| Item No. |
Part Number |
Name | Spline | Notes | Price |
Buy |
|
| 1 |
1900 645 002
|
Assy, Clutch Coil
| | | Log in to see
prices |
|
|
| 2 |
1356 539 004
|
Assy, Rear Case Half
| | | Log in to see
prices |
|
|
| 2A |
1356 039 008
|
Case, Rear Half
| | | Log in to see
prices |
|
|
| 2B |
6207
|
Bearing, Rear Output
| | Can Use 1300 139 027 | Log in to see
prices |
|
|
| 2C |
1300 139 027
|
Ring, Retaining
| | 2 Req'D | Log in to see
prices |
|
|
| 2D |
B2012
|
Bearing Needle
| | | Log in to see
prices |
|
|
| Ni |
1300 183 017
|
Bolt, Case Half
| | 12 Req'D | Log in to see
prices |
|
|
| Ni |
1300 052 003
|
Plug, Drain/Fill
| | 2 Req'D | Log in to see
prices |
|
|
| 3 |
1356 053 003
|
Spacer
| | All Exc. Assy# 1356-087,088 | Log in to see
prices |
|
|
| 4 |
1900 110 017
|
Gear, Speedo (7T)
| | All Exc. Assy# 1356-087,088 | Log in to see
prices |
|
|
| 5 |
JH1612
|
Bushing
| | Can Use 1000 132 039 | Log in to see
prices |
|
|
| 6 |
3687
|
Seal
| | Can Use 1300 044 001 | Log in to see
prices |
|
|
| 7 |
1356 056 003
|
Bracket, Wire Connector
| | | Log in to see
prices |
|
|
| 7 |
1356 185 001
|
Bracket
| | Assy# 1356-051 | Log in to see
prices |
|
|
| 7 |
1900 056 006
|
Bracket, Motor
| | Assy# 1356-051 | Log in to see
prices |
|
|
| 8 |
1356 648 001
|
Motor, Shift
| | All Exc. Below | Log in to see
prices |
|
|
| 8 |
1356 648 003
|
Motor, Shift
| | Assy# 1356-051,056,059,061 | Log in to see
prices |
|
|
| 8 |
1356 648 002
|
Motor, Shift
| | Assy# 1356-087,088 | Log in to see
prices |
|
|
| 8 |
4400 648 002
|
Motor, Shift
| | Assy# 1356-051 | Log in to see
prices |
|
|
| 9 |
1350 640 003
|
Assy, Sensor & O-Ring
| | | Log in to see
prices |
|
|
| 9A |
1300 140 002
|
Sensor, Speed
| | | Log in to see
prices |
|
|
| 9B |
1000 141 014
|
O-Ring
| | | Log in to see
prices |
|
|
| 10 |
1356 527 001
|
Assy, Bearing Cap
| | Assy# 1356-056,087 | Log in to see
prices |
|
|
| 10 |
1356 566 003
|
Assy, Bearing Cap
| | Assy# 1356-051,059 | Log in to see
prices |
|
|
| 10 |
1356 566 010
|
Assy, Extension Housing
| | Assy# 1356-085,086 | Log in to see
prices |
|
|
| 10 |
1356 566 012
|
Assy, Extension Housing
| | Assy# 1356 061 | Log in to see
prices |
|
|
| 10 |
1356 566 009
|
Assy, Extension Housing
| | Assy# 1356-088 | Log in to see
prices |
|
|
| 10A |
1356 027 001
|
Cap, Bearing
| | Assy# 1356-056,087 | Log in to see
prices |
|
|
| 10A |
1356 066 005
|
Cap, Bearing (Fixed)
| | Assy# 1356-088 | Log in to see
prices |
|
|
| 10A |
1356 066 008
|
Extension (Slip)
| | Assy# 1356-088 | Log in to see
prices |
|
|
| 10A |
1356 066 009
|
Extension (Slip)
| | Assy# 1356 061 | Log in to see
prices |
|
|
| Ni |
1356 127 001
|
