| Item No. |
Part Number |
Name | Notes | Price |
Buy |
|
| 1 |
1356 090 004
|
Hub, Shift Collar
| 9T, 48 Spline | Log in to see
prices |
|
|
| 2 |
1356 539 003
|
Assy, Rear Case Half
| | Log in to see
prices |
|
|
| 2A |
1356 039 012
|
Case, Rear Half
| | Log in to see
prices |
|
|
| 2B |
6207
|
Bearing, Rear Output
| Can Use 1345 130 001 | Log in to see
prices |
|
|
| 2C |
1300 139 027
|
Ring, Retaining
| 2 Req'D | Log in to see
prices |
|
|
| 2D |
B2012
|
Bearing Needle
| | Log in to see
prices |
|
|
| Ni |
1300 052 003
|
Plug, Drain/Fill
| 2 Req'D | Log in to see
prices |
|
|
| 3 |
1356 053 003
|
Spacer
| All exc. Assy# 1356-085,086,089 | Log in to see
prices |
|
|
| 4 |
1900 110 017
|
Gear, Speedo (7T)
| All Exc. Assy# 1356-085,086,089 & Below | Log in to see
prices |
|
|
| 4 |
1900 110 018
|
Gear, Speedo (8T)
| Assy# 1356-046,049,052 | Log in to see
prices |
|
|
| 5 |
1356 527 001
|
Assy, Bearing Cap
| Assy# 1356-089 | Log in to see
prices |
|
|
| 5 |
1356 566 003
|
Assy, Bearing Cap
| Assy# 1356-016,052,053 | Log in to see
prices |
|
|
| 5 |
1356 566 010
|
Assy, Extension Housing
| Assy# 1356-085,086 | Log in to see
prices |
|
|
| 5 |
1356 566 012
|
Assy, Extension Housing
| Assy# 1356 004,008,046 - 049 | Log in to see
prices |
|
|
| 5 |
1356 566 009
|
Assy, Extension Housing
| Assy# 1356-085,086 | Log in to see
prices |
|
|
| 5 |
1356 566 011
|
Assy, Extension Housing
| Assy# 1356 004,008,046 - 049 | Log in to see
prices |
|
|
| 5A |
1356 027 001
|
Cap, Bearing
| Assy# 1356-089 | Log in to see
prices |
|
|
| 5A |
1356 066 005
|
Cap, Bearing (Fixed)
| Assy# 1356-016,052,053 | Log in to see
prices |
|
|
| 5A |
1356 066 008
|
Extension (Slip)
| Assy# 1356-085,086 | Log in to see
prices |
|
|
| 5A |
1356 066 009
|
Extension (Slip)
| Assy# 1356 004,008,046 - 049 | Log in to see
prices |
|
|
| 5B |
FUL 18507
|
Seal, Rear Output
| Slip Yoke, Can Use 1900 044 03 | Log in to see
prices |
|
|
| 5B |
18892
|
Seal, Rear Output
| Bolt On, Can Use1900 044 012 | Log in to see
prices |
|
|
| 5C |
1356 127 001
|
Bushing, Ext Housing
| | Log in to see
prices |
|
|
| Ni |
1300 183 017
|
Bolt, Ext. Housing
| 4 Req'D 1989 & Up | Log in to see
prices |
|
|
| Ni |
1300 183 008
|
Bolt, Ext. Housing
| 4 Req'D 1987-88 | Log in to see
prices |
|
|
| 6 |
1356 531 002
|
Assy, Rear Output Yoke
| | Log in to see
prices |
|
|
| 6 |
1356 531 004
|
Assy, Rear Output Flange
| | Log in to see
prices |
|
|
| 6A |
nss
|
Yoke, Rear Output
| | Log in to see
prices |
|
|
| 6A |
nss
|
Flange, Rear Output
| | Log in to see
prices |
|
|
| 6B |
1300 035 001
|
Deflector
| | Log in to see
prices |
|
|
| 7 |
1300 016 002
|
Washer, Rubber
| Bolt On | Log in to see
prices |
|
|
| 7 |
1356 016 001
|
Washer, Rubber
| Slip Yoke | Log in to see
prices |
|
|
| 8 |
1000 047 015
|
Washer, Yoke
| | Log in to see
prices |
|
|
| 9 |
1900 149 002
|
Nut, Output Yoke
