Home » LD Transfer Case » Borg Warner
BW 4404 (1997-Up Ford Explorer & Mountaineer w/ 5.0L & Full Time) Borg Warner BW4404
View Larger

BW 4404 (1997-Up Ford Explorer & Mountaineer w/ 5.0L & Full Time)


See Below  ▼ Borg Warner
More Products from Borg Warner
  Share

Overview

BW 4404 (1997-Up Ford Explorer & Mountaineer w/ 5.0L & Full Time)
Item No. Part Number Name Notes Price Buy
1
4404 539 001
 Assy, Rear Case Half Assy # 4404-001 - 005 Log in to see
prices
1
4404 539 003
 Assy, Rear Case Half Assy # 4404-006, 007 Log in to see
prices
1A
4404 039 001
 Case, Rear Half Assy # 4404-001 - 005 Log in to see
prices
1A
4404 039 002
 Case, Rear Half Assy # 4404-006, 007 Log in to see
prices
1B
1000 012 002
 Magnet Log in to see
prices
1C
N1061
 Bearing, Mainshaft Rear Can Use 1900 130 016 Log in to see
prices
1D
16485
 Seal, Rear Output Can Use 1900 044 009 Log in to see
prices
2
1300 146 004
 Stud 4 Req'D Log in to see
prices
3
1900 052 008
 Plug, Drain/Fill 2 Req'D Log in to see
prices
4
1900 183 008
 ID Tag Screw Log in to see
prices
5
1300 146 003
 Stud Log in to see
prices
6
1900 183 023
 Bolt, Case 17 Req'D Log in to see
prices
7
1900 110 004
 Gear, Speedo Drive Log in to see
prices
8
4400 031 009
 Flange, Rear Output Log in to see
prices
9
1900 044 002
 Washer,Rubber Can Use 1000 044 012 Log in to see
prices
10
1000 047 016
 Washer, Output Yoke Log in to see
prices
11
1900 149 001
 Nut, Output Yoke Log in to see
prices
12
1900 193 005
 Thrust Washer Log in to see
prices
13
4472 659 003
 Assy, Planetary Log in to see
prices
14
1900 193 006
 Thrust Washer Log in to see
prices
15
1372 162 001
 Gear, Planetary Ring Log in to see
prices
16
4404 671 001
 Assy, Mainshaft Assy # 4404-001 - 005 Log in to see
prices
16
4404 671 005
 Assy, Mainshaft Assy # 4404-006, 007 Log in to see
prices
16A
4404 171 004
 Mainshaft Assy # 4404-001 - 005 Log in to see
prices
16A
4404 171 003
 Mainshaft Assy # 4404-006, 007 Log in to see
prices
16B
1900 132 001
 Bearing, Caged Needle Log in to see
prices
16C
1900 034 001
 Oil Scoop Log in to see
prices
16D
1900 139 001
 Ring, Retaining Log in to see
prices
16E
6206
 Bearing, Mainshaft Front Can Use 1000 130 008 Log in to see
prices
16F
1900 139 045
 Ring,Retaining Log in to see
prices
16G
1900 139 057
 Ring, Retaining Log in to see
prices
17
4404 565 001
 Assy, Front Case Half Assy # 4404-001 - 003 Log in to see
prices
17
4404 565 002
 Assy, Front Case Half Assy # 4404-004 Log in to see
prices
17
4404 565 003
 Assy, Front Case Half Assy # 4404-005 - 007 Log in to see
prices
17A
4404 065 001
 Case, Front Half All Log in to see
prices
17B
18994
 Seal, Input Can Use 1900 044 012 Log in to see
prices
17C
16485
 Seal, Front Output Shaft Can Use 1900 044 009 Log in to see
prices
17D
6207
 Bearing, Front Output Can Use 1345 130 001 Log in to see
prices
17E
1900 127 003
 Bushing, Input Log in to see
prices
17F
1900 043 008
 Dowel Pin 2 Req'D Log in to see
prices
18
1000 043 017
 Dowel Pin Log in to see
prices
19
1900 072 005
 Breather Log in to see
prices
20
4404 689 001
 Assy, Input Shaft Log in to see
prices
20A
4404 189 001
 Shaft, Input Log in to see
prices
20B
1352 034 002
 Oil Tube Log in to see
prices
21
6009
 Bearing, Input Ball Can Use 1900 130 002 Log in to see
prices
22
4404 144 001
 Sprocket, Chain Drive Log in to see
prices
23
4473 625 001
 Assy, Viscous Clutch Log in to see
prices
24
4404 665 001
 Assy, Sun Gear Log in to see
prices
Ni
4404 165 001
 Gear, Sun Log in to see
prices
25
SCH1310
 Shaft Bushing Can Use 1900 127 004 Log in to see
prices
26
4404 671 002
 Assy, Front Output Shaft Assy # 4404-001 - 004 Log in to see
prices
26
4404 671 004
 Assy, Front Output Shaft Assy # 4404-005 - 007 Log in to see
prices
26A
4404 171 001
 Shaft, Front Output Assy # 4404-001 - 004 Log in to see
prices
26A
4404 171 003
 Shaft, Front Output Assy # 4404-005 - 007 Log in to see
prices
26B
1350 035 002
 Dust Shield Log in to see
prices
27
4400 150 001
 Damper Log in to see
prices
28
1900 183 008
 Bolt, Damper 2 Req'D Log in to see
prices
29
1900 139 007
 Retainer, Frt. Output Bearing Log in to see
prices
29
1300 139 027
 Retainer, Frt. Output Bearing Log in to see
prices
Ni
1372 053 002
 Spacer Log in to see
prices
30
4410 144 003
 Sprocket, Chain Driven Log in to see
prices
31
6206
 Bearing, Front Output Shaft Can Use 1000 130 011 Log in to see
prices
32
HV051
 Chain 1.25" Wide Assy # 4404-001 - 006 Log in to see
prices
32
HV070
 Chain 1.25" Wide Assy # 4404-007 Log in to see
prices
Ni
TC4404
 Kit, Bearing & Seal Log in to see
prices
Ni
SK4404
 Kit, Seal & Gasket Log in to see
prices

Specifications

  Product NameBW 4404 (1997-Up Ford Explorer & Mountaineer w/ 5.0L & Full Time)
  Brand NameBorg Warner

Documents

BW - 4404.pdf
