |
|
|
| 192 |
MER 1227P1056
|
Nut - sensor switch
| | All except 1752, 1753 & 1899 | 1 | Log in to see
prices |
|
|
| 194 |
MER 2208L1000
|
Gasket - adapter
| Only used with item 193 which are no longer available | | 1 | Log in to see
prices |
|
|
| 194A |
MER 3266M897
|
Cover - cylinder hole
| | For carriers with DCDL bolt holes, but less DCDL | 1 | Log in to see
prices |
|
|
| 194B |
MER 41X1080
|
Capscrew - cylinder hole cover
| | For carriers with DCDL bolt holes, but less DCDL | 4 | Log in to see
prices |
|
|
| 194C |
MWA-516
|
Washer - cylinder hole cover
| | For carriers with DCDL bolt holes, but less DCDL | 4 | Log in to see
prices |
|
|
 |
.JPG "Forward Carrier Sans Iad & Pump"){kind=small}
Forward Carrier Sans Iad & Pump.JPG "Forward Carrier W Iad & Pump"){kind=small}
Forward Carrier W Iad & Pump
Housing Assembly