Bushing, Ext. Housing
| | | Log in to see
prices |
|
|
| 10B |
18994
|
Seal
| | All Exc. Below Can Use 1900 044 012 | Log in to see
prices |
|
|
| 10B |
FUL 18507
|
Seal
| | Assy# 1356-061,088 -Can use 1900 044 013 | Log in to see
prices |
|
|
| Ni |
1300 183 017
|
Bolt, Ext. Housing
| | 4 Req'D | Log in to see
prices |
|
|
| 11 |
1356 014 002
|
Plate, Speedo Isolator
| | | Log in to see
prices |
|
|
| Ni |
1300 146 003
|
Bolt, Isolator Plate
| | | Log in to see
prices |
|
|
| 12 |
1356 531 001
|
Assy, Rear Yoke
| | | Log in to see
prices |
|
|
| 12 |
1356 531 004
|
Assy, Rear Flange
| | | Log in to see
prices |
|
|
| 12A |
1356 031 002
|
Yoke, Rear Output
| | | Log in to see
prices |
|
|
| 12B |
1300 035 001
|
Deflector
| | | Log in to see
prices |
|
|
| 13 |
1300 016 002
|
Washer, Rubber
| | | Log in to see
prices |
|
|
| 14 |
1000 047 015
|
Washer, Output Yoke
| | | Log in to see
prices |
|
|
| 15 |
1900 149 002
|
Nut, Yoke Output
| | (M22X1.5) | Log in to see
prices |
|
|
| 16 |
4401 410 001
|
Housing, Clutch Coil
| | Update Kit | Log in to see
prices |
|
|
| 17 |
1356 090 002
|
Hub, Shift Collar
| | | Log in to see
prices |
|
|
| 18 |
4400 589 001
|
Assy, Lockup
| | | Log in to see
prices |
|
|
| 18A |
4400 055 001
|
Collar, Lockup
| | | Log in to see
prices |
|
|
| 18B |
1350 156 007
|
Spring
| | | Log in to see
prices |
|
|
| 18C |
1900 089 001
|
Hub, Lockup
| | | Log in to see
prices |
|
|
| 18D |
1000 139 041
|
Ring, Retaining
| | | Log in to see
prices |
|
|
| 19 |
1356 144 003
|
Sprocket, Chain Drive
| | 34T | Log in to see
prices |
|
|
| 20 |
1356 671 006
|
Assy, Mainshaft & Pump
| | Slip Yoke Assy# 1356-051,059 | Log in to see
prices |
|
|
| 20 |
1356 671 005
|
Assy, Mainshaft & Pump
| | Fixed Yoke Assy# 1356-088 | Log in to see
prices |
|
|
| 20A |
1356 171 003
|
Mainshaft
| | W/ Flange | Log in to see
prices |
|
|
| 20A |
1356 171 009
|
Mainshaft
| | W/ Yoke | Log in to see
prices |
|
|
| 20B |
1345 043 007
|
Pin, Pump
| | 2 Req'D | Log in to see
prices |
|
|
| 20C |
1345 156 004
|
Spring
| | | Log in to see
prices |
|
|
| 20D |
1345 039 007
|
Cover, Front Pump
| | | Log in to see
prices |
|
|
| 20E |
1345 097 004
|
Housing, Pump
| | | Log in to see
prices |
|
|
| 20F |
1345 039 005
|
Cover, Rear Pump
| | | Log in to see
prices |
|
|
| 20G |
1356 056 004
|
Retainer, Pump
| | | Log in to see
prices |
|
|
| 20H |
1345 183 003
|
Bolt, Pump Housing
| | 4 Req'D | Log in to see
prices |
|
|
| 21 |
1345 056 005
|
Clamp, Hose
| | | Log in to see
prices |
|
|
| 22 |
1356 034 001
|
Hose
| | | Log in to see
prices |
|
|
| 23 |
1345 238 001
|
Filter
| | | Log in to see
prices |
|
|
| 24 |
1000 109 001
|
Ball, Speedo