| | Log in to see
prices |
|
|
| 10 |
1356 014 002
|
Plate, Speedo Isolator
| | Log in to see
prices |
|
|
| 11 |
1300 146 003
|
Bolt, Isolator Plate
| | Log in to see
prices |
|
|
| Ni |
F2UZ 7H183 A
|
Plug, Speedo
| | Log in to see
prices |
|
|
| 12 |
1356 589 001
|
Assy, Lockup
| | Log in to see
prices |
|
|
| 12 |
1356 589 002
|
Assy, Lockup
| | Log in to see
prices |
|
|
| 12A |
1356 055 001
|
Collar, Lockup
| | Log in to see
prices |
|
|
| 12B |
1350 156 007
|
Spring
| | Log in to see
prices |
|
|
| 12C |
1900 089 001
|
Hub, Lockup
| | Log in to see
prices |
|
|
| 12D |
1000 139 041
|
Ring, Retaining
| | Log in to see
prices |
|
|
| 13 |
1356 144 003
|
Sprocket, Chain Drive
| | Log in to see
prices |
|
|
| 14 |
1356 671 004
|
Assy, Mainshaft & Pump
| Slip Yoke | Log in to see
prices |
|
|
| 14 |
1356 671 005
|
Assy, Mainshaft & Pump
| W/ Fixed Yoke | Log in to see
prices |
|
|
| 14 |
1356 671 015
|
Assy, Mainshaft & Pump
| Assy# 1356-085,086 | Log in to see
prices |
|
|
| 14 |
1356 671 016
|
Assy, Mainshaft & Pump
| Assy# 1356-086,089 | Log in to see
prices |
|
|
| 14 |
1356 671 006
|
Assy, Mainshaft & Pump
| Assy# 1356-053 | Log in to see
prices |
|
|
| 14A |
1356 171 007
|
Mainshaft
| Rear Spline | Log in to see
prices |
|
|
| 14A |
1356 171 009
|
Mainshaft
| 32 Spl., 48 Hub Spl., 31 Output Spl. | Log in to see
prices |
|
|
| 14A |
1356 171 013
|
Mainshaft
| Rear Flange | Log in to see
prices |
|
|
| 14B |
1345 043 007
|
Pin, Pump
| 2 Req'D | Log in to see
prices |
|
|
| 14C |
1345 156 004
|
Spring
| | Log in to see
prices |
|
|
| 14D |
1345 039 007
|
Cover, Front Pump
| | Log in to see
prices |
|
|
| 14E |
1345 097 004
|
Housing, Pump
| | Log in to see
prices |
|
|
| 14F |
1345 039 005
|
Cover, Rear Pump
| | Log in to see
prices |
|
|
| 14G |
1356 056 004
|
Retainer, Rear
| | Log in to see
prices |
|
|
| 14H |
1345 183 003
|
Screws, Pump
| 4 Req'D | Log in to see
prices |
|
|
| 15 |
1350 034 002
|
Clamp, Hose
| | Log in to see
prices |
|
|
| 16 |
1356 034 001
|
Hose
| | Log in to see
prices |
|
|
| 17 |
1345 238 001
|
Filter
| | Log in to see
prices |
|
|
| 18 |
1000 109 001
|
Ball, Speedo
| All Exc. Assy# 1356-085,086,089 | Log in to see
prices |
|
|
| 19 |
1356 089 003
|
Hub, Reduction Shift
| Late After 6/5/97 | Log in to see
prices |
|
|
| 19 |
1356 089 001
|
Hub, Reduction Shift
| Early After 6/5/97 | Log in to see
prices |
|
|
| 20 |
1356 410 003
|
Kit, Planetary Update
| W/O Pto Can Use 1356 410 004 | Log in to see
prices |
|
|
| 20 |
1356 410 004
|
Kit, Planetary Update
| W/ Pto | Log in to see
prices |
|
|
| 20A |
1356 189 006
|
Shaft, Input
| W/O Pto | Log in to see
prices |
|
|
| 20A |
1356 189 007
|
Shaft, Input
| W/ Pto | Log in to see
prices |
|
|
| Ni |
1356 689 005
|
Assy, Input Shaft
| W/O Pto | Log in to see
prices |
|
|
| Ni |
1356 689 006
|
Assy, Input Shaft
| W/ Pto | Log in to see
prices |
|