| | All Exc. Assy # 1356-087,088 | Log in to see
prices |
|
|
| 25 |
1356 089 001
|
Hub, Reduction Shift
| | 38T | Log in to see
prices |
|
|
| 25 |
1356 089 003
|
Hub, Reduction Shift
| | 31T 90-97 All | Log in to see
prices |
|
|
| 26 |
1356 659 009
|
Assy, Planetary
| | | Log in to see
prices |
|
|
| 26A |
1356 189 006
|
Shaft, Input
| | | Log in to see
prices |
|
|
| Ni |
1356 689 005
|
Assy, Input Shaft
| | | Log in to see
prices |
|
|
| 26B |
1300 132 015
|
Bearing, Input Pocket
| | | Log in to see
prices |
|
|
| 26C |
1345 127 001
|
Bushing, Input Pocket
| | | Log in to see
prices |
|
|
| 26D |
1900 193 026
|
Washer
| | 2 Req'D | Log in to see
prices |
|
|
| 26E |
4406 659 001
|
Carrier, Planetary
| | | Log in to see
prices |
|
|
| 26F |
4406 014 001
|
Plate, Planetary Carrier
| | | Log in to see
prices |
|
|
| 26G |
4407 042 001
|
Shaft, Pinion
| | 4 Req'D | Log in to see
prices |
|
|
| 26H |
1900 193 027
|
Washer, Thrust
| | 8 Req'D | Log in to see
prices |
|
|
| 26I |
1300 131 002
|
Bearing, Needle
| | 152 Req'D | Log in to see
prices |
|
|
| 26J |
4406 163 001
|
Gear, Pinion
| | 4 Req'D | Log in to see
prices |
|
|
| 26K |
1900 053 013
|
Spacer (Wedding Ring)
| | 4 Req'D | Log in to see
prices |
|
|
| 27 |
1300 139 012
|
Ring, Retaining
| | | Log in to see
prices |
|
|
| 28 |
4407 162 001
|
Gear, Planetary Ring
| | | Log in to see
prices |
|
|
| 29 |
1300 139 009
|
Ring, Retaining
| | | Log in to see
prices |
|
|
| 30 |
18662
|
Seal, Input
| | Can Use 1000 044 053 | Log in to see
prices |
|
|
| 30 |
18771
|
Seal, Input
| | Can Use 1900 044 019 | Log in to see
prices |
|
|
| 31 |
1300 072 001
|
Breather
| | | Log in to see
prices |
|
|
| 32 |
1356 531 001
|
Assy, Front Yoke
| | 31 Spline | Log in to see
prices |
|
|
| 32A |
1356 032 001
|
Yoke, Front Output
| | | Log in to see
prices |
|
|
| 32B |
1356 035 001
|
Deflector
| | | Log in to see
prices |
|
|
| 33 |
1356 565 006
|
Assy, Front Case Half
| | | Log in to see
prices |
|
|
| 33A |
1356 065 008
|
Case, Front Half
| | | Log in to see
prices |
|
|
| 33B |
6207
|
Bearing, Input
| | Can Use 1345 130 001 | Log in to see
prices |
|
|
| 33C |
1300 139 010
|
Ring, Retaining
| | | Log in to see
prices |
|
|
| 33D |
6010
|
Bearing, Front Output
| | Can Use 1300 130 001 | Log in to see
prices |
|
|
| 33E |
T86-7.5
|
Ring, Retaining
| | | Log in to see
prices |
|
|
| 33F |
18994
|
Seal, Front Output
| | Can Use 1900 044 012 | Log in to see
prices |
|
|
| 33G |
1900 043 008
|
Dowel Pin
| | 2 Req'D | Log in to see
prices |
|
|
| 34 |
1000 012 002
|
Magnet
| | | Log in to see
prices |
|
|
| 35 |
4400 596 001
|
Assy, Reduction Shift Fork
| | | Log in to see