|
| 20B |
1300 132 015
|
Bearing, Input Pocket
| | Log in to see
prices |
|
|
| 20B |
1345 127 001
|
Bushing, Input Pocket
| | Log in to see
prices |
|
|
| 20C |
1900 193 026
|
Washer
| | Log in to see
prices |
|
|
| 20D |
4406 659 001
|
Carrier, Planetary
| | Log in to see
prices |
|
|
| 20E |
4406 014 001
|
Plate, Planetary Carrier
| | Log in to see
prices |
|
|
| 20F |
4407 042 001
|
Shaft, Pinion
| 4 Req'D | Log in to see
prices |
|
|
| 20G |
1900 193 027
|
Washer, Thrust
| 8 Req'D | Log in to see
prices |
|
|
| 20H |
4406 163 001
|
Gear, Pinion
| 4 Req'D | Log in to see
prices |
|
|
| 20I |
1300 131 002
|
Bearing, Needle
| 152 Req'D | Log in to see
prices |
|
|
| 20J |
1900 053 013
|
Spacer (Wedding Ring)
| 4 Req'D | Log in to see
prices |
|
|
| 21 |
1300 139 012
|
Ring, Retaining
| | Log in to see
prices |
|
|
| 22 |
4407 162 001
|
Gear, Planetary Ring
| | Log in to see
prices |
|
|
| 23 |
4400 070 001
|
Gear, PTO
| W/ Pto | Log in to see
prices |
|
|
| 24 |
1300 191 010
|
Cover, PTO Opening
| Can Use T53-160D | Log in to see
prices |
|
|
| Ni |
1000 183 008
|
Bolts, PTO Cover
| | Log in to see
prices |
|
|
| 25 |
1300 045 001
|
Gasket, PTO Cover
| | Log in to see
prices |
|
|
| 26 |
18771
|
Seal, Input
| Can Use 1900 044 019 | Log in to see
prices |
|
|
| 27 |
1300 139 009
|
Ring, Retaining
| | Log in to see
prices |
|
|
| 28 |
1900 072 005
|
Breather
| | Log in to see
prices |
|
|
| 29 |
4400 640 076
|
Switch, 4WD Indicator
| | Log in to see
prices |
|
|
| 30 |
1356 531 001
|
Assy, Flange Yoke
| All Exc. Below | Log in to see
prices |
|
|
| 30 |
1356 531 002
|
Assy, Flange Yoke
| Assy# 1356-008,048,049,086 | Log in to see
prices |
|
|
| 30A |
nss
|
Yoke, Front Output
| | Log in to see
prices |
|
|
| 30B |
1300 035 001
|
Deflector
| | Log in to see
prices |
|
|
| 31 |
1300 016 001
|
Sealing Ring
| | Log in to see
prices |
|
|
| 32 |
1356 598 005
|
Assy, Shift Shaft
| Straight, W/O Shaft | Log in to see
prices |
|
|
| 32 |
1356 598 007
|
Assy, Shift Shaft
| Straight, Setscrew Shaft | Log in to see
prices |
|
|
| 32 |
1356 598 008
|
Assy, Shift Shaft
| Curved W/ Shaft | Log in to see
prices |
|
|
| 32 |
1356 598 009
|
Assy, Shift Shaft
| Straight, Splined Shaft | Log in to see
prices |
|
|
| Ni |
1356 098 004
|
Shift Lever
| Assy # 1356-004, 008, 016 | Log in to see
prices |
|
|
| Ni |
1356 122 001
|
Shaft, Shifter
| Shift Shaft Only | Log in to see
prices |
|
|
| 33 |
1356 565 005
|
Assy, Front Case Half
| W/O Pto | Log in to see
prices |
|
|
| 33 |
1356 565 011
|
Assy, Front Case Half
| W/ Pto | Log in to see
prices |
|
|
| 33A |
1356 065 007
|
Case, Front Half
| W/O Pto | Log in to see
prices |
|
|
| 33A |
1356 065 009
|
Case, Front Half (Alum)
| W/ Pto | Log in to see
prices |
|
|
| 33B |
6010
|
Bearing, Input
| Can Use 1300 130 001 | Log in to see
prices |
|
|
| 33C |
1300 139 010
|
Ring, Retaining
| | Log in to see