prices |
|
|
| 35A |
1300 096 001
|
Fork, Reduction Shift
| | | Log in to see
prices |
|
|
| 35B |
1356 235 001
|
Pad, Shift Fork
| | 2 Req'D | Log in to see
prices |
|
|
| Ni |
1900 127 006
|
Bushing, Reduction Fork
| | 2 Req'D All Exc Assy # 1356-051 | Log in to see
prices |
|
|
| 36 |
1350 543 001
|
Assy, Pin, Roller & Retainer
| | | Log in to see
prices |
|
|
| 36A |
1900 043 009
|
Pin, Fork
| | | Log in to see
prices |
|
|
| 36B |
1352 127 001
|
Roller
| | | Log in to see
prices |
|
|
| 36C |
1350 056 002
|
Retainer
| | | Log in to see
prices |
|
|
| 37 |
1356 235 001
|
Pad, Shift Fork
| | 2 Req'D | Log in to see
prices |
|
|
| 38 |
1356 096 007
|
Fork, Lockup
| | | Log in to see
prices |
|
|
| 39 |
1350 100 001
|
Shift Rail
| | | Log in to see
prices |
|
|
| 40 |
4400 156 001
|
Spring
| | | Log in to see
prices |
|
|
| 41 |
1356 122 007
|
Shift Shaft
| | | Log in to see
prices |
|
|
| 42 |
1356 053 005
|
Spacer
| | 2 Req'D | Log in to see
prices |
|
|
| 43 |
1356 156 006
|
Spring, Torsion
| | | Log in to see
prices |
|
|
| 44 |
1356 099 008
|
Cam, Electric Shift
| | | Log in to see
prices |
|
|
| 45 |
1356 171 008
|
Shaft, Front Output
| | | Log in to see
prices |
|
|
| 46 |
1356 144 002
|
Sprocket, Chain Driven
| | 34T | Log in to see
prices |
|
|
| 47 |
1345 193 005
|
Washer
| | | Log in to see
prices |
|
|
| 48 |
1345 139 004
|
Ring, Retaining
| | | Log in to see
prices |
|
|
| 49 |
1345 143 002
|
Chain
| | 1.25" Wide | Log in to see
prices |
|
|
| Ni |
1356 410 005
|
Kit, Service Motor
| | Assy # 1356-051 | Log in to see
prices |
|
|
| Ni |
1900 183 002
|
Capscrew
| | 3 Req'D | Log in to see
prices |
|
|
| Ni |
1350 140 010
|
Wire Connector
| | | Log in to see
prices |
|
|
| Ni |
1350 140 011
|
Wire Terminal
| | | Log in to see
prices |
|
|
| Ni |
4400 640 001
|
Assy, Wire Connector
| | | Log in to see
prices |
|
|
| Ni |
PK 1356
|
Kit, Oil Pump Repair
| Ni | | Log in to see
prices |
|
|
| Ni |
TC1356
|
Kit, Bearing & Seal
| | | Log in to see
prices |
|
|
| Ni |
SK1356XJ
|
Kit, Seal & Gasket
| | | Log in to see
prices |
|
|
| Ni |
SP1356-50
|
Kit, Small Parts
| | | Log in to see
prices |
|
|
 | |
BW 1345 (1980-91 Ford F150-350 & Bronco)
BW 1350 (1986-97 Ranger & Bronco II Electric Shift)
BW 1350 (1983-97 Ranger & Bronco II Mechanical Shift)
BW 1354 (1986-97 Ford Ranger, Bronco II, & Explorer Electric Shift)
BW 1354 (1983-97 Ford Ranger, Bronco II, & Explorer Mechanical Shift)
BW 1356 (1987-96 Ford F150-350 & Bronco Mechanical Shift)
BW 1360 (Ford Motorhome)
BW 1370 (1989-91 Chevrolet Pickup)
BW 4401 (1991-97 GMC Pickup K30 Mechanical Shift)
BW 4404 (1997-Up Ford Explorer & Mountaineer w/ 5.0L & Full Time)