prices |
|
|
| 33D |
6207
|
Bearing, Front Output
| Can Use 1345 130 001 | Log in to see
prices |
|
|
| 33E |
T86-7.5
|
Ring, Retaining
| | Log in to see
prices |
|
|
| 33F |
18994
|
Seal, Front Output
| Can Use 1900 044 012 | Log in to see
prices |
|
|
| 33G |
1900 043 008
|
Dowel Pin
| 2 Req'D | Log in to see
prices |
|
|
| Ni |
1300 183 017
|
Bolt, Case Half
| 12 Req'D 1989 & Up | Log in to see
prices |
|
|
| Ni |
1300 183 008
|
Bolt, Case Half
| 12 Req'D 1987-88 | Log in to see
prices |
|
|
| 34 |
1000 012 002
|
Magnet
| | Log in to see
prices |
|
|
| 35 |
4400 596 001
|
Assy, Reduction Shift Fork
| | Log in to see
prices |
|
|
| 35A |
1300 096 001
|
Fork, Reduction Shift
| | Log in to see
prices |
|
|
| 35B |
1356 235 001
|
Pad, Shift Fork
| 2 Req'D | Log in to see
prices |
|
|
| Ni |
1900 127 006
|
Bushing, Reduction Fork
| 2 Req'D Assy# 1356-085,089 | Log in to see
prices |
|
|
| 36 |
1350 543 001
|
Assy, Pin, Roller, & Retainer
| | Log in to see
prices |
|
|
| 36A |
1900 043 009
|
Pin, Fork
| | Log in to see
prices |
|
|
| 36B |
1352 127 001
|
Roller
| | Log in to see
prices |
|
|
| 36C |
1350 040 002
|
Retainer
| | Log in to see
prices |
|
|
| 37 |
1356 235 001
|
Pad, Shift Fork
| 2 Req'D | Log in to see
prices |
|
|
| 38 |
1356 096 007
|
Fork, Lockup
| | Log in to see
prices |
|
|
| 39 |
1350 100 001
|
Shift Rail
| | Log in to see
prices |
|
|
| 40 |
4400 156 001
|
Spring
| | Log in to see
prices |
|
|
| 41 |
1356 156 002
|
Spring, Assist
| | Log in to see
prices |
|
|
| 42 |
1356 127 001
|
Bushing, Assist
| | Log in to see
prices |
|
|
| 43 |
1345 056 002
|
Retaining Clip
| | Log in to see
prices |
|
|
| 44 |
1356 599 001
|
Shift Cam
| Assy# 1356-049,052,053 | Log in to see
prices |
|
|
| 45 |
1356 171 008
|
Shaft, Front Output
| | Log in to see
prices |
|
|
| 46 |
1356 144 002
|
Sprocket, Chain Driven
| 34T | Log in to see
prices |
|
|
| 47 |
1345 193 005
|
Washer
| | Log in to see
prices |
|
|
| 48 |
1345 139 004
|
Ring, Retaining
| | Log in to see
prices |
|
|
| 49 |
1345 143 002
|
Chain
| 1.25" Wide | Log in to see
prices |
|
|
| Ni |
PK 1356
|
Kit, Pump Repair
| | Log in to see
prices |
|
|
| Ni |
TC1356XJ
|
Kit, Bearings & Seals
| | Log in to see
prices |
|
|
| Ni |
SK1356
|
Kit, Seal & Gasket
| | Log in to see
prices |
|
|
| Ni |
SP1356-50
|
Kit, Small Parts
| | Log in to see
prices |
|
|
 | |
BW 1345 (1980-91 Ford F150-350 & Bronco)
BW 1350 (1986-97 Ranger & Bronco II Electric Shift)
BW 1350 (1983-97 Ranger & Bronco II Mechanical Shift)
BW 1354 (1986-97 Ford Ranger, Bronco II, & Explorer Electric Shift)
BW 1354 (1983-97 Ford Ranger, Bronco II, & Explorer Mechanical Shift)
BW 1356 (1987-96 Ford F150-350 Electric Shift)
BW 1360 (Ford Motorhome)
BW 1370 (1989-91 Chevrolet Pickup)
BW 4401 (1991-97 GMC Pickup K30 Mechanical Shift)
BW 4404 (1997-Up Ford Explorer & Mountaineer w/ 5.0L & Full Time)
